Technical Data

3.1 General Data

3.1.1 Performance and
Consumption Data
ClO
2
System generation
performance *
At 6 bar
back-pressure
(g/h) (l/h)
164-150C 150 428
164-450C 450 442
164-750C 750 937
164-1300C 1300 962
164-2500C 2500 1022
Tolerance of flow limiter (bypass line)
Permissible concentration of NaClO
Permissible concentration of HCl solution
Permissible ambient temperature
Permissible process water temperature (bypass water)
Permissible component temperature (chemicals)
Storage temperature of system
Storage temperature of chemicals
Permissible relative humidity
System frame
Screws, washers and nuts
Reactor
Post-mixer
Piping
Gaskets
15.710010-V5.0
Max. system Consumption of
pressure components *
50 Hz 60 Hz HCl NaClO2
1)
(bar) (bar) (l/h) (l/h)
9 6 1,0 1,0
9 6 2,8 2,8
9 6 4,8 4,8
9 6 8,2 8,2
7 6 16
* Generation performance and consumption of components are increased
by approx. 20% in 60-Hz operation
1) With max. generation performance, shortened reaction time
2) With input pressure 2 bar higher compared with the pressure at the injection
unit
3) Depends on flow losses of solution line up to injector
4) Concentration of ClO
Input pressure for bypass water: 3 - 8 bar
5) Concentration of ClO
Input pressure for bypass water: 3 - 8 bar
General concentration range for all systems: 0.5 - 3.3 g/l
solution
2
Dilution water requirement for bypass system
Solenoid valve
(standard)
H2O Standard MIN
(l/h) (l/h) (l/h)
5,5 420 63
16 420 126
27 900 315
46 900 405
16 90 900 630
solution approx. 3,3 g/l,
2
solution approx. 2 g/l,
2
+/- 10%
24.5% w/w
33 % w/w
+5 °C to +40 °C
+2 °C to +40 °C
+5 °C to +30 °C
-5 °C to +50 °C
+5 °C to +40 °C
Max. 80%, no condensation
Materials
PP
1.4301
Gray PVC, 1.4571 painted RAL 6017
Gray PVC
Gray PVC
FPM / PTFE
Bypass pump In batch mode
2) 3)
Internal/external
Standard MIN min.
(l/h) (l/h) (l/h)
420 63 30
420 126 90
900 315 150
900 405 260
900 630 510
max.
4) 5)
(l/h)
70
200
340
590
1150
