GE Moisture Image 1 Series Programming Manual page 93

Procedure for Setting
Error Processing (cont.)
Advanced Programming
Table 3-11: Entering the Error Processing Menu
Press the Main Menu key:
SETTINGS*
SYSTEM
CONFIG
ERRORS
* The Settings Menu will prompt for a passcode (see page 2-6).
1. Press the keys shown in Table 3-11 above, and a screen similar to
that in Figure 3-17 below appears (see Figure 3-19 on page 3-32
for a complete menu map of the procedure).
ERROR PROCESSING CONFIGURATION
Error: Under Range
Alarm A:
Alarm B:
Rcrd A:
Rcrd B:
Display Messages: ON
Error Processing Menu
HELP CHANNEL
Figure 3-17: Error Processing Menu
2. Use the menu key to cycle to the desired channel.
CHANNEL
3. Move the pointer to the desired range and output.
4. Press the menu key repeatedly until the desired action
ACTION
appears (the default setting for all actions is Ignore):
•
Alarms: The available actions are Trip and Ignore. For the
Ignore option, the alarms remain in the state they were in at the
time a range error occurs.
•
Recorders/Analog Outputs: The available actions are: Ignore,
High, Low, Hold (last value), and Value (specified by user). For
the Ignore option, both the A and B analog output signals are
forced to 0 mA or 0 V when a range error occurs.
5. Repeat Steps 2-4 for both ranges and for each output on the
desired channel(s).
To exit Error Processing, press the
appears on the message line.
To enter the:
Settings Menu
System Settings Menu
Probe Configuration Menu
Error Processing Menu
Over Range
Ignore TRIP
TRIP Ignore
Ignore Ignore
LOW HIGH
ACTION
menu key until Main Menu
DONE
January 2004
1
Ch
DONE
3-29
