14.3 Hose Connections

14.4 Gas Sensor + Gas Warning
Device
15.710010-V5.0
Hose connection DN20 - hose with 25 mm ID for the Oxiperm system
DN20
Order No.
529-050
Adapter screwed gland for external booster pump
Order No.
529-051
PVC hose, 25 mm ID, PN6
Order No.
526-030/5
526-030/10
526-030/25
NOTE
The gas sensor can be mounted at the rear of the Oxiperm C164 system underneath
the reactor. The required mounting screw (countersunk screw M6x20) is included
in the mounting material of the system.
Gas sensor
Connex DIS-G
NOTE
CAUTION
Designation
Hose connection DN20 -
hose with 25 mm ID
with hose clamps (2x)
Designation
Adapter screwed gland
Rp 1"AG - hose with 25 mm ID
with hose clamps (2x)
Designation
Length
Length
Length
Max. system pressure for PVC hose: 6 bar
With a higher system pressure, PVC tube (DN16) must
be used for the installation.
Order No.
Order No.
The gas sensor cannot be directly connected to the
controller of the Oxiperm C164 system. A gas warning
device is required in addition. The cabling must be
carried out on site.
Please observe the operation manual of the gas
detector 307 and the gas sensor 314.
5 m
10 m
25 m
314-011
307-2000
