7.7.11 Automatic start

7.8 Service Mode

7.8.1 Venting of Bypass Water Line

and Dosing Pumps for NaClO
HCl and H O
2
48
This function is used to perform an automatic system restart, if the system's bypass
water supply becomes compromised as a result of pressure fluctuations (bypass
water undershoots the MIN limit) or if the bypass water overshoots the MAX limit.
The system will restart automatically following a set pause time. The number of start
attempts (cycles) is configurable.
Pause time:
No. of cycles:
Cycles set to 0 = „Automatic start" function not activated
If the bypass water supply remains compromised after the set number of cycles has
elapsed, an alarm message will be output (bypass water MIN or bypass water
MAX).
In the „Setup" menu, switch to the „Automatic start" menu
Display indicator:
●
Use the „F1" key to activate the input field (input field will flash). Use the „Up",
„Down", „Arrow right" and „Arrow left" keys to input the new values, then
press the „Enter" key to confirm.
●
Use the „F2" key to apply the new settings.
Use the „Enter" or „Escape" key to return to the „Setup" menu.
Use the „Escape" key to return to the main menu.
/
2
●
In the main menu, switch to the "Service mode" menu using the "F3" key,
or scroll in the main menu.
●
Switch to the "Venting" menu using the "F1" key.
Display:
1 to 10 minutes
0 - 10
Automatic start
Cycles: xxx
Pause time xxx mins
2 Accept
Venting
1 Bypass
2 HCl pump
3 NaClO 2 pump
Oxiperm 164 150-2500 g en
<off>
<off>
<off> >
