ASWipLL and
AS3010 Systems
Wireless IP-Based Local Loop System
Release 4.6
Commissioning Manual
Leading the World in Wireless DSL

Advertisement

Table of Contents

Troubleshooting

loading
Need help?

Need help?

Do you have a question about the ASWipLL and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Airspan ASWipLL

Summary of Contents for Airspan ASWipLL

  • Page 1 ASWipLL and AS3010 Systems Wireless IP-Based Local Loop System Release 4.6 Commissioning Manual Leading the World in Wireless DSL...
  • Page 2 The ASWipLL product bears the CE marking. This CE marking demonstrates ASWipLL's full compliance with applicable European Union (EU) directives: The ASWipLL product bears the Underwriters Laboratories (UL) marking, demonstrating full compliance with UL's safety requirements: ASWipLL products also bear the Federal Communications Commission (FCC) marking, demonstrating compliance with FCC Part 15 regulations.
  • Page 3 Information supplied by Airspan Networks Inc. is believed to be accurate and reliable. However, no responsibility is assumed by Airspan Networks Inc. for the use thereof nor for the rights of third parties which may be effected in any way by the use thereof.
  • Page 4 This page is intentionally left blank.

  • Page 5: Table Of Contents

    1.4.4. Traffic Engineering in Multi-Tenant Application ....1-18 1.4.4.1. VLAN Tagging............1-18 1.4.4.2. Without VLAN Tagging ........1-20 1.4.5. Repeater Solution............... 1-21 Installing ASWipLL Management Software ........... 2-1 2.1. System Requirements ................. 2-2 2.2. Installing WipConfig................2-3 2.3. Installing WipManage ................ 2-11 01040311-07 Airspan Networks Inc.
  • Page 6 Establishing BSR-SPR Link in Bridge Mode ......... 5-1 5.1. Summary of Tasks ................5-2 5.2. Task 1: Configure BSR for Transparent Bridging........ 5-4 5.3. Task 2: Configure SPR for Transparent Bridging........ 5-9 5.4. Task 3: Start WipManage..............5-14 Airspan Networks Inc. 01040311-07...
  • Page 7 7.2. Summary of Tasks ................7-4 7.3. Task 1: Configure BSR for IP Routing..........7-5 7.4. Task 2: Configure SPR for IP Routing..........7-10 7.5. Task 3: Add an SPR................7-15 7.6. Task 4: Test the BSR-SPR Network Link.......... 7-23 01040311-07 Airspan Networks Inc.
  • Page 8 8.4.3. Task 2: Add an AutoConnect SPR ........8-46 8.4.4. Task 3: Redefine AutoConnect for Currently Redirected SPR................... 8-48 8.4.5. Task 4: Reset the SPR Device ........... 8-52 8.5. Color-Coding of AutoConnect SPR Icons ......... 8-56 8.6. AutoConnect Trap Messages............8-58 viii Airspan Networks Inc. 01040311-07...
  • Page 9 11.2.2. Task 1: Enable Asymmetric Bandwidth Policy ....11-4 11.2.3. Task 2: Define Downlink and Uplink CIR and MIR Values 11-6 Defining Static Routes ................12-1 12.1. Overview ..................12-1 12.2. Adding Static Routes to a BSR ............12-2 12.2.1. Summary of Tasks............12-3 01040311-07 Airspan Networks Inc.
  • Page 10 15.2.3. Task 2: Verify BSR's Air Subnet Address......15-9 15.2.4. Task 3: Define SPR's Air Subnet using WipConfig..15-10 15.2.5. Task 4: Verify SPR's Air Subnet Address....... 15-14 15.2.6. Task 5: Return PC's IP Settings for Connectivity with BSR ................. 15-16 Airspan Networks Inc. 01040311-07...
  • Page 11 15.2.7. Task 6: Add BSR and SPR in WipManage..... 15-16 15.2.8. Task 7: View Air Subnets in WipManage ....... 15-16 Defining ASWipLL as a DHCP Relay Agent ......... 16-1 16.1. Overview ..................16-1 16.2. Defining ASWipLL as a DHCP Relay Agent........16-2 Defining PPPoE ..................
  • Page 12 21.2.6. Task 5: Reset the BSDUs..........21-12 21.2.7. Task 6: Verify BSDU Synchronization ......21-14 21.2.8. Task 7: Enable BSR Synchronization......21-16 21.2.9. Task 8: Reset BSRs ............21-18 21.2.10. Task 9: Verify BSRs Synchronization......21-20 Airspan Networks Inc. 01040311-07...
  • Page 13 23.5.3. Task 2: Reset the BSR ........... 23-16 23.5.4. Task 3: Verify BSR in IP Filtering Mode ......23-17 23.5.5. Task 4: Add BSR IP Filtering Rules........ 23-18 23.5.6. Task 5: Enable IP Filtering for SPR ........ 23-22 01040311-07 Airspan Networks Inc. xiii...
  • Page 14 24.3.2. Task 1: Define QoS for IP Addresses of SIP Server and Softswitch..............24-11 24.3.3. Task 2: Configure DiffServ Tagging for RGW ....24-14 24.3.4. Task 3: Map DiffServ Tags to ASWipLL Prioritization Scheme................24-15 Managing Traps..................25-1 25.1. Overview ..................25-1 25.2.
  • Page 15 C o m m i s s i o n i n g M a n u a l C o n t e n t s 26.4. Task 2: Start WipLL DB Upgrade ..........26-10 26.5. Task 3: Upgrade the ASWipLL Database ........26-11 26.6. Task 4: Compact the ASWipLL Database........26-15 Upgrading ASWipLL Devices..............27-1 27.1.
  • Page 16 C o n t e n t s C o m m i s s i o n i n g M a n u a l This page is intentionally left blank. Airspan Networks Inc. 01040311-07...

