Airspan ASWipLL AS3010 Hardware Installation Manual

Wireless ip-based local loop system
Hide thumbs Also See for ASWipLL AS3010:
Table of Contents

Advertisement

Quick Links

Download this manual
ASWipLL / / / / AS3010 Systems
ASWipLL
ASWipLL
ASWipLL
Wireless IP-Based Local Loop System
Hardware
Installation Guide
Leading the World in Wireless DSL
AS3010 Systems
AS3010 Systems
AS3010 Systems
Release 5.2

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ASWipLL AS3010 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Airspan ASWipLL AS3010

Summary of Contents for Airspan ASWipLL AS3010

  • Page 1 ASWipLL ASWipLL / / / / AS3010 Systems AS3010 Systems ASWipLL ASWipLL AS3010 Systems AS3010 Systems Wireless IP-Based Local Loop System Release 5.2 Hardware Installation Guide Leading the World in Wireless DSL...
  • Page 2 Nov-01 ASWipLL Release 2.6 (Marconi) Jun-02 ASWipLL Release 3.0A (Marconi) Feb-03 ASWipLL Release 4.0. Author: MD. Updates: Airspan template and content (connector pinouts; cable crimping, and general) May-03 ASWipLL Release 4.2F. Author: MD. Updates: graphics, deleted BSR with serial port.
  • Page 3 Information supplied by Airspan Networks INC. is believed to be accurate and reliable. However, no responsibility is assumed by Airspan Networks INC. for the use thereof nor for the rights of third parties which may be effected in any way by the use thereof.
  • Page 4 This page is intentionally left blank.

  • Page 5: Table Of Contents

    2.3.1. Handling Electrostatic Devices ..........2-5 2.3.2. Grounding ................2-6 2.3.3. Lightning Protection............. 2-6 2.4. Cabling ....................2-7 2.4.1. Considerations ..............2-7 2.4.2. Labeling................2-9 2.4.2.1. Voltage Warning ........... 2-9 2.4.2.2. High Earth Leakage Current........ 2-10 2.4.2.3. Signal Cable Designation........2-10 02030311-10 Airspan Networks Inc.
  • Page 6 Part I: Base Station Installation Basic Design of Devices ................ 6-1 6.1. BSR ....................6-1 6.1.1. Models ................6-1 6.1.2. Physical Dimensions ............6-2 6.1.3. Ports..................6-2 6.2. BSDU ....................6-3 6.2.1. Physical Dimensions ............6-3 6.2.2. Ports..................6-4 Airspan Networks Inc. 02030311-10...
  • Page 7 8.1.5. Connecting BSDU to PC for SNMP Management....8-11 8.2. BSR Connected to SDA..............8-14 Serial Cabling..................9-1 9.1. Serial Cabling BSR to PC ..............9-2 9.2. Serial Cabling BSDU to PC..............9-4 9.3. Serial Cabling BSPS to BSDU ............9-6 02030311-10 Airspan Networks Inc.
  • Page 8 12.2.2.1. SDA-4S............. 12-4 12.2.2.2. SDA-4H............. 12-6 12.2.2.3. SDA-1 ............... 12-7 12.2.2.4. SDA-1/DC ............12-7 12.2.2.5. SDA-1 Type II ........... 12-8 12.2.3. LED Indicators..............12-8 12.2.3.1. SDA-4S............. 12-8 12.2.3.2. SDA-4H............12-11 12.2.3.3. SDA-1, SDA-1/DC, SDA-1 Type II....12-12 viii Airspan Networks Inc. 02030311-10...
  • Page 9 18.2. SPR Connected to AC Power ............18-5 18.2.1. SDA-4S, SDA-4H and SDA-1 Models......18-6 18.2.2. SDA-1 Type II..............18-8 18.2.2.1. Changing SDA-1 Type II Plug Prongs ....18-8 18.2.2.2. Plugging SDA-1 Type II into Wall Outlet..18-10 02030311-10 Airspan Networks Inc.
  • Page 10 Power Cabling..................25-1 25.1. Connecting the Power Adapters ............ 25-3 25.2. AC Power Supply................25-4 25.3. DC Power Supply ................25-6 25.3.1. Housing the Power Connectors ........25-6 25.3.2. Connecting DC Power to IDR .......... 25-7 Airspan Networks Inc. 02030311-10...
  • Page 11 RSS Led Plug Cabling for SPR with DB9 Port ........D-1 RJ-45 to DB15 Adapter for IDU/ODU Connectivity ....... E-1 Extending IDU/ODU Cable Length............F-1 Evaluating Link Quality ................. G-1 Installing SDA-E1 for TDMoP ..............H-1 Installing a Lightning Protector .............. I-1 Declaration of FCC Conformity.............. J-1 02030311-10 Airspan Networks Inc.
  • Page 12 C o n t e n t s H a r d w a r e I n s t a l l a t i o n G u i d e This page is intentionally left blank. Airspan Networks Inc. 02030311-10...

  • Page 13: About This Guide

    For a system description and detailed information on software configuration, refer to the following documentation: ASWipLL System Description: provides an overview of the entire ASWipLL system. WipConfig User's Guide: Airspan recommends that you refer to this guide for performing serial initial configuration. 02030311-10 Airspan Networks Inc.

  • Page 14: Basic Design

    H a r d w a r e I n s t a l l a t i o n G u i d e WipManage User's Guide: Airspan recommends that you refer to this guide as a reference for using the WipManage program for configuring and managing the ASWipLL devices.

