5.9. Task 8: Add an SPR

Once you have added the BSR, you can add SPRs to this BSR. You can add up to
126 SPRs per BSR device and assign any one of the index numbers (2 through 127)
to the SPR.
In our example, we need to add one SPR (10.0.0.11) to the SPR index #2 icon (as
defined previously in WipConfig).
To add an SPR:
1. Double-click the BSR
below.
2. Right-click the SPR index #2 icon, and then from the shortcut menu, choose
Add, as shown below.
Figure 5-24: Choosing the Add command from the shortcut menu
01040311-07
E s t a b l i s h i n g B S R - S P R L i n k i n B r i d g e M o d e
icon. The BSR Zoom window appears, as displayed
Airspan Networks Inc. 5-23
