5.2.8 Preliminary Water Tank

5.2.9 Options

Power supply
18
The preliminary water tank for dilution of the hydrochloric acid (HCl) is located
underneath the system. It is continuously filled with water via a float valve. The water
supply is via the bypass line of the Oxiperm system which is located at the rear of
the system rack. Filling of the preliminary tank can be interrupted using an
additional ball valve located at the rear of the rack.
An additional float switch prevents overflowing of the preliminary tank should the
float valve malfunction.
Code
V000
V001
Bypass Code
B000
B001
B010
B011
B012
B013
B014
B015
B016
B020
B021
B022
B023
B024
B025
B026
B027
Description
Power supply 230 V (50/60 Hz)
Power supply115 V (50/60 Hz)
Description
Bypass line with pump 230 V 50/60 Hz
Purging with ball valve
Bypass line with pump 115 V 60 Hz
Purging with ball valve
Bypass line with solenoid valve 230 V 50/60 Hz and flow limiter
Purging with ball valve
Bypass line with solenoid valve 115 V 50/60 Hz and flow limiter
Purging with ball valve
Bypass line with solenoid valve 230 V 50/60 Hz and ball valve
Purging with ball valve
Bypass line with solenoid valve 115 V 50/60 Hz and ball valve
Purging with ball valve
Bypass line for external booster pump for 115/230 V 50/60 Hz
power supply, Purging with ball valve
Bypass line for external booster pump for 230 V 50/60 Hz power
supply, Purging with ball valve
Bypass line for external booster pump for 115 V 50/60 Hz power
supply, Purging with ball valve
Bypass line with solenoid valve 230 V 50/60 Hz and flow limiter
Purging with solenoid valve / drain unit
Bypass line with solenoid valve 115 V 50/60 Hz and flow limiter
Purging with solenoid valve / drain unit
Bypass line with pump 230 V 50 Hz
Purging with solenoid valve / drain unit
Bypass line with pump 115 V 60 Hz
Purging with solenoid valve / drain unit
Bypass line with solenoid valve 230 V 50/60 Hz and ball valve
Purging with solenoid valve / drain unit
Bypass line with solenoid valve 115 V 50/60 Hz and ball valve
Purging with solenoid valve / drain unit
Bypass line for external booster pump for 230 V 50/60 Hz power
supply. Purging with solenoid valve / drain unit
Bypass line for external booster pump for 115 V 50/60 Hz power
supply. Purging with solenoid valve / drain unit
(see Section 14, Accessories, for booster pump and load unit)
