Valcom V-AW12A Installation Manual page 51

Double Mount Installation - V-AW12A / V-AW16A
9) Place the cover back onto each battery pack. You
should hear a snapping noise as the locking tab
engages. Use the #4x5/16 Screw screw to prevent
the cover from opening again.
11) If you feel the need to detach the clock from the housing after the installation has been completed,
remove the outer adapter screws, press down on the latches, and gently pull on the rim of the clock until
the clock detaches.
9
Valcom, Inc.
5614 Hollins Road
Roanoke, VA 24019
USA
10
10) Remove the outer adapter screws, then slide
each clock onto the adapter in the rotation that you
wish it to be viewed. You should hear a snapping
noise as the four clips on the adapter secure the
clock in place. Insert the screws again to complete
the installation.
11
P. 540-563-2000
F. 540-362-9800
www.valcom.com
51
