Verify that the correct probe types have been activated for each
channel. To do this, make sure a probe is activated for each
measurement it is capable of taking. For example, if a Moisture
Image Series Probe with the temperature and pressure functions is
connected to channel 1, "MIS" must be selected in the hygrometry,
temperature, and pressure columns as shown in Figure 2-6 below.
If the optional auxiliary inputs are installed and active, you only need
to select whether the input is current or voltage. If you do not select
current or voltage, the Series 1 defaults to current.
Note: If you are using an auxiliary input to measure pressure,
activate Au1 (or Au2 depending on which input you are using)
in the pressure column for the desired channel; then activate
current or voltage in the Aux 1(or Aux 2) column.
In addition, if you connect a pressure transducer to the PRESS/
OTHER terminal block, you must activate the TF probe in the
pressure column for that channel.
If you need to change any data in the Probe Configuration Menu, see
the following section, Entering or Changing Probe Configuration
Data. If the data is correct, refer to Tagging the Inputs on page 2-37.
SYSTEM CONFIGURATION
Ch O2 HYG
MIS
1
2
3
4
5
6
Probe Configuration Menu
HELP TAG
Figure 2-6: MIS Probe Configuration on Channel 1
