Airspan ASWipLL Commissioning Manual page 422

M a n a g i n g F r e q u e n c y T a b l e s
Figure 20-7: Multi SPRs Frequency Tables dialog box
2. Select the all the SPRs (with which you want to communicate with the BSR), by
clicking the Select All button.
3. Select the SPR (i.e. 10.0.0.20) for which you defined the NVRAM Frequency
table (in Section 20.2.3, "Task 2: Add Frequency Table for SPR"). Note that in
our example, the Hashed Table value of SPR 10.0.0.20 is 159710956, and of
SPR 10.0.0.36 is 0.
The selected SPR's NVRAM Frequency table appears in the Frequency Tables
list, located in the upper pane.
4. Click Apply. The Multi-Apply Confirmation box appears, as displayed below.
20-16 Airspan Networks Inc.
C o m m i s s i o n i n g M a n u a l
Frequency
table (ID 32)
of selected
SPR
Selected SPR
(i.e. 10.0.0.20)
with unique
Hashed Table
value
01040311-07
