Memory Riser and DIMM FRU Names
DIMM FRU names are based on the location of the memory riser in the server, the DIMM
slot on the memory riser, and the CPU module associated with the memory riser. For example,
the full FRU name for the top-most DIMM slot (BOB1/CH0/DIMM) on the first memory riser
associated with CPU module 0 (CM0/CMP/MR0) is:
/SYS/MB/CM0/CMP/MR0/BOB1/CH0/DIMM
Memory
Riser Label
CM0/MR0
CM0/MR1
CM0/MR2
CM0/MR3
CM1/MR0
92 SPARC T8-2 Server Service Manual • June 2019
Memory Riser or DIMM FRU Name
/SYS/MB/CM0/CMP/MR0 (riser)
/SYS/MB/CM0/CMP/MR0/BOB0/CH0/DIMM
/SYS/MB/CM0/CMP/MR0/BOB0/CH1/DIMM
/SYS/MB/CM0/CMP/MR0/BOB1/CH0/DIMM
/SYS/MB/CM0/CMP/MR0/BOB1/CH1/DIMM
/SYS/MB/CM0/CMP/MR1 (riser)
/SYS/MB/CM0/CMP/MR1/BOB0/CH0/DIMM
/SYS/MB/CM0/CMP/MR1/BOB0/CH1/DIMM
/SYS/MB/CM0/CMP/MR1/BOB1/CH0/DIMM
/SYS/MB/CM0/CMP/MR1/BOB1/CH1/DIMM
/SYS/MB/CM0/CMP/MR2 (riser)
/SYS/MB/CM0/CMP/MR2/BOB0/CH0/DIMM
/SYS/MB/CM0/CMP/MR2/BOB0/CH1/DIMM
/SYS/MB/CM0/CMP/MR2/BOB1/CH0/DIMM
/SYS/MB/CM0/CMP/MR2/BOB1/CH1/DIMM
/SYS/MB/CM0/CMP/MR3 (riser)
/SYS/MB/CM0/CMP/MR3/BOB0/CH0/DIMM
/SYS/MB/CM0/CMP/MR3/BOB0/CH1/DIMM
/SYS/MB/CM0/CMP/MR3/BOB1/CH0/DIMM
/SYS/MB/CM0/CMP/MR3/BOB1/CH1/DIMM
/SYS/MB/CM1/CMP/MR0 (riser)
/SYS/MB/CM1/CMP/MR0/BOB0/CH0/DIMM
/SYS/MB/CM1/CMP/MR0/BOB0/CH1/DIMM
Ejector
Color
Black
White
Black
White
Black
White
Black
White
Black
White
Black
White
Black
White
Black
White
Black
White
Black
