Setting Up the Alarms

3-4
The Series 1 has two optional alarms for each channel. To select the
measurement mode, units and set point values for each alarm, press
the keys shown in Table 3-2. A screen appears similar to Figure 3-2
below. Figure 3-19 on page 3-32 for a menu map.
To test alarms, refer to Testing the Alarm Relays in Chapter 2,
Troubleshooting and Maintenance, of the Service Manual.
Table 3-2: Moving to Alarm Settings Menu
Press the Main Menu key:
SETTINGS*
OUTPUTS
ALARMS
*The Settings Menu will prompt for a passcode (see page 2-6).
ALARM SETPOINT
Alarm A
Mode: OFF
Trip: Above
Setpoint: +0.0000
+0.0000
Deadband:
Reset
Status:
Alarm Settings Menu
SET CHANNEL
Figure 3-2: Alarm Settings Menu
Note: The first time you enter this menu, all alarm relays are OFF.
When an alarm value is not entered, the alarm relay is OFF.
To enter the:
Settings Menu
Output Settings Menu
Alarm Settings Menu
Ch
1
Alarm B
OFF
Above
+0.0000
+0.0000
Reset
TEST DONE