  • Page 17: About This Manual

    AutoConnect, and frequency tables Upgrade procedures Troubleshooting Targeted Audience This manual is intended for the person who is responsible for commissioning the ASWipLL system. This person should be familiar with working with Airspan’s ASWipLL WipConfig and WipManage programs. 01040311-07 Airspan Networks Inc. xvii...
  • Page 18 ASWipLL Hardware Installation Guide: The manual describes serial configurations of ASWipLL devices. Therefore, Airspan recommends that you refer to the ASWipLL Hardware Installation Manual for detailed description of connecting the cables for serial (or IP network) connections. Organization of this Manual This manual is organized into the following chapters: Chapter 1, "Introduction": provides an overview of the ASWipLL system.
  • Page 19 ASWipLL radios interfacing with the wireless communication path. Chapter 16, "Defining ASWipLL as a DHCP Relay Agent": provides a step- by-step instruction for defining ASWipLL as a DHCP relay agent. 01040311-07...
  • Page 20 BSR/PPR antenna for antenna diversity. Chapter 19, "Configuring Radio Transmit Power": provides step-by-step instructions for configuring transmit power levels for the ASWipLL devices. Chapter 20, "Managing Frequency Tables": provides step-by-step instructions for defining frequency tables used in wireless communicate between the BSR/PPR and SPR.
  • Page 21 Customer Service For service and support for your ASWipLL system, contact your regional Airspan representative, or Airspan’s Technical Assistance Center (TAC) at: E-mail: WipLL.tech_support@Airspan.com Boca Raton Call Center: (+1) 561 893 8679 UK Call Center: (+44) 1895 467 467 01040311-07 Airspan Networks Inc.
  • Page 22 Ab o u t t h i s M a n u a l C o m m i s s i o n i n g M a n u a l This page is intentionally left blank. xxii Airspan Networks Inc. 01040311-07...

  • Page 23: Introduction

    ASWipLL operates in the licensed band (700 MHz, 925 MHz, 1.5 GHz, 2.3 GHz, 2.5 GHz Multichannel Multipoint Distribution Services - MMDS, 2.8 GHz, and 3.x GHz - ranging from 3.3 to 3.8 GHz), and unlicensed band (900 MHz, 2.4 GHz ISM,...

  • Page 24: Main Features

    ASWipLL supports VLANs and VPNs based on IEEE 802.1Q/p. ASWipLL supports IP routing and PPPoE bridging, as well as transparent bridging. ASWipLL provides embedded security features such as IP (packet) filtering based on addresses, protocols, and applications. The ASWipLL system provides SNMP-based management, allowing remote and local management, configuration, and monitoring of ASWipLL equipment.

  • Page 25: Customer Benefits

    Scalability and modular Base Station architecture, allowing customers to add equipment when needed, thereby, allowing low initial cost entry and pay-as-you- grow strategy. Unlike competitors, the ASWipLL Base Station is not a chassis- based design, and, therefore, provides flexibility and space-saving at Base Stations.
  • Page 26 C o m m i s s i o n i n g M a n u a l Supports transparent bridging for easy implementation of IP addressing schemes. ASWipLL’s IP routing provides efficiency and eliminates the need for additional hardware.

