Setting Up the
Recorders (cont.)
Selecting Measurement
Mode and Units for
Recorders
3-2
Recorder Outputs
Recorder A
Mode:
Range:
Zero:
Span:
Recorder Setting Menu
SET CHANNEL
Figure 3-1: Recorder Settings Menu
IMPORTANT: You should record this data on the Program
Information List supplied in Appendix A of the
Startup Guide, or on a separate sheet of paper, and
keep it in a safe place.
Figure 3-19 on page 3-32 for a menu map.
1. At the Recorder Settings Menu (see Table 3-1 on page 3-1), use
the CHANNEL menu key to cycle to the desired channel. The
channel number is indicated in the top right-hand corner of the
screen. The screen will only display installed channels.
2. Press the SET menu key. A box highlights Recorder A, and the
menu keys change to [RANGE], [MODE] and [A
3. Press the [A B] menu key to move the box to the desired
recorder.
4. Press the MODE menu key. A list of available measurement
modes appears on the message line. Refer to Table 2-6 on page 2-
31 for a list of measurement modes.
5. Move the brackets to the desired measurement mode and press the
UNITS menu key. A list of the available units appears on the
message line.
Note: An arrow sign at either end of the message line indicates
more choices.
6. Move the brackets to the desired units and press [YES].
Recorder B
TEST DONE
B].