  • Page 15: Connecting Third-Party External Antenna

    Appendix A, "Glossary": glossary of terms used in this guide Appendix B, "Installing the BSPS": describes the procedures for installing an optional third-party Base Station Power System. Appendix C, "Cable Crimping": describes the crimping procedure for 15-Pin D-type, N-type, and GPS connectors. 02030311-10 Airspan Networks Inc.
  • Page 16 Appendix J, "FCC Declaration of Conformity ": provides a declaration of FCC conformity for the ASWipLL radios. Conventions This guide uses the following bulletin conventions: Warning: Provides information that can prevent and avoid bodily or mechanical harm. Note: Provides useful information. Airspan Networks Inc. 02030311-10...
  • Page 17 H a r d w a r e I n s t a l l a t i o n G u i d e O ve r v i e w Customer Service For service and support for your ASWipLL system, contact your regional Airspan representative or Airspan's Technical Assistance Center (TAC) at: Web site (Support Request Form): http://www.airspan.com/Ultra/ContactForm/airspansupportform.asp...
  • Page 18 E r r o r ! S t y l e n o t d e f i n e d . H a r d w a r e I n s t a l l a t i o n G u i d e This page is intentionally left blank xviii Airspan Networks Inc. 02030311-10...

  • Page 19: Overview

    Overview Overview Overview Airspan's ASWipLL system provides a low-cost, high-performance point-to- multipoint frequency hopping- and IP-based broadband wireless access (BWA) solution. ASWipLL provides wireless local-loop (last-mile) connectivity designed to deliver high-speed data, Voice over IP (VoIP), and multimedia services to residential, SOHO, and small to medium enterprises.
  • Page 20 ASWipLL provides embedded security features such as IP (packet) filtering based on addresses, protocols, and applications. The ASWipLL system supports SNMP-based management, allowing remote fault, configuration, performance, and security management of the entire ASWipLL system. This includes remote simultaneous software upgrade of multiple ASWipLL devices. Airspan Networks Inc. 02030311-10...

  • Page 21: System Architecture

    Base Station Power Supply (BSPS) -- provides –48 VDC power supply and power redundancy The implementation of these devices depends on the desired network (e.g. point-to- point radio link), number of outdoor radios, and power source at the Base Station, and required synchronization method (e.g. by GPS). 02030311-10 Airspan Networks Inc.

  • Page 22: Base Station Radio (Bsr)

    VDC power supply and for synchronizing BSDUs, BSRs, and Base Stations (when a GPS is implemented). The BSDU is installed indoors in a standard 19-inch cabinet and connects to the BSRs by standard CAT 5 cables. Each BSDU can service up to six BSRs. In Airspan Networks Inc. 02030311-10...

  • Page 23: Global Positioning System (Gps) - Optional

    DC-uninterruptible power supply (UPS) with a battery connected to it. The size of the battery determines the backup and charging time. Since the system is current limited, the maximum battery size is based on this limit. Remote power management and monitoring (by ASWipLL's WipManage program). 02030311-10 Airspan Networks Inc.

  • Page 24: Subscriber Site

    The ASWipLL radios interface with the subscriber's Ethernet network either through a hub or switch, or directly, depending on the ASWipLL radio implemented. Note: For VoIP support, Airspan can provide a third-party residential gateway (RGW). The RGW typically provides two POTS ports for telephony, a 10BaseT LAN port for subscriber PC/network, and a 10BaseT port for connecting to the SDA or IDR (depending on subscriber site configuration).

  • Page 25: Subscriber Data Adapter (Sda)

    SDA-4H: hub providing four 10BaseT interfaces with the subscriber's computers and/or networks. One of the 10BaseT ports provides crossover cabling for interfacing with another hub or LAN switch. Alternatively, it may be connected to another PC via a crossed Ethernet cable. 02030311-10 Airspan Networks Inc.
  • Page 26 VLAN IDs tagged by SDA-4S/VLtag to four VLAN IDs configured through ASWipLL's network management system (WipManage). The tag conversion is performed by SPR before sending the traffic to the air (i.e. to the BSR) and vice versa when coming from the air. Airspan Networks Inc. 02030311-10...
  • Page 27 SDA-4S/1H3L models (i.e. VLAN for each port and a high-priority port for VoIP). SDA-E1: integrated TDMoP fE1/Ethernet converter with standard SDA features. The figure below displays a typical subscriber site setup implementing an SPR and SDA. Figure 1-2: Subscriber site with SPR and SDA units (optional RGW) 02030311-10 Airspan Networks Inc.

  • Page 28: Indoor Radio Only

    The IDR can be used for data and voice transmissions. In the case of voice, the IDR uses a third-party RGW to interface with the subscriber's IP phone. Figure 1-3 displays a typical setup for data and voice at a subscriber site implementing the IDR. 1-10 Airspan Networks Inc. 02030311-10...
  • Page 29 H a r d w a r e I n s t a l l a t i o n G u i d e O ve r v i e w Figure 1-3: Subscriber site with IDR (optional third-party external antenna and RGW) 02030311-10 Airspan Networks Inc. 1-11...
  • Page 30 O ve r v i e w H a r d w a r e I n s t a l l a t i o n G u i d e This page is intentionally left blank. 1-12 Airspan Networks Inc. 02030311-10...

