12.7 Ball Valve (batch mode)

12.8 Solenoid valve (batch
mode)

12.9 Vane Anemometer

104
Spare parts for ball valve
Item Part No.
30.8.1 53.563-16
53.563-20
30.8.2 53.183-20-16
30.8.3 53.183-25-20
30.8.4 53.081-25
Item Part No.
30.15.5 53.919-10
53.919-11
Spare parts for vane anemometer G1/4"
Item Part No.
30.11.1 53.058-25
30.11.2 12.6202-410
30.11.3 12.6010-2
12.6010-3
12.6010-1
12.6010-1
30.11.4 52.337
Oxiperm 164 150-2500 g en
Designation
Ball valve DN10
Ball valve DN15
Reduction, short
Reduction, short
Sleeve DN20
Designation
PVC-solenoid valve 230V/50Hz
PVC-solenoid valve 115V/60Hz
Designation
Union nut DN20
Insert unit DN20-G1/4"IG
Flowmeter FHKU 40
Flowmeter FHKU 56
Flowmeter FHKU 100
Flowmeter FHKU 100
O-ring
164-150C
164 450C to
164-2500C
164-150C
System
164-150C
164-450C
164-750C
164-1300C/
164-2500C
15.710010-V5.0
