7.3 Automatic Mode

7.4 Manual Mode

7.5 Logbook

40
In this operating mode the capacity of the system can be controlled automatically
by incoming signals such as contact input, current input or bus control.
In batch mode, the solution tank is filled automatically.
The system is switched off once the chlorine dioxide solution in the tank reaches
the MAX contact.
The system is switched on again when the level in the tank drops below the MIN
contact.
NOTE In order to operate the system in automatic mode, it is
first necessary to select the system type and the
operating mode (see Sections 7.6.1 and 7.6.2).
Automatic mode is only possible together with batch mode, current input, contact
input.
In manual control mode there is no automatic operation.
Automatic mode is activated in the main menu using the "F1" key, and indicated
by flashing on the display.
This operating mode Betriebsmodus facilitates the manual input of the dosing
capacity by the display in the modes current input, contact input, manual control
or Bus control.
In batch mode, the tank is only filled once up to the MAX contact.
The system must be started again if the level in the tank drops below the MIN
contact.
NOTE In order to operate the system in manual mode, it is
first necessary to select the system type and the
operating mode.
Manual mode is activated in the main menu using the "F2" key, and indicated by
flashing on the display.
In the "Logbook" menu, all alarm messages (active / acknowledged) are recorded.
The operating hours can also be called in this menu.
●
In the main menu, switch to the "Logbook" submenu using the "F3" key
(logbook).
Display:
●
Use "F1" key to display the alarms (if present).
●
All alarm messages can be called using the "F2" key.
●
Use "F3" key to display the operating hours.
Scroll in the respective menu using the "Up" and "Down" arrow keys.
Oxiperm 164 150-2500 g en
Logbook
1 Alarm
2 Status
3 Operating hours