  • Page 31: Safety Guidelines

    2.1. General Warning: The user and the installer should be aware that changes and modifications not expressly approved by Airspan Networks could void the user's authority to operate the equipment. Warning: Never install equipment that is damaged. Warning: Only qualified personnel should be allowed to install, replace, and service the ASWipLL equipment.

  • Page 32: Aswipll Radios And Third-Party External Antennas

    Failure to do so may void Airspan's ASWipLL product warranty and may expose the end user or the service provider to legal and financial liabilities. Airspan and its resellers or distributors are not liable for injury, damage or violation of regulations associated with the installation of outdoor units or antennas.
  • Page 33 EIRP is defined by the following formula: Max. Power Output + Antenna Gain - Cable Loss ≤ 36 dBm (EIRP) Airspan does not supply cables for connecting external antennas. It is the responsibility of the installer to provide the cable and ensure the cable characteristics (i.e.
  • Page 34 Warning: Inherent risks exist in operating equipment in unlicensed bands (e.g. 900 MHz). Airspan recommends that you do not purchase or deploy any equipment that operates in unlicensed bands without first analyzing the interference environment at each of your proposed deployment locations.

  • Page 35: Electrical Safety Guidelines

    Airspan recommends the following guidelines to be adopted to minimize the risk of component failure due to electrostatic discharge to the device: ASWipLL devices are provided typically in see-through anti-static bags.

  • Page 36: Grounding

    This capability is provided by the fact that all ASWipLL devices are designed with transient voltage suppressor (TVS) components that maintain potential differences. Airspan Networks Inc. 02030311-10...

  • Page 37: Cabling

    S a f e t y G u i d e l i n e s However, in geographical areas that have above normal lightning activity, Airspan can supply an optional DC surge protector adapter (see Part II, Chapter 18, "Power Cabling").
  • Page 38 Silicone sealant should be used to plug any holes on both internal and external wall surfaces once cables are in place. Cables not housed in conduits must be placed in a manner to avoid a trip hazard. (Avoid trailing wires across passageways.) Airspan Networks Inc. 02030311-10...

  • Page 39: Labeling

    On the rear of the main power rack adjacent to the terminal block Attached to BSPS AC mains power plug or lead Attached to the customer mains power socket or distribution rail On the BSPS power circuit connection at the fuse board 02030311-10 Airspan Networks Inc.

  • Page 40: High Earth Leakage Current

    ASWipLL data cables. Care should be taken to ensure that the cable identification information is clearly visible. Fit the label 100 mm from the cable end. Wrap the label ensuring good adhesion to cable and itself. 2-10 Airspan Networks Inc. 02030311-10...

  • Page 41: Package Contents

    Package Contents Package Contents Warning: Examine the ASWipLL shipping container. If you notice any damage, or missing items as listed in the Packing List, immediately notify the carrier that delivered the unit and contact an Airspan representative. 02030311-10 Airspan Networks Inc.
  • Page 42 P a c k a g e C o n t e n t s H a r d w a r e I n s t a l l a t i o n G u i d e This page is intentionally left blank. Airspan Networks Inc. 02030311-10...

  • Page 43: Required Tools

    The following tools are required for installing the ASWipLL system: Crimping tools (CAT-5 cables for 15-Pin D-type, N-type connectors, and for GPS connectors) Cable stripping tool Philips-head screwdriver Flat-blade screwdriver Torque wrench for N-type connectors 10-, 13-, and 17-mm A/F open ended spanner 02030311-10 Airspan Networks Inc.
  • Page 44 R e q u i r e d T o o l s H a r d w a r e I n s t a l l a t i o n G u i d e This page is intentionally left blank. Airspan Networks Inc. 02030311-10...

  • Page 45: Radio Site Planning

    Ensure that you have sufficient wiring conduit and cable ties to channel and protect the CAT 5 cable connecting the outdoor radio to the indoor hub/switch. Ensure required power mains outlet is available at the site. 02030311-10 Airspan Networks Inc.

  • Page 46: Minimal Radio Path Obstructions

    Objects with reflective surfaces that seem relatively far away, but yet still encroaching on Fresnel Zone, may cause these interferences. Figure 5-1: At least 60% of first Fresznel Zone should be clear Airspan Networks Inc. 02030311-10...
  • Page 47 Typically, at least 60% clearance of the first Fresnel Zone is considered as LOS. Therefore, in the above example, a height of at least 12 meters (i.e. 60% of 20 meters) above ground level is sufficient for LOS. 02030311-10 Airspan Networks Inc.

  • Page 48: Multipath Fading

    5.4. Spectrum Analysis for Locating Clear Frequencies Before setting up your wireless link between Base Station and subscribers, Airspan recommends (especially in unlicensed bands), analyzing the RF spectrum at the Base Station to select only clear frequency channels (i.e. without interferences) for building a frequency table for wireless communication between Base Station and subscriber.

  • Page 49: Adjacent Base Station Radios

    In general, you will be looking for frequencies with signal strengths of –85 dBm or greater. For using Airspan's spectrum analyzer tool, refer to the WipConfig User's Guide. For evaluating link quality using the Spectrum Analyzer, see Appendix G, "Evaluating Link Quality".
  • Page 50 + 20logf + 20logf) + Rx gain – cable loss Therefore, RSS = 27 + 11 – 116 + 15 = -63 dBi Conclusion: calculated link budget received signal strength (-63) is above the device's receive sensitivity threshold (-75); thus a communication link should succeed. Airspan Networks Inc. 02030311-10...
  • Page 51 - 30 dBm: 900 MHz, 925 MHz, 1.5 GHz, 1.9 GHz (for SPR) - 27 dBm: 2.3, 2.4, 2.5 (MMDS), 2.8, 3.x, and 5.8 GHz For maximum transmit power according to FCC standards, see Appendix I, "Declaration of FCC Conformity". 02030311-10 Airspan Networks Inc.
  • Page 52 Cable loss (negative value) Operating range Note: The maximum operating range depends on the antenna configuration and FSK level. The range can be increased to a maximum of 38 km by implementing a third-party external antenna. Airspan Networks Inc. 02030311-10...

