24.3.4. Task 3: Map DiffServ Tags to ASWipLL
Prioritization Scheme
You need to enable ASWipLL to recognize and assign appropriate QoS to the
DiffServ tagging that you configured for the RGW for voice data and for voice
signaling. You need to configure this for both the BSR and the SPR, thereby,
ensuring QoS in both the downlink and uplink.
This procedure is similar for the BSR and SPR, except performed in the BSR Zoom
window and SPR Zoom window respectively. Therefore, the procedure below only
describes this QoS setting for the SPR. Perform the same QoS settings for the BSR.
To enable ASWipLL QoS (e.g. SPR) to support DiffServ tagging by RGW:
1. In the SPR Zoom window, from the Configuration menu, choose QoS.
2. Select the DiffServ / TOS tab.
3. Select the Enable/Disable Priority check box, and then perform the following:
a. For priority 4, assign class (4) Media and 200 ms stamp.
b. For priority 5, assign class (5) Signaling and 250 ms stamp.
