GE Moisture Image 1 Series Programming Manual page 33

April 2004
Entering Moisture Probe
Calibration Data (cont.)
2-14
Referring to the Calibration Data Sheets, enter calibration data
separately for each probe on the designated channel as described
below. Figure 3-19 on page 3-32 for a menu map.
Note: If you want to enter a constant value, refer to Entering
Constants on page 3-9. It is not necessary to enter the
calibration data if you are using a constant.
1. At the System Calibration Menu (see Table 2-3 on page 2-12),
press the PROBE menu key until the Moisture Probe Calibration
screen appears (see Figure 2-7 below).
2. Use the CHANNEL menu key to cycle to the desired channel. The
channel number is indicated in the top right-hand corner of the
screen.The screen will only display installed channels.
Moisture Probe Calibration
S/N:
## MH DP/°C
01
02
03
04
05
06
07
08
System Calibration Menu
HELP CHANNEL
Figure 2-7: System Calibration Menu for Moisture
S/N
3. Move the pointer to
4. Enter the probe serial number from the Calibration Data Sheet,
and press [YES]. (The serial number is also scribed on the hex nut
of the moisture probe.) The pointer automatically jumps to
Press [YES] again.
5. Enter the number of data points indicated on the Calibration Data
Sheet (typically 2-16 points for each probe), and press [YES]. The
pointer automatically jumps to the first data point.
6. Move the pointer to 1 and enter the MH (or FH) values and dew
point (in °C) for each data point. Make sure you press [ENT] after
you enter each value.
7. Repeat Step 6 for each data point.
8. Repeat Steps 2 through 7 to enter moisture probe calibration data
for the remaining channels.
To enter calibration data for other probes, refer to the following
sections. To exit, press the DONE menu key until Main Menu
appears on the message line. Then refer to Entering High and Low
Reference Values on page 2-21.
ND:
## MH DP/°
09
10
11
12
13
14
15
16
Screen 1 of 1
PROBE
and press [YES].
Basic Programming
Ch
1
DONE
ND .