  • Page 53: Radio Antenna Alignment

    SPR/IDR. For short links you can expect an RSSI of –60 dBm or better. For longer links, an RSSI of –75 dBm is acceptable. Any RSSI of less than –80 dBm may be too weak for the radios to reliably communicate. 02030311-10 Airspan Networks Inc.

  • Page 54: Antenna Polarization Usage

    H a r d w a r e I n s t a l l a t i o n G u i d e Airspan offers various tools for measuring RSS (check with your Airspan representative regarding cost and supply): SPR: RSS LED adapter (see Part II, Chapter 17, "Antenna Alignment using RSS...

  • Page 55: Considerations When Using External Antennas

    5) Antenna must be DC grounded. 5.9.1. Cable Loss Airspan's ASWipLL radios provide transmit power compensation for power attenuation caused by cable loss (in cable connecting to external antenna). Cable loss is the loss of radio transmit (Tx) power as heat, and directly proportional to cable length and quality, and operating frequency.
  • Page 56 H a r d w a r e I n s t a l l a t i o n G u i d e Table 5-1: Examples of cable loss per cable length Note: Airspan does not supply external antenna cables. It is the responsibility of the installer to provide the cable and ensure the cable characteristics (e.g.

  • Page 57: Omni-Directional Antennas

    Therefore, it is recommended that the operator, during installation, compare the performance between horizontal and vertical polarization of external antennas, and implement the polarization providing the best performance. Some third-party antennas that can be optionally supplied by Airspan for the 900 MHz band support both horizontal and vertical polarization. 02030311-10 Airspan Networks Inc.

  • Page 58: Operating In Band-C For Fcc Markets

    714 MHz). To overcome this interference, a 1-meter vertical separation (in addition to the general 1-meter horizontal separation) is recommended between the BSRs operating in the upper frequency and the BSRs operating in the lower frequency. 5-14 Airspan Networks Inc. 02030311-10...

  • Page 59: Dual Antenna Receive Diversity

    Notes: 1) The BSR with two antennas transmits using only one of the antennas (factory selected). 2) Antennas must be orientated to cover the same area/cell (i.e. subscriber sites), from only a slightly different location. 02030311-10 Airspan Networks Inc. 5-15...

  • Page 61: Part I: Base Station Installation

    Base Station, and includes the following chapters: Chapter 6, “Basic Design of Devices” Chapter 7, “Mounting the Devices” Chapter 8, “Network Cabling” Chapter 9, “Serial Cabling” Chapter 10, “Connecting Third-Party External Antennas” Chapter 11, “Power Cabling” 02030311-10 Airspan Networks Inc.
  • Page 62 R a d i o S i t e P l a n n i n g H a r d w a r e I n s t a l l a t i o n G u i d e This page is intentionally left blank. Airspan Networks Inc. 02030311-10...

  • Page 63: Basic Design Of Devices

    The BSR is available in the following basic physical designs: BSR with a built-in (integral), internal antenna BSR with an N-type port for connecting an optional third-party external antenna BSR with two N-type ports for connecting two optional third-party external antennas for dual antenna diversity 02030311-10 Airspan Networks Inc.

  • Page 64: Physical Dimensions

    317 mm (12.48 inches) Depth 65.5 mm (2.58 inches) Weight 4.7 kg 6.1.3. Ports The BSR provides ports on its front panel, as displayed below: 9-pin D-type port 15-pin D-type port Figure 6-1: BSR front panel (built-in antenna model) Airspan Networks Inc. 02030311-10...

  • Page 65: Bsdu

    6.2.1. Physical Dimensions The BSDU's physical dimensions are described in the table below. Table 6-3: BSDU physical dimensions Parameter Value Height 43.2 mm (1.7 inches) Width 482.6 mm (19 inches) Depth 228.6 mm (9 inches) Weight 2.9 kg 02030311-10 Airspan Networks Inc.

  • Page 66: Ports

    100BaseT interface with provider's backbone (WAN), and for BSDU and BSRs management interface (if 10Base-T ports are looped) SYNC RJ-45 (two) Synchronization between BSDUs 9-pin D-type female BSDU serial interface Monitor 10Base-T RJ-45 (two) BSDU management (port #2) and management Airspan Networks Inc. 02030311-10...
  • Page 67 48 VDC Rear 15-pin D-type Global Positioning System (GPS)-based synchronization 15-pin D-type (six) DC power, Ethernet, and synchronization interfaces with BSRs Note: A 5-mm diameter-grounding lug is present on the rear panel for grounding the BSDU. 02030311-10 Airspan Networks Inc.

  • Page 68: Led Indicators

    No power is available, or the BSDU's BSR port is disabled by software, or port failure has occurred 6.2.3.2. 100Base-T LEDs The 100Base-T LED indicators provide three LEDs for each of the two 100Base-T ports. These LEDs are described in Table 6-6. Airspan Networks Inc. 02030311-10...

