Powering Up (cont.)
Basic Programming
Do not operate the Delta F oxygen cell for extended
periods of time at oxygen concentrations that are over
range. Trace and low percent range sensors may be
damaged if exposed to high levels of oxygen, such as
air, for long periods (>1 hour) while the Series 1 is on. If
exposure is unavoidable, either disconnect the oxygen
cell from the Series 1 or equip the sample system with a
valve that allows the cell to be switched to purge gas.
If the meter passes its self-test, the screen begins displaying
measurements in a matrix format similar to the one shown in
Figure 2-1 below.
1 Dew Point
-18.0 °C
2 Temperature
+35.9 °C
3 H O
2
+0.535 ppm
Main Menu
HELP SELECT
Figure 2-1: Screen Matrix Format After Power Up
Caution!
4 Oxygen
48.3 ppb
5 Pressure
27.10 PSIg
X Unassigned
v
11:35 01/22/2000
SETTINGS
June 2003
v
pg: 1
OPTIONS
2-3
