6.7.2 RS232 / RS422 / 485 Interface

RS 232
RS 422 / 485
36
As a further option, the controller of the Oxiperm C164 can be equipped with
interfaces.
See following Fig. for connection of the RS232 interface
See following Fig. for connection of the RS 422 / 485 interface