  • Page 69: Status Leds

    Both LEDs are off BSDU synchronization pulse lost (i.e. no synchronization) GPS antenna is connected to the Green BSDU Blinking Receiving a satellite signal via GPS HSP P (Hop Green Change state for the HSP pulse Synchronization Process Pulse) 02030311-10 Airspan Networks Inc.

  • Page 70: Gps

    The GPS provides a 12-pin male contacts for connecting a cable between it and the BSDU. Figure 6-4: GPS antenna – side view 6.4. BSPS For a detailed description of the BSPS, see Appendix B, "Installing the BSPS". Airspan Networks Inc. 02030311-10...

  • Page 71: Mounting The Devices

    Warning: The BSR device is an outdoor radio unit, and therefore, must only be mounted outside. Note: In the standard BSR kit, Airspan does not supply wall-mounting brackets. To order wall-mounting brackets, contact your Airspan representative. BSR wall mounting is identical to SPR wall mounting (see Part II, Chapter 13, "Mounting the Devices").
  • Page 72 (i.e. 711.5 and 714.5 for 1 Msps mode; 712 and 714 for 1.33 Msps mode) and the other pair operating in the upper frequencies (i.e. 741.5 and 744.5 for 1 Msps mode; 742 and 744 for 1.33 Msps mode). Airspan Networks Inc. 02030311-10...
  • Page 73 Align the mounting bracket with the BSR's mounting holes so that the mounting bracket's side with the built-in nut is aligned with the BSR's mounting holes furthest from the BSR's front panel, as shown in the figure below. 02030311-10 Airspan Networks Inc.
  • Page 74 From the external side of the mounting bracket, insert the M6-hex head screw into the pivot holes and then fasten, but not tightly. (The clamping bracket provides a built-in nut.) Airspan Networks Inc. 02030311-10...
  • Page 75 Slide an M8-flat washer and M8-spring lock washer onto each U-bolt screw side (ensure that the flat washer is adjacent to the clamping bracket). Fasten each U-bolt side with the two M8-hex nuts. b. Attach the second U-bolt as described above. 02030311-10 Airspan Networks Inc.
  • Page 76 Adjust the horizontal position of the BSR by rotating the BSR about the pole, and then tightening the nuts of the U-bolts. BSR positioning is obtained in two planes by adjustment of the mounting bracket assembly a shown in Figure 7-7. Airspan Networks Inc. 02030311-10...
  • Page 77 Note: A thread-locking compound is to be used to prevent the bolts working loose. The figure below displays the possible angles of elevation. As shown, the BSR pole- mounting bracket allows elevation between -18.5° and 26.3°. Figure 7-8: Orientating BSR in the elevation plane (side view of BSR) 02030311-10 Airspan Networks Inc.
  • Page 78 Drip loop and strain relief Cable tie Figure 7-9: Pole-mounted BSR with cable drip loop and strain relief Airspan Networks Inc. 02030311-10...

  • Page 79: Rack Mounting Bsdu

    Figure 7-10. In this way, the chassis is supported until you tighten the chassis screws. 5. Tighten the M5-mounting screws to fasten the chassis to the cabinet. 02030311-10 Airspan Networks Inc.
  • Page 80 Figure 7-11: BSDU and vertical space for cables 7.3. Mounting BSPS (Optional) The BSPS is supplied pre-mounted in a standard 19" x 11U rack, providing available space for additional equipment (i.e. BSDUs, which require 1U each). Thus, no mounting procedures are required. 7-10 Airspan Networks Inc. 02030311-10...

  • Page 81: Connecting Third-Party External Antennas

    The following lists the BSR-to-third party external antenna cable setup: Cable (third party): RF coaxial Connector (third party): N-type male The usage of N-type ports for BSR models with two N-type ports: 02030311-10 Airspan Networks Inc. 10-1...
  • Page 82 Max. Power Output + Antenna Gain + Cable Loss ≤ ≤ ≤ ≤ 36 dBm (EIRP) Note: It is recommended that the same antenna polarization (i.e. horizontal/vertical) exists at both ends of the link (i.e. Base Station and subscriber site). 10-2 Airspan Networks Inc. 02030311-10...
  • Page 83 1) For crimping RF coaxial cables to N-type connectors, see Appendix C, "Cable Crimping". 2) Ensure that the third-party antenna cable is of sufficient quality to reduce or eliminate loss when operating in the required frequency band. (Airspan does not supply cables for external antennas.). 02030311-10 Airspan Networks Inc.

  • Page 84: Connecting Gps Antenna To Bsdu

    Note: When mounting the GPS on a metal pole that is in physical contact with the ground, the GPS will not synchronize. To enable synchronization, you need to isolate the GPS from the pole using isolation material. 10-4 Airspan Networks Inc. 02030311-10...

