D e f i n i n g V L AN s
4. For IP traffic, in the IP Routing / Transparent Bridging group, perform one of
the following:
Select one of the following options:
Pass Any: passes all IP traffic
−
Drop 802.1Q: discards IP traffic that has a VLAN tag
−
To enable VLAN tagging/untagging for IP traffic, select the Tag/Untag
check box, and then enter the following fields:
VLAN ID: VLAN ID of the SPR (to the BSR)
−
Priority: select the priority level (0 to 7, where zero is the lowest
−
priority) of traffic for this VLAN
5. For SPR PPPoE traffic, fill in the fields in the PPPoE Bridging group, as
described in Step 4.
6. To enable SPR SNMP management through a VLAN, select the Management
VLAN Enabled check box, and then fill in the following fields:
VLAN ID: VLAN ID to which the WipManage station belongs
Priority: select the priority level (0 to 7, where zero is the lowest priority)
7. Click Apply, and then OK.
Notes:
1) The SDA-4S/VL – VLAN Tagging group is relevant only when ASWipLL is
configured in Bridge mode.
2) If you select the Management VLAN Enabled check box, only those
WipManage stations belonging to the defined VLAN can manage the SPR.
