Oxiperm 164 150-2500 g en
12 Details on the
Versions

12.1 Housing Suction

15.710010-V5.0
Spare parts for housing suction
Item Part No.
50.1 12.6101-200
12.6102-200
50.3 545-2000-1
50.5 53.056-25
50.6 53.057-25
50.7 53.058-25
50.8 52.141
50.9 53.183-25-20
50.10 12.6416-400
50.11 45.10245-1/2
45.10249-1/2
50.12 45.916
50.13 45.10131
50.14 45.10132
50.15 47.1320008
50.16 50.461
50.17 54.027
50.18 12.6238-300
12.6238-310
50.20 50.1570
Designation
Side part
Side part
Injector
Insert unit DN2 0
Screw-in unit DN20
Union nut DN20
O-ring
Reduction, short DN20 / DN15
Transition nipple
Solenoid valve 230 V, 50 Hz
Solenoid valve 115 V, 60 Hz
Cable
Cable gland M16x1.5
Cable gland M20x1.5
PE hose 8/11
Screw M6x25
Flat gasket
Rear wall of system support
Rear wall of system support
Nut M6
System
164-150C to
164-750C
164-1300C /
164-2500C
164-150C to
164-750C
164-1300C /
164-2500C
