6. Fill in the following fields:
Destination: enter the IP address of the SPR (e.g. 10.0.0.20)
Route Mask: enter the subnet mask of the SPR (e.g. 255.255.255.240)
To allow WipManage to help you calculate the subnet mask, click the Calc
button. The Calculate Subnet dialog box appears, as shown below.
Once you have calculated the subnet mask, click the OK button, and the Static
Route Table – Add dialog box reappears.
01040311-07
E s t a b l i s h i n g B S R - S P R L i n k i n R o u t e r M o d e
Figure 4-27: Calculate Subnet dialog box
