3.2 Electrical Data

Power consumption
Max. permissible loading of
loating output contacts
Analog input
Analog output
Contact input
Max. permissible mains impedance C164
With 90 Watt bypass
With 340 Watt bypass
Degree of protection

3.3 Delivery State

12
Order No. Power consumption (VA)
164-150C
164-450C
164-750C
164-1300C
164-2500C
250 V / 6 A, max. 550 VA
0(4) - 20 mA Load:
0(4) - 20 mA Load:
Max. 50 pulses/second
(0.168 + j 0.168) Ohm (testing according to EN 61000-3-11)
(0.059 + j 0.059) Ohm (testing according to EN 61000-3-11)
IP 65 Electronics
IP 65 Dosing pumps
IP 65 Solenoid valve
IP 44 Bypass pump
IP 67 Dosing controller
IP 65 Flowmeter
®
The Oxiperm C 164 compact chlorine dioxide system comprises:
❏
The generation system, completely assembled and wired up, on a
PP system frame, including dosing pumps and suction line and water tanks
for preliminary dilution of the hydrochloric acid
❏
Dosing controller for flow monitoring of hydrochloric acid, sodium chlorite
and dilution water for hydrochloric acid
❏
Tank level monitor and empty signalling system for hydrochloric acid
and sodium chlorite
❏
Chlorine dioxide reactor with temperature sensor
❏
Bypass system with flowmeter and solenoid valve, or optionally
- Circulating pump and flowmeter
- Solenoid valve, dosing ball valve and flowmeter
❏
Static mixer
❏
Control electronics, directly mounted on system frame and wired up
With housing suction option:
❏
Suction injector with solenoid valve, electrically connected to the control
electronics, system frame with side parts and back part.
Oxiperm 164 150-2500 g en
550VA
550 VA
550 VA
900 VA
1100 VA
50 Ohm
max. 500 Ohm
