Introduction

Setting Up the
Recorders
Advanced Programming
Now that the Series 1 is running and the screen is set up, you may
want to use the other operational features that are listed below:
•

Setting Up the Recorders

•
Setting Up the Alarms
•
Using Automatic Calibration
•
Entering Constants and User Functions
•
Using Enhanced Response
•
Using Data Logging
•
Setting Up the RS232 Communications Port
•
Setting Error Processing
The Series 1 has two recorder outputs for each channel: Recorder A
and Recorder B. To select the measurement mode, units and range for
each recorder, press the menu keys as shown in Table 3-1 below. The
screen appears similar to Figure 3-1 on page 3-2. Figure 3-19 on page
3-32 for a menu map.
IMPORTANT: Switch Blocks must be set to the appropriate
positions for output ranges. See Connecting the
Recorder Outputs in Chapter 1 of the Service
Manual.
To test or trim recorders, refer to Testing the Recorder Outputs or
Trimming Recorders in Chapter 2 of the Service Manual.
Table 3-1: Entering the Recorder Settings Menu
Press the following menu keys:
SETTINGS*
OUTPUTS
RECORDER
* The Settings Menu will prompt for a passcode (see page 2-6).
April 2004
To enter the:
Settings Menu
Output Settings Menu
Recorder Settings Menu
3-1
