Airspan ASWipLL Commissioning Manual page 416

M a n a g i n g F r e q u e n c y T a b l e s
Figure 20-3: Adding frequencies using Normal method
3. Click the Normal Table tab.
4. In the Insert New Table To field, enter the frequency table's index number (32
to 63). If you do not enter a number, WipManage automatically assigns it the
next available consecutive Frequency Table number.
5. In the Valid Frequencies pane (i.e. right pane), select the desired frequency, and
then click the left-pointing arrow
Frequency Table pane (i.e. left pane). For example, 2402, 2405, 2408, 2411,
2414, 1417, 2420, 2423, 2426, 2429, and 2432.
20-10
button to add the frequency to the
Airspan Networks Inc.
C o m m i s s i o n i n g M a n u a l
01040311-07