  • Page 85: Connecting The Gps

    Warning: To avoid electrical or fire hazard, ensure that the connection to the GPS is made prior to connecting the BSDU to the power supply. Note: Airspan supplies unterminated cables for connecting the GPS to the BSDU. For an explanation on cable crimping, see Appendix C, "Cable Crimping".
  • Page 86 15-pin D-type male Pin name Cable color Lead POWER RX_DATA_1- Blue TD+ (after R5) RX_DATA_1+ Black TX_DATA_1- Yellow TX_DATA_1+ RD+ (after R3) Black RX_DATA_2- Brown RX_DATA_2+ Black Black 1PPS+ Green 1PPS- 1PPS- Black 1PPS+ (After R7) 10-6 Airspan Networks Inc. 02030311-10...
  • Page 87 GPS. 2. Connect the 15-pin D-type male connector, at the other end of the cable, to the 15-pin D-type port labeled GPS located on the rear panel of the BSDU. Figure 10-4: GPS-to-BSDU cable connections 02030311-10 Airspan Networks Inc. 10-7...
  • Page 88 (i.e. cable strain relief). 2) A loop should be left in the dressed cable for maintenance purposes and to prevent the cable weight being taken directly on the connector itself. 3) Ensure that the connector is waterproof. 10-8 Airspan Networks Inc. 02030311-10...
  • Page 89 Basic Design of Devi Basic Design of Devi Basic Design of Devices This chapter describes the basic design of the ASWipLL devices installed at a subscriber site when an SPR is implemented: RSS LED Adapter 02030311-10 Airspan Networks Inc. 12-1...

  • Page 90: Basic Design Of Devices

    400 mm (15.74 inches) The SPR's physical dimensions exclude the Width 224 mm (8.82 inches) 317 mm (12.48 inches) mounting kit. Depth 65.5 mm (2.58 inches) 65.5 mm (2.58 inches) Weight 2.5 kg 4.7 kg 12-2 Airspan Networks Inc. 02030311-10...

  • Page 91: Physical Dimensions

    The SDA is an encased device that interfaces with the SPR. 12.2.1. Physical Dimensions The SDA's physical dimensions are described in the table below. Table 12-2: SDA physical dimensions Dimension (H x W x Weight 02030311-10 Airspan Networks Inc. 12-3...

  • Page 92: Ports

    MDI/MDI-X automatic crossover, SDA-4S/VL; SDA-4S/Vltag; allowing connection of straight-through SDA-4S/1H3L; or crossover cables SDA-4S/VL/1H3L) SDA-4H 10BaseT SDA-1 10BaseT SDA-1/DC 10BaseT SDA-1 Type II 10/100BaseT 12.2.2.1. SDA-4S The SDA-4S model and ports are shown in the figure below: 12-4 Airspan Networks Inc. 02030311-10...
  • Page 93 H a r d w a r e I n s t a l l a t i o n G u i d e B a s i c D e s i g n o f D e v i c e s Power port 15-pin D-type 10/100BaseT ports Figure 12-2: Ports of SDA-4S models 02030311-10 Airspan Networks Inc. 12-5...

  • Page 94: Sda-4H

    H a r d w a r e I n s t a l l a t i o n G u i d e 12.2.2.2. SDA-4H The SDA-4H model and ports are shown in the figure below: Power port 15-pin D-type RJ-45 (J5) crossover RJ-45 (J4) RJ-45 (J3) RJ-45 (J2) Figure 12-3: Ports of SDA-4H models 12-6 Airspan Networks Inc. 02030311-10...

  • Page 95: Sda-1/Dc

    15-pin D-type port Figure 12-4: Ports of SDA-1 model 12.2.2.4. SDA-1/DC The SDA-1/DC model and ports are shown in the figure below: 15-pin D-type port DC Anderson Powerpole RJ-45 port receptacles Figure 12-5: SDA-1/DC model 02030311-10 Airspan Networks Inc. 12-7...

  • Page 96: Led Indicators

    12.2.3. LED Indicators The SDA models provide various LED indicators. These LEDs are located on the top panel of the SDA module. 12.2.3.1. SDA-4S The figure below displays the location of the SDA-4S LED indicators. 12-8 Airspan Networks Inc. 02030311-10...
  • Page 97 H a r d w a r e I n s t a l l a t i o n G u i d e B a s i c D e s i g n o f D e v i c e s Ethernet LEDs Uplink (SPR to BSR) LED Power LED Figure 12-7: SDA-4S LED indicators 02030311-10 Airspan Networks Inc. 12-9...
  • Page 98 10BaseT physical link between SDA-4H and Ethernet network Blinking 10BaseT traffic flow between SDA-4H and Ethernet network No traffic flow between SDA-4S and Ethernet network POWER Green Power received by the SDA-4S model No power received by SDA-4S model 12-10 Airspan Networks Inc. 02030311-10...

  • Page 99: Sda-4H

    The figure below displays the location of the SDA-4H LED indicators. Power LED Crossover Ethernet Uplink (SPR to BSR) LED (port 5) Ethernet straight-through LEDs (ports 2, 3, and 4) Figure 12-8: SDA-4H LED indicators 02030311-10 Airspan Networks Inc. 12-11...

  • Page 100: Sda-1, Sda-1/Dc, Sda-1 Type Ii

    The LED for the SDA-1 Type II also indicates correct port assignments for cabling. Table 12-6: LED description for SDA-1, SDA-1/DC and SDA-1 Type II models Color Status Meaning Green Power received POWER No power received 12-12 Airspan Networks Inc. 02030311-10...

  • Page 101: Rss Led Adapter

    12.3.1. Physical Dimensions The following table lists the RSS LED Plug adapter dimensions: Table 12-7: RSS LED adapter dimensions Parameter Dimensions Height 123 mm (4.84 inches) Width 68 mm (2.68 inches) Depth 30 mm (1.18 inches) Weight 02030311-10 Airspan Networks Inc. 12-13...

