- Page 1 Installation and Programming Manual V1 V-D2425B / V-D2440B Digital Clock +1 540-563-2000 P. Valcom, Inc. +1 540-362-9800 F. 5614 Hollins Road www.valcom.com Roanoke, VA 24019...
-
Page 2: Wiring Information
Valcom, Inc. +1 540-563-2000 P. 5614 Hollins Road +1 540-362-9800 F. Roanoke, VA 24019 www.valcom.com V-D2425B / V-D2440B Wired Digital Clock Table of Contents Table of Contents—2 Installation Included in the Kit—3 Surface (Wall) Mount Installation —4 Surface (Wall) Mount Installation (continued)—5 Double Mount Installation—6... -
Page 3: Included In The
Valcom, Inc. +1 540-563-2000 P. 5614 Hollins Road +1 540-362-9800 F. Roanoke, VA 24019 www.valcom.com Included in the Kit Below is a list of all the items included in the installation kit. Surface Mount – 24VDC Kit Kit will be labeled: D-PK-3-24-S •... -
Page 4: Surface (Wall) Mount
Valcom, Inc. +1 540-563-2000 P. 5614 Hollins Road +1 540-362-9800 F. Roanoke, VA 24019 www.valcom.com Surface (Wall) Mount Installation... -
Page 5: Wiring And Jumper
Valcom, Inc. +1 540-563-2000 P. 5614 Hollins Road +1 540-362-9800 F. Roanoke, VA 24019 www.valcom.com Surface (Wall) Mount Installation (continued) Mount Housing to Wall and/or Gang Box - To mount the housing to the wall, install two (2) wall anchors into the wall (not supplied in kit) and take two pan head screws no larger than #8 (also not supplied in kit) and drive them into the anchors leaving an 1/8th inch gap between the head of the screw and the wall. -
Page 6: Double Mount
Valcom, Inc. +1 540-563-2000 P. 5614 Hollins Road +1 540-362-9800 F. Roanoke, VA 24019 www.valcom.com Double Mount Installation... - Page 7 Valcom, Inc. +1 540-563-2000 P. 5614 Hollins Road +1 540-362-9800 F. Roanoke, VA 24019 www.valcom.com Double Mount Installation (continued) *For metal mounting bracket: Use a wall anchor that can support 50 lbs or more with a maximum screw size of #8 Screw both housings together - Using the two (2) self tapping, 6-19 x 7/16”...
- Page 8 Valcom, Inc. +1 540-563-2000 P. 5614 Hollins Road +1 540-362-9800 F. Roanoke, VA 24019 www.valcom.com Double Mount Installation (continued) Feed wiring through base and pole - Take the wiring coming from the switch box and begin to feed it through the center of the base of the mounting assembly until it emerges from the hole in the center of the clock housing.
- Page 9 Valcom, Inc. +1 540-563-2000 P. 5614 Hollins Road +1 540-362-9800 F. Roanoke, VA 24019 www.valcom.com Wiring and Jumper Settings...
-
Page 10: Wire Digital
Valcom, Inc. +1 540-563-2000 P. 5614 Hollins Road +1 540-362-9800 F. Roanoke, VA 24019 www.valcom.com 2-Wire Digital Communication RS485 Output V-VCU 120VAC or 240VAC 24VDC Wired Analog Clock Wired Digital Clock V-VCU 120VAC or 240VAC 24VDC Wired Analog Clock... -
Page 11: Frequently Asked
Can the digital clock be used as an independent clock? No, the V-D2425B and V-D2440B digital clocks require Valcom 2-wire digital correction. Some clocks require a 9 volt battery backup for timekeeping. What happens to the V-D2524B or V-D2440B if a power failure occurs? Upon restoration of power, the clock immediately receives a correction signal from the master clock and resets itself to display the correct time. -
Page 12: Troubleshooting
Valcom, Inc. +1 540-563-2000 P. 5614 Hollins Road +1 540-362-9800 F. Roanoke, VA 24019 www.valcom.com Troubleshooting The clock is not running. What do I do? Measure the input voltage to the clock. The voltage should measure 10-28 volts in the 2.5”/24VDC model and 16-28 volt in the 4.0”/24VDC model.
