Use the steps below to select the channels, measurement modes and
units you want to log, as well as the log interval and whether the log is
cyclic or has a definite start and end.
Note: If all six logs are filled, a log must be deleted to create room
for another.
Figure 3-18 on page 3-31 for a menu map.
1. At the Data Logger Menu (see Table 3-7 on page 3-18), select a
"New Log" file and press [YES] to enter the Label Entry Menu
shown in Figure 3-12 below.
( ) - 0 1 2 3 4 5 6 7 8 9 A B C
D E F G H I J K L M N O P Q R S
T U V W X Y Z [ ] _ { }
Label Entry:
HELP NEXT ROW
Figure 3-12: Label Entry Menu
2. Specify the log name. Use the NEXT ROW and PREV ROW
menu keys to scroll to the desired line, and then use the arrow keys
to reach the desired letters, numbers or symbols. When you have
completed the label, press the DONE menu key. The Set Data
Logger Menu now appears, as shown in Figure 3-13 below.
DATA LOGGING SETUP
Cyclic: N
Error Log: N
Start: 06/03/2000
End: 06/03/2000
Interval: 00:00
Ch:Mode Ch:Mode
: :
: :
: :
Set Data Logger Menu
HELP START
Figure 3-13: Set Data Logger Menu
