Oracle SPARC T8-2 Service Manual page 162

Install the Drive Backplane
Note -
both SAS cables into the drive backplane, then install the top SAS cable into the motherboard
connector labeled top. Install the other SAS cable into the bottom connector.
5. Replace the System Remind button assembly (air divider).
Replace all memory risers you removed.
6.
See "Install a Memory Riser" on page
7. Replace all drives and filler panels.
See "Install a Drive" on page
8. Return the server to operation.
See "Returning the Server to Operation" on page
Note -
the drive backplane. This number is used for service entitlement and warranty coverage. The
correct product serial number is located on a label on the front of the chassis.
162 SPARC T8-2 Server Service Manual • June 2019
The SAS cable connectors on the motherboard are labeled top and bottom. Plug the
70.
Authorized service personnel might need to reprogram the product serial number on
104.
171.
