12.2 Solenoid Valve

12.3 Flow Limiter + Vane Ane-
mometer
100
Spare parts for solenoid valve
Item Part No.
30.1.1 53.055-25
30.1.5 53.183-25-20
30.1.6 53.095-20-1/2
30.1.7 45.10245-1/2
45.10249-1/2
30.1.8 54.027
Spare parts for flow limiter
Item Part No.
30.2.1 53.055-25
30.2.2 53.058-25
30.2.3 52.141
30.2.4 53.057-25
30.2.5 53.183-25-20
30.2.6 53.095-20-1/2
30.2.10 53.625-80
53.625-150
30.2.11 54.027
30.2.30 12.6202-400
30.2.31 12.6010-1
30.2.32 52.416
Oxiperm 164 150-2500 g en
Designation
Union piece DN20
Reduction, short
Transition nipple
Solenoid valve 230 V
Solenoid valve 115 V
Flat gasket
Designation
Insert unit DN20
Union nut DN20
O-ring
Screw-in unit DN20
Reduction, short
Transition nipple
Flow limiter
7 l/min
Flow limiter
16 l/min
Flat gasket
Insert unit G1/2"
Flowmeter FHKU 100
O-Ring
System
164-150C to
164-450C
164-750C to
164-2500C
15.710010-V5.0