  • Page 27: System Architecture

    Base Station and the subscriber’s network. Network management tools: consists mainly of Windows- and SNMP-based programs, providing fault, configuration, performance, security management. Figure 1-1 displays a block diagram of the main areas of the ASWipLL system. Figure 1-1: ASWipLL System Architecture 01040311-07 Airspan Networks Inc.

  • Page 28: Base Station Site

    C o m m i s s i o n i n g M a n u a l 1.3.1. Base Station Site The ASWipLL Base Station interfaces between the subscriber sites and the service provider's backbone, providing subscribers with high-speed data, Internet, and VoIP services.
  • Page 29 SPR. Base Station Power Supply (BSPS): The BSPS is an optional unit that provides the ASWipLL Base Station with –48 VDC power supply and power redundancy. The BSPS is installed at the Base Station site in a standard 19-inch cabinet. The BSPS connects to, and services a maximum of four BSDUs.
  • Page 30 C o m m i s s i o n i n g M a n u a l Figure 1-2 shows a fully populated ASWipLL Base Station at maximum configuration (i.e. 24 BSRs, 4 BSDUs, 1 BSPS, and 1 GPS).

  • Page 31: Subscriber Site

    Base Station. The radio transceiver provides the subscriber with high- speed data access, Internet access, and VoIP at up to 4 Mbps. The ASWipLL radios interface to the subscriber's Ethernet network either through a hub or switch, or directly, depending on the ASWipLL radio model.
  • Page 32 100 Mbps, the port connection will transmit packets at 100 Mbps. If the device to which the port is connected is running at 10 Mbps, the port connection will transmit packets at 10 Mbps. 1-10 Airspan Networks Inc. 01040311-07...
  • Page 33 The VLAN IDs are fixed (since SDA-4S/VLtag is not user configurable). SPR converts the four VLAN IDs tagged by SDA- 4S/VLtag to four VLAN IDs configured through ASWipLL’s network management system (WipManage). The tag conversion is performed by SPR before sending the traffic to the air and vice versa when coming from the air.
  • Page 34 C o m m i s s i o n i n g M a n u a l Figure 1-3 displays a typical setup at a subscriber site implementing an ASWipLL outdoor radio unit (SPR) and an ASWipLL indoor Ethernet switch /hub (SDA).

  • Page 35: Indoor Radio Unit Only

    I n t r o d u c t i o n 1.3.2.2. Indoor Radio Unit Only The indoor radio unit configuration consists of the ASWipLL Indoor Data Radio (IDR). The IDR combines the functionality of the SPR and SDA, functioning as a transceiver and a hub.

  • Page 36: Network Management Tools

    Trap commands. WipConfig™: Windows-based program, providing serial initial configuration (e.g. IP addresses) of the ASWipLL devices, used typically at the factory, or during installation. WipConfig also provides received signal strength indication (RSSI) for subscriber radios allowing accurate device orientation and positioning for optimal reception with Base Station.

  • Page 37: Applications

    PSTN modem, a full channel is occupied for as long as the session lasts. In contrast, ASWipLL subscribers are limited only by their own configuration, with a maximum of 4 Mbps—70 times faster than the fastest PSTN modem. In addition, subscribers do not necessarily consume more bandwidth from the provider, since bandwidth is used only when a data packet is transmitted.

  • Page 38: High Speed Internet Access

    C o m m i s s i o n i n g M a n u a l 1.4.2. High Speed Internet Access One of the advantages of ASWipLL is the fact that subscribers are "always on" Internet. This means that there is no dialing process and no need for the hassle involved with dialup access.

  • Page 39: Voice Over Ip

    I n t r o d u c t i o n 1.4.3. Voice over IP The ASWipLL system enables providers the flexibility of migration from a data- only network to an integrated Voice-over-IP and data network. The ASWipLL voice solution provides interoperability with any IP-to-PSTN network gateway.

