7.7.8 Bus Options

7.7.9 Program Version

7.7.10 MIN Bypass Time

15.710010-V5.0
●
Scroll in the "Basic setting" menu using the "Arrow right" and "Arrow left"
keys.
●
Switch to the "Bus options" menu using the "F2" key.
Display:
Select the bus system using the "F2" or "F3" key
Use the "Enter" or "Escape" key to return to the "Basic setting" menu.
●
In the "Basic setting" menu switch to the "Program version" display using
the "F2" key
Display:
Use the "Enter" or "Escape" key to return to the "Basic setting" menu.
Use the "Escape" key to return to the main menu.
●
In the "Basic setting" menu switch to the "MIN bypass time" display
using the "F1" key.
Display:
NOTE The min. bypass time is factory set to 60 seconds. This
time can be adjusted between 20 and 210 seconds.
Changing the MIN bypass time
●
Activate the input field using the "F1" key (flashing), enter numerical value
using the "Up" and "Down" keys, change the input point using the "Arrow
left" and "Arrow right" keys.
●
Confirm using the "Enter" key.
●
Accept the new setting using the "F2" key. The "New" and "Current" values
are now identical.
Bus options
1 Off
2 Profibus DP
3 Ethernet
Hardware C16x_01
Software
SPS: .......
OP: .......
MIN bypass time
New: XXX sec
Current: XXX sec
2 Accept
