Oracle SPARC T8-2 Service Manual page 156

Reactivate RAID Volumes
ok devalias
...
scsi0
scsi
...
5. Choose the RAID module on the motherboard.
ok select scsi
Instead of using the alias name scsi, you could type the full device path name (such as
/pci@400/pci@2/pci@0/pci@e/scsi@0).
6. List all connected logical RAID volumes to determine which volumes are in an
inactive state.
ok show-volumes
For example, the following output shows an inactive volume:
ok show-volumes
Volume 0 Target 389 Type RAID1 (Mirroring)
WWID 03b2999bca4dc677
Optimal Enabled Inactive
2 Members
Disk 1
Primary Optimal
Target 9
Disk 0
Secondary Optimal
Target c
For each RAID volume listed as inactive, type the following command to activate
7.
that volume.
ok inactive_volume activate-volume
where inactive_volume is the name of the RAID volume that you are activating. For example:
ok 0 activate-volume
Volume 0 is now activated
156 SPARC T8-2 Server Service Manual • June 2019
/pci@400/pci@2/pci@0/pci@e/scsi@0
/pci@400/pci@2/pci@0/pci@e/scsi@0
583983104 Blocks, 298 GB
HITACHI H103030SCSUN300G A2A8
HITACHI H103030SCSUN300G A2A8
