8.2.1 Batch Mode

56
Activating the "batch mode" operating mode
● In the operating mode menu, use the "F1" button to switch to the "Batch
Mode" menu.
The display reads:
Press "Enter" or "Escape" to return to the "Installation Selection" menu.
NOTE
You must ensure that the level contacts of the batch
containers are connected and correctly set up.
Otherwise, activating batch mode may result in error
messages.
Setting the concentration
● Press "Escape" to switch to the main menu (see page 2)
The display reads:
● Press "F3" to switch to "Service Mode"
The display reads:
● Press "F2" to switch to the "Startup Mode" menu from the "Service Mode"
menu.
The display reads:
● Press "F1" to switch to the "Batch concentration" menu
The display reads:
NOTE
The default batch concentration is 3.0 g/l.
You can enter any concentration in the range 2-3.3 g/l.
● Press "F1" to select the variable field (3.0).
● The value is entered by pressing the "Up" or "Down" buttons (to change the
number) and the left and right arrow buttons (to change the input position).
● Press "Enter" to confirm the entry
● Press "Enter" or "Escape" to return to the "Startup Mode" menu.
Oxiperm 164 150-2500 g en
Batch mode
activated
Main menu
<
1 Installation selection
2 Basic settings
3 Service mode
>
Service Mode
1 Deaeration
2 Start-up mode
3 Test mode
Startup Mode
1 Batch concentration
2 Bypass water
3 Start
Batch concentration
3.0 g/l ClO2
15.710010-V5.0
