7.7 Basic Setting

7.7.1 Language

7.7.2 Min. Contact Water

7.7.3 Current Output

7.7.4 Code Function

15.710010-V5.0
●
In the main menu, switch to the "Basic setting" menu using the "F2" key
(scroll if necessary).
●
In the "Basic setting" menu, switch to the "Language" menu using the "F1"
key.
●
Select language using "Arrow right" or "Arrow left" key.
●
Confirm using "ENTER".
●
Use the "Enter" or "Escape" key to return to the "Basic setting" menu.
The min. contact in the main water line (on site) switches the system to standby if
the set minimum main water flow is fallen below.
●
In the "Basic setting" menu, select the "Min. contact water" menu using the
"F2" key.
●
Activate or deactivate the function using the "F1" or "F2" key.
Display:
●
Use the "Enter" or "Escape" key to return to the "Basic setting" menu.
The function is displayed flashing in the "Min. contact water" menu.
●
In the "Basic setting" menu, select the "Current output" menu using the "F3"
key.
Display:
●
Press "F1" key to select the variable input fields. Switching between the
values (0%; XXmA; 100%; YYmA) is also carried out using the "F1" key.
●
Enter individual values using the "Up" and "Down" keys (to modify
numerical values) and the "Arrow left" and "Arrow right" keys (to change
input position).
●
Confirm the set values using the "Enter" key.
The selected current output is activated by pressing the "Enter" key again.
Display:
●
Use the "Enter" or "Escape" key to return to the "Basic setting" menu.
2 different code functions can be selected:
- Level 1 Operators:
- Level 2 Parameters: unlimited privileges
NOTE Preset level 1 = 0; level 2 = 0 means unlimited
privileges without password scanning.
Min. cont. main water
activated
Current output
ClO performance
2
0% = XX mA
100% = YY mA
Current output
XX - YY mA
activated
authorisation for the menus automatic, manual
operation, Logbook and local / remote
