D e f i n i n g Q u a l i t y o f S e r vi c e
Note:
according to source; QoS for SPR is according to destination.

24.3.1. Summary of Tasks

This section describes the procedures for configuring QoS for VoIP based on
DiffServ/TOS tagging to ensure the ASWipLL system assigns the highest QoS for
VoIP packets. This QoS configuration is based on the following network scenario:
SIP server (e.g. 10.0.0.1) and softswitch (e.g. 10.0.0.2) is located behind BSR
Residential gateway (located at the subscriber's site behind the SPR), configured
with a DiffServ tag for voice data (i.e. RTP) and voice signaling
The procedure for configuring QoS for VoIP is based on the configuration setup
displayed in the figure below.
Figure 24-7: Configuration example for defining QoS for VoIP based on DiffServ/TOS
24-10
When setting priority for a specific IP address, QoS for BSR is
tagging
Airspan Networks Inc.
C o m m i s s i o n i n g M a n u a l
01040311-07
