9.1.2 Batch Mode

15.710010-V5.0
● Press "F1" to switch to the "Activate Automatic Mode" menu from the main
menu
Auto:
Display indicator:
(Page 1) Dosing
Bypass
ClO2:
The field x.x displays the set batch concentration.
● Press "Enter"
The display changes from "start?" to "active" or from "active" to "start?". This display
indicator contains the most important information about the operation of the
installation. Further information, such as levels, dosing pumps and bypass water,
can be obtained by scrolling with the "arrow buttons" on pages 2 and 3.
Auto:
Display indicator:
(Page 2) 1 Level
2 reactor temp.
Level
● Press "F1" to switch to the "Level" menu
Display indicator:
● Press "Escape" to go back.
● The current reactor temperature can be called using the "F2" key, return
using the "Escape" key.
Scroll on with the arrow buttons on page 2:
Display indicator: Auto:
(Page 3) 1 Dosing pumps
2 Bypass
Dosing pump
● Press "F1" to switch to the "Dosing Pumps" menu
Display indicator:
The Hall sensor signals and the signals from the flow controllers can be checked
in this menu.
H = X, means Hall sensor signals; D = X, means flow controller signals.
NOTE The values displayed here are not identical to the
dosing stroke details from the individual dosing pumps,
e.g. 120 strokes/min because the calculation does not
relate to 1 minute.
x.x g/l start ?
xxx%
xxx l/h
x.x g/h >
to activate or deactivate the installation
start ? <
>
Level
HCl : MIN - MAX
NaClO 2 : MIN - MAX
ClO2: MIN - MAX
start ? <
NaClO 2
HCl
H2O
H =X D =Y
H =X D =Y
H = X D = Y