  • Page 102: Ports

    SPR side; female port for connecting to the SDA side. 15-pin D-type male (connects to SPR side) RSSI LED 8 RSSI LED 1 Power LED 15-pin D-type female (connects to SDA side) Figure 12-9: RSS LED adapter 12-14 Airspan Networks Inc. 02030311-10...

  • Page 103: Leds

    -93 ≤ RSS ≤ -90 LED blinking: 1 RSS ≤ -94 Note: A smaller RSS number indicates a stronger signal because the RSS level is given as a negative value (e.g. –66 is better than –70). 02030311-10 Airspan Networks Inc. 12-15...

  • Page 105: Mounting The Devices

    Note: The standard SPR kit includes wall-mounting brackets. For ordering pole-mounting brackets (supply and costs), please contact your Airspan representative. SPR pole mounting procedure is identical to BSR pole mounting, thus, for a detailed description on pole mounting, see Part I, Chapter 7, "Mounting Devices".
  • Page 106 A minimum of 3-meter separation is required between mounted SPRs and existing customer radio equipment when not transmitting on the same sector (see Figure 13-2). 3.0 metres Figure 13-2: SPR separation when not transmitting on the same sector 13-2 Airspan Networks Inc. 02030311-10...
  • Page 107 1. Position the mounting bracket on the mounting surface (e.g. wall), and then use a pencil to mark the position of the four mounting holes. Figure 13-4 displays the fixing dimensions. Ensure that the distance between the hole centers are 120 mm (height) and 60 mm (width). 02030311-10 Airspan Networks Inc. 13-3...
  • Page 108 3. Insert wall anchors (not supplied) into each of the drilled holes. 4. Align the mounting bracket's four holes with the wall anchors, and then insert a screw (not supplied) through the mounting bracket holes into each wall anchor, and tighten. 13-4 Airspan Networks Inc. 02030311-10...
  • Page 109 M o u n t i n g t h e D e v i c e s Note: Airspan does not provide screws for attaching the mounting bracket to the wall. The screw size depends on the structure of the building to which the bracket is to be attached.
  • Page 110 SPR's mounting holes. Loosely fasten with the M10-hex nuts. Figure 13-6: Attaching SPR to mounting bracket 6. Adjust the horizontal positioning of the SPR, and then tighten the two M10- hex head screws with the M10 hex nuts. 13-6 Airspan Networks Inc. 02030311-10...
  • Page 111 Rotation is restricted in the horizontal plane only. The permissible rotation is shown in Figure 13-7. Figure 13-7: Horizontal rotation of the SPR (top view) Note: A third-party thread-locking compound must be applied to the M10-hex head screws to prevent the bolts working loose. 02030311-10 Airspan Networks Inc. 13-7...

  • Page 112: Mounting The Sda

    Rubber feet Figure 13-8: Rubber feet on rear panel for SDA desktop mounting Warning: To prevent a fire hazard caused by overheating, do not place the SDA on a carpeted surface where airflow is restricted. 13-8 Airspan Networks Inc. 02030311-10...

  • Page 113: Wall Mounting

    M o u n t i n g t h e D e v i c e s 13.2.2. Wall Mounting The SDA provides two mounting hooks molded into the SDA's bottom panel, as displayed below. Mounting Entrance to hook mounting hole Figure 13-9: Mounting hooks on SDA rear panel 02030311-10 Airspan Networks Inc. 13-9...
  • Page 114 3) The cable must be dressed tidily and not be taught or pose a trip hazard when connected. 4) The maximum cable run between SDA and SPR is 100 meters. However, this can be extended to up to 300 meters (see Appendix F, "Extending IDU/ODU Cable Length"). 13-10 Airspan Networks Inc. 02030311-10...

  • Page 115: Network Cabling

    Cable: straight-through 10BaseT Ethernet UTP 4 Pair CAT-5e 24 AWG outdoor type (100 meters) Connectors: SPR side: 15-pin D-type male (only 6 pins are used) SDA side: 15-pin D-type male (only 6 pins are used) for all SDAs except SDA-1 Type II (RJ-45 port) 02030311-10 Airspan Networks Inc. 14-1...
  • Page 116 For SDA except SDA-1 Type II: connect the 15-pin D-type male connector to the SDA's 15-pin D-type port (see Figure 14-1) For SDA-1 Type II: connect the RJ-45 connector to the SDA's RJ-45 port labeled RADIO (see Figure 14-2) 14-2 Airspan Networks Inc. 02030311-10...
  • Page 117 H a r d w a r e I n s t a l l a t i o n G u i d e N e t w o r k C a b l i n g Figure 14-1: SPR-to-SDA (except SDA-1 Type II) cable connections 02030311-10 Airspan Networks Inc. 14-3...
  • Page 118 Warning: When the SDA-1 Type II is implemented at the Base Station (i.e. with the BSR), an RJ-45 adapter must be used (supplied) to connect the BSR to the SDA-1 Type II (see Chapter 8, Section 8.2, "BSR Connected to SDA"). 14-4 Airspan Networks Inc. 02030311-10...

