3.1.2 Connection Data and Weights

Connection for
System bypass water
inlet
(DN)
164-150C 20
164-450C 20
164-750C 20
164-1300C 20
164-2500C 20
10
CAUTION
Connection for
ClO solution line
2
forcing water
pressure
(DN)
20
20
20
20
20
The solution line must be provided with an excess
pressure valve (set to 10 bar) for the case that a
pressure of more than 10 bar occurs in the system with
the chlorine dioxide solution line shut (at the Oxiperm
C164 outlet) as a result of a correspondingly high input
pressure (at the Oxiperm
water line.
Housing suction
(option)
forcing pressure
requirements
(bar) (l/h)
5 1300
5 1300
5 1300
5 1300
5 1300
Oxiperm 164 150-2500 g en
® C164 inlet) in the dilution
System
weight
Suction
connection
(DN) (kg)
20 58
20 62
20 68
20 90
20 110
