I/O Root Complex Connections
Device
Name
HDD0
HDD1
HDD2
HDD3
HDD4
HDD5
NVMe0
Single NMVe card (Slot 1)
Single NVMe Card (Slot 2)
Dual NVMe Switch Cards
NVMe1
Single NMVe card (Slot 1)
Single NVMe Card (Slot 2)
Dual NVMe Switch Cards
NVMe2
Single NMVe card (Slot 1)
Single NVMe Card (Slot 2)
Dual NVMe Switch Cards
NVME3
Single NMVe card (Slot 1)
Single NVMe Card (Slot 2)
Dual NVMe Switch Cards
Related Information
"Server Block Diagram" on page 23
■
"PCIe Card Configuration" on page 119
■
"Rear Panel Components (Service)" on page 15
■
"Remove a PCIe Card or Filler" on page 123
■
"Install a PCIe Card or Filler" on page 125
■
122 SPARC T8-2 Server Service Manual • June 2019
IOH Root Width Root Complex Path
Complex
(IOS)
0 0 x4
/pci@301/pci@1/scsi@0/disk@p0
0 0 x4
/pci@301/pci@1/scsi@0/disk@p1
0 0 x4
/pci@301/pci@1/scsi@0/disk@p2
0 0 x4
/pci@301/pci@1/scsi@0/disk@p3
1 0 x4
/pci@303/pci@1/scsi@0/disk@p0
1 0 x4
/pci@303/pci@1/scsi@0/disk@p1
0 0 x4
/pci@306/pci@1/pci@0/pci@4/nvme@0/disk@1
/pci@307/pci@1/pci@0/pci@4/nvme@0/disk@1
/pci@306/pci@1/pci@0/pci@6/nvme@0/disk@1
0 0 x4
/pci@306/pci@1/pci@0/pci@5/nvme@0/disk@1
/pci@307/pci@1/pci@0/pci@5/nvme@0/disk@1
/pci@306/pci@1/pci@0/pci@7/nvme@0/disk@1
1 0 x4
/pci@306/pci@1/pci@0/pci@6/nvme@0/disk@1
/pci@307/pci@1/pci@0/pci@6/nvme@0/disk@1
/pci@307/pci@1/pci@0/pci@6/nvme@0/disk@1
1 0 x4
/pci@306/pci@1/pci@0/pci@7/nvme@0/disk@1
/pci@307/pci@1/pci@0/pci@7/nvme@0/disk@1
/pci@307/pci@1/pci@0/pci@7/nvme@0/disk@1
Oracle ILOM
Target
/SYS/DBP/HDD0
/SYS/DBP/HDD1
/SYS/DBP/HDD2
/SYS/DBP/HDD3
/SYS/DBP/HDD4
/SYS/DBP/HDD5
