6. In the RF Configuration group, enter the following fields:
Index in BSR: SPR's index number that is indexed in the BSR, e.g. 2.
BSR Air MAC Address: BSR's Air MAC address to which the SPR is
associated (valid ranges is between 0x0000 through 0xFFFF), e.g. 0x1200.
Note: For the Air MAC address, Airspan recommends using only the most
significant bytes (MSB), i.e. the two left-most bytes, and not the least significant
bytes (LSB), i.e. the right-most bytes. For example, a typical Air MAC address
would be "AB00", where the zeros represent the LSB.
7. the toolbar, click the Write
On
8. the toolbar, click the Reset
On
A Warning message box appears, requesting you to confirm device reset.
Figure 3-16: Warning message box for resetting SPR
9. Click Yes to reset the device.
01040311-07
button to apply the new settings to the SPR.
button to reset the SPR.
