Setting Up the Line
Graph
Switching from the
Matrix Format to a Line
Graph
Basic Programming
A line graph displays data for each channel using a point-to-point
graph. A line graph is useful for indicating trends or changes in
measurements. You can only choose one measurement mode, which
you can change at any time, for all channels. Only channels
programmed for the selected measurement mode appear.
This section describes how to:
•
switch from the matrix format to a line graph
•
select the measurement units and mode
•
select the X and Y axis scale
At the Main Menu, press the keys as shown in Table 2-8 below.
Figure 3-18 on page 3-31 for a menu map. The screen appears similar
to Figure 2-18 below. Proceed to the appropriate section that follows
to change the mode, units or scale. If you do not want to change any
of the line graph settings, press the DONE menu key until Main Menu
appears on the message line.
Table 2-8: Moving from Graph Screen Menu to Main Menu
Press the following menu keys:
OPTIONS
SCREEN
GRAPHS*
*This menu key will not appear if your screen is already set up for the
graph format. If you switched your screen to display a line graph
earlier and are now returning to adjust the graph, press the MATRIX
menu key in its place. The screen will switch to the matrix format.
Press the DONE menu key once to exit the Matrix Screen Menu.
Then press the SCREEN menu key, and the GRAPHS menu key
should appear.
Dew Point, °C
+070.0
+050.0
+030.0
+010.0
-010.0
-030.0
02
00
Graph Screen Menu
MATRIX SCALE
Figure 2-18: Graph Screen Menu for a Line Graph
To enter the:
Option Menu
Matrix Screen Menu
Graph Screen Menu
10 m
04 06
08
11:35 01/22/2000
CONTRAST
April 2004
DONE
2-35
