13 Spare Parts Sets

106
Order No. Designation
553-740 164-150C
553-740.1 164-150C
553-741 164-450C
553-741.1 164-450C
553-742 164-750C
553-742.1 164-750C
553-743 164-1300C System back-pressure less than 3 bar
553-743.1 164-1300C System back-pressure greater than 3 bar
553-744 164-2500C System back-pressure less than 3 bar
553-744.1 164-2500C System back-pressure greater than 3 bar
The spare parts sets comprise:
●
O-rings for the bypass line and post-mixer
●
Check valve DN20 for bypass line
●
O-rings and flat gasket for bypass line
●
Spare parts sets for the dosing pumps (Section 11.1.3)
●
Spare parts set for dosing controller
●
Valves for the reactor (see also Section 11.3)
The spare parts refer to the positions marked with ❇ ❇ ❇ ❇ ❇
NOTE
in the single parts drawings or assembly drawings
NOTE For safety reasons we do not provide components of
the reactors as spare parts. In case of faults, the
reactor has to be exchanged as a whole!
NOTE Spare parts for the dosing pumps: see Section 11.1
Spare parts for suction lines: see Section 11.2
Spare parts for the reactor: see Section 11.3
Spare parts for the suction injector: see Section 11.4
Post-mixer
Battery for the electronics
Pressure loading valve DN8
Pressure loading valve DN20
Set of fine fuses
for electronics
Pressure hoses for HCl and
NaClO2, with connections
(pump - reactor)
Oxiperm 164 150-2500 g en
System back-pressure less than 3 bar
System back-pressure greater than 3 bar
System back-pressure less than 3 bar
System back-pressure greater than 3 bar
System back-pressure less than 3 bar
System back-pressure greater than 3 bar
Order No. 12.5861-300
Order No. 45.8801-101
Order No. 525-0567
Order No. 525-1113
Order No. 553-1095
Order No. 553-1711
15.710010-V5.0
