6. In the RF Configuration group, in the Freq Table Size field, enter the number
of frequencies listed in the frequency table used by the BSR (valid range is 1
through 96), e.g. 23. This is used by the BSDU for synchronizing BSRs and
BSDUs.
7. the toolbar, click the Write
On
8. the toolbar, click the Reset
On
A Warning message box appears, requesting you to confirm device reset.
Figure 3-8: Warning message box for resetting BSDU
9. Click Yes to reset the device.
Notes: The BSR Power Control group contains six BSR check boxes, each
corresponding to the BSDU's rear panel BSR ports for connecting to the SPRs.
In the example configuration, all the ports are connected to BSRs.
01040311-07
button.
button to reset the BSDU.
