8.6.1 Batch Mode

68
During startup mode in batch mode, first set the concentration of the solution.
Then check the bypass water.
Setting the concentration
● Press "Escape" to switch to the main menu (see page 2)
The display reads:
● Press "F3" to switch to "Service Mode"
The display reads:
● Press "F2" to switch to the "Startup Mode" menu from the "Service Mode"
menu.
The display reads:
● Press "F1" to switch to the "Batch concentration" menu
The display reads:
NOTE The default batch concentration is 3.0 g/l.
You can enter any concentration in the range 2-3.3 g/l.
● Press "F1" to select the variable field (3.0).
● The value is entered by pressing the "Up" or "Down" buttons (to change the
number) and the left and right arrow buttons (to change the input position).
● Press "Enter" to confirm the entry
● Press "Enter" or "Escape" to return to the "Startup Mode" menu.
Oxiperm 164 150-2500 g en
Main menu <
1 Installation selection
2 Basic settings
3 Service mode >
Service Mode
1 Deaeration
2 Start-up mode
3 Test mode
Startup Mode
1 Batch concentration
2 Bypass water
3 Start
Batch concentration
3.0 g/l ClO2
15.710010-V5.0