  • Page 119: Connecting Sda To Subscriber's Ethernet Network

    2) Airspan supplies unterminated CAT cables. For a detailed description on crimping cables, see Appendix C, "Cable Crimping". 3) Airspan offers an optional RJ45-to-DB15 adapter for attaching to the SDA's 15-pin D-type port. This allows you to crimp an RJ45 connector to one end of the CAT cable.
  • Page 120 CAT-5 cables can be connected to these ports. Connector Pinouts: SDA-4S, SDA-4H (ports J2, J3, J4), SDA-1, SDA-1/DC, and SDA-1 Type II models: 8-pin RJ-45 straight-through cable Function Note: Pins not mentioned are not used. 14-6 Airspan Networks Inc. 02030311-10...
  • Page 121 1. Connect the 8-pin RJ-45 male connector, at the one end of the Ethernet cable, to the SDA's RJ-45 Ethernet port. 2. Connect the 8-pin RJ-45 male connector, at the other end of the Ethernet cable, to the subscriber's PC (or device). 02030311-10 Airspan Networks Inc. 14-7...
  • Page 122 N e t w o r k C a b l i n g H a r d w a r e I n s t a l l a t i o n G u i d e Figure 14-3: SDA-to-PC/network cable connections (e.g. SDA-1 model) 14-8 Airspan Networks Inc. 02030311-10...
  • Page 123 H a r d w a r e I n s t a l l a t i o n G u i d e N e t w o r k C a b l i n g Figure 14-4: SDA-1 Type II to PC/network cable connections 02030311-10 Airspan Networks Inc. 14-9...

  • Page 124: Connecting To Hub

    1. Connect the RJ-45 male, at one end of the cable, to any one of the SDA-4S's RJ-45 ports (see Figure 14-5), or to the SDA-4H's left-most RJ-45 port - J5 (see Figure 14-6). 2. Connect the RJ-45 male, at the other end of the cable, to a hub. 14-10 Airspan Networks Inc. 02030311-10...
  • Page 125 H a r d w a r e I n s t a l l a t i o n G u i d e N e t w o r k C a b l i n g Figure 14-5: SDA-4S crossover/straight-through cable connections to hub 02030311-10 Airspan Networks Inc. 14-11...
  • Page 126 N e t w o r k C a b l i n g H a r d w a r e I n s t a l l a t i o n G u i d e Figure 14-6: SDA-4H crossover cable connections to hub 14-12 Airspan Networks Inc. 02030311-10...

  • Page 127: Connecting To Voip Network

    RJ-45 port on the front panel of the SDA-4S/1H3L and SDA- 4S/VL/1H3L. 2. Connect the RJ-45 male connector, at the other end of the cable, to the VoIP network, for example, to a Residential Gateway. 02030311-10 Airspan Networks Inc. 14-13...
  • Page 128 N e t w o r k C a b l i n g H a r d w a r e I n s t a l l a t i o n G u i d e Figure 14-7: Connecting SDA-4S/1H3L and SDA-4S/VL/1H3L to VoIP network 14-14 Airspan Networks Inc. 02030311-10...
  • Page 129 H a r d w a r e I n s t a l l a t i o n G u i d e N e t w o r k C a b l i n g This page is intentionally left blank. 02030311-10 Airspan Networks Inc. 14-15...

  • Page 131: Serial Cabling

    D-type port to both the PC and the SDA. Notes: 1) SPR initial configuration is performed using Airspan's WipConfig program (refer to the ASWipLL WipConfig User's Guide). 2) For customers with previous SPR models providing a 9-pin D-type port, the serial cabling is identical to BSR serial cabling (see Part I, Chapter 9, "Serial...
  • Page 132 Straight-through Y-cable 15-pin D-type Function Function 15-pin D-type male male +48 VDC +48 VDC 48 RTN 48 RTN Ethernet Tx+ Ethernet Tx- Ethernet Rx+ Ethernet Rx- 9-pin D-type Function Function female RS232 Rx RS232 Tx 15-2 Airspan Networks Inc. 02030311-10...
  • Page 133 3. Connect the 9-pin D-type female (RS232) connector, at the other end of the Y-cable, to the PC's serial port. Figure 15-2: SPR serial cable connections using a Y-cable Notes: For SPR serial configuration, the SPR remains connected to the SDA. 02030311-10 Airspan Networks Inc. 15-3...
  • Page 134 S e r i a l C a b l i n g H a r d w a r e I n s t a l l a t i o n G u i d e This page is intentionally left blank. 15-4 Airspan Networks Inc. 02030311-10...
  • Page 135 2) It is recommended that the same antenna polarization (i.e. horizontal/ vertical) exists at both ends of the link (i.e. Base Station and subscriber site). 3) For crimping RF coaxial cables, see Appendix C, "Cable Crimping". 02030311-10 Airspan Networks Inc. 16-1...
  • Page 136 To connect the SPR to a third-party external antenna: Connect an N-type male connector of the third-party antenna to the N-type port located on the SPR's front panel, as displayed below. Figure 16-1: SPR model with N-type connector for attaching an external antenna 16-2 Airspan Networks Inc. 02030311-10...
  • Page 137 Conformity Conformity We, Airspan Networks Inc., declare that the ASWipLL radio devices listed in the table below comply with FCC Rules. We further declare that only the antenna installation configurations shown in the table below are used in specific installations.
  • Page 138 Hybrid 4 Mbps 3 Mbps / 28.8 dBm According to 2.5 GHz Digital (MMDS) 4 Mbps FCC approved antenna gain 3 Mbps 17.6 dBm 36 dBm 5.8 GHz Hybrid 4 Mbps 21 dBm 36 dBm Hybrid Airspan Networks Inc. 02030311-10...
  • Page 139 H a r d w a r e I n s t a l l a t i o n G u i d e D e c l a r a t i o n o f F C C C o n f o r m i t y This page is intentionally left blank. 02030311-10 Airspan Networks Inc.
