Viewing the Data Logger
Status

Viewing Logged Data

Removing Logged Data

3-18
Press the keys as shown in Table 3-7. The screen appears similar to
Figure 3-7 below. Figure 3-18 on page 3-31 for a menu map. Log
statuses include running, stopped, pending (waiting to start) or
finished. The screen also displays whether internal or extra (PCMCIA
card) memory is in use, as well as the amount of memory available.
Table 3-7: Entering the Data Logger Menu
Press the Main Menu key:
OPTIONS
LOGGER
TUES.LOG
TIME 1:User 1
12:15:22
12:15:32
12:15:42
12:15:52
12:16:02
Data Logger Menu
HELP
Figure 3-11: The Data Logger Menu
To view a specific file from the Data Logger Menu, move the pointer
to that file, and then press [YES]. The screen appears similar to
Figure 3-11 above. Figure 3-18 on page 3-31 for a menu map.
Use the PREV and NEXT menu keys to view the next and previous
pages of logged data. To view other records, continue to press the
NEXT menu key until <end> appears at the end of the record. If the
screen has more than three columns, use the pointer to scroll across
the columns.
To exit, press the DONE menu key until Main Menu appears on the
message line.
To remove a log, select it with the arrow keys on the Data Logger
Menu. Press the [FILE] menu key, and then [REMOVE]. The screen
will ask "Are you sure?" Confirm the deletion by pressing [YES].
IMPORTANT: Deleted logs cannot be retrieved!
To enter the:
Option Menu
Data Logger Menu
VIEWING
1:DP/°C
-4.8 +15.3
-4.7 +15.3
-4.8 +15.3
-4.6 +15.3
-4.7 +15.3
15:16
NEXT PREV
Advanced Programming
06/15/00
1:FH
163.590
163.600
163.610
163.600
163.620
06/15/99
DONE
