Replace the Top Cover

Replace the Top Cover
1. Place the top cover on the chassis (panel 1).
A metal air baffle is attached to the rear inside surface of the top cover. When you place the top
cover on the server, ensure that the air baffle does not catch on anything inside the server.
Set the cover down so that it is about 1 inch (2.5 cm) forward of the rear of the server.
Slide the top cover toward the rear of the chassis until the rear cover lip engages
2.
with the rear of the chassis.
Close the top cover by pressing down firmly on the cover with both hands, on
3.
the two locations highlighted in green marked "Push here to latch", until both
latches engage.
Caution -
4. Return the server to its normal operating position.
See "Return the Server to the Normal Operating Position" on page
Related Information
"Remove the Top Cover" on page 60
■
172 SPARC T8-2 Server Service Manual • June 2019
Failure to completely secure the top cover may cause the server to malfunction.
173.
