Servicing The Drive Backplane; Remove The Drive Backplane - Oracle SPARC T8-2 Service Manual

Servicing the Drive Backplane

This board provides connectors for the drive signal cables. This board also serves as the
interconnect for the front I/O board, the Power and Locate buttons, and server or component
status LEDs.
These topics describe how to service the drive backplane.
"Remove the Drive Backplane" on page 159
■
"Install the Drive Backplane" on page 160
■
"Verify the Drive Backplane" on page 163
■

Remove the Drive Backplane

This is a cold-service procedure that must be performed by qualified service personnel. Power
down the server completely before performing this procedure.
This procedure requires that you handle components that are sensitive to ESD which
Caution -
can cause server components to fail.
Prepare for servicing.
1.
See "Preparing for Service" on page
Remove all drives and fillers.
2.
See "Remove a Drive" on page
Note the positions of the drives so you can return them to the correct slots.
Note -
3. Remove one or more memory risers to have easier access to components in the
drive area.
See "Remove a Memory Riser" on page
4. Remove the System Remind button assembly (air divider) by lifting it up and
away from the power supplies.
45.
65.
98.