  • Page 40: Traffic Engineering In Multi-Tenant Application

    ASWipLL's SDA-4S/VLtag assigns a different VLAN ID (fixed) to traffic from each of its four ports. ASWipLL’s SPR converts these four VLAN IDs, tagged by SDA-4S/VLtag, to four VLAN IDs configured by ASWipLL’s NMS (WipManage). SPR performs this tag conversion before sending traffic to the air, and when receiving traffic from the air.
  • Page 41 I n t r o d u c t i o n Figure 1-7 shows an example of how MTU works in an ATM environment. Figure 1-7: Multi-tenant solution (i.e., multiple VLANs) in an ATM environment 01040311-07 Airspan Networks Inc. 1-19...

  • Page 42: Without Vlan Tagging

    C o m m i s s i o n i n g M a n u a l 1.4.4.2. Without VLAN Tagging The ASWipLL system also provides regular VLAN support (without VLAN tagging), providing privacy between tenants in MTU applications. The ASWipLL...

  • Page 43: Repeater Solution

    I n t r o d u c t i o n 1.4.5. Repeater Solution ASWipLL units can be used to provide repeater functionality. This is implemented in scenarios where the BSR needs to be “extended” to remote subscriber sites that are blocked by obstacles such as trees, hills, and other typical line-of-sight obstructions or that the BSR-SPR (or BSR-IDR) transmission is out-of-range.
  • Page 44 C o m m i s s i o n i n g M a n u a l In Figure 1-9, BSR A is part of an ASWipLL Base Station connected to the service provider’s backbone. BSR A serves multiple SPRs, marked as SPR Ai. Two SPRs—...

  • Page 45: Installing Aswipll Management Software

    Installing ASWipLL Management Software This chapter describes the procedures for installing software for configuring and managing the ASWipLL system. This chapter includes the following sections: System Requirements Installing WipConfig Installing WipManage 01040311-07 Airspan Networks Inc.

  • Page 46: System Requirements

    Minimum free hard disk space 500 MB (recommended 2 GB or more) Network adapter 100 Mbps Software requirements - operating system: Microsoft™ Windows™ NT 4 work station (English only) SP3.0 or later Microsoft™ Windows™ 2000 Professional Microsoft™ Windows™ XP Professional Airspan Networks Inc. 01040311-07...

  • Page 47: Installing Wipconfig

    On the Windows taskbar, click Start, and then choose Run. Type D:\WIPCONFIG.EXE (where D is the letter of your CD-ROM drive letter). Click OK. The windows installation wizard will now take you through the following setup procedure. 01040311-07 Airspan Networks Inc.
  • Page 48 I n s t a l l i n g AS W i p L L M a n a g e m e n t S o f tw a r e C o m m i s s i o n i n g M a n u a l 5. Click Next. Airspan Networks Inc. 01040311-07...
  • Page 49 I n s t a l l i n g AS W i p L L M a n a g e m e n t S o f t w a r e To accept the default destination folder for installing WipConfig, click Next. 01040311-07 Airspan Networks Inc.
  • Page 50 I n s t a l l i n g AS W i p L L M a n a g e m e n t S o f tw a r e C o m m i s s i o n i n g M a n u a l Leave “Airspan” as the Program Manager group, and then click Next. Airspan Networks Inc.
  • Page 51 I n s t a l l i n g AS W i p L L M a n a g e m e n t S o f t w a r e Enter your customer key number, if relevant, and then click Next. 01040311-07 Airspan Networks Inc.
  • Page 52 I n s t a l l i n g AS W i p L L M a n a g e m e n t S o f tw a r e C o m m i s s i o n i n g M a n u a l 9. Click Next to begin the installation. Airspan Networks Inc. 01040311-07...
  • Page 53 I n s t a l l i n g AS W i p L L M a n a g e m e n t S o f t w a r e When WipConfig is successfully installed, the following appears: 01040311-07 Airspan Networks Inc.
  • Page 54 C o m m i s s i o n i n g M a n u a l 10. Click Finish to complete the installation. The WipConfig shortcut icon is automatically created and placed on your desktop. 2-10 Airspan Networks Inc. 01040311-07...

  • Page 55: Installing Wipmanage

    On the Window’s taskbar, click Start, and then choose Run. Browse the WipManage CD that is in your CD-ROM drive, and then double- click the “wipmng.exe” file. The installation wizard will now take you through the following setup procedure. 01040311-07 Airspan Networks Inc. 2-11...
  • Page 56 I n s t a l l i n g AS W i p L L M a n a g e m e n t S o f tw a r e C o m m i s s i o n i n g M a n u a l 4. Click Next to begin the installation. 2-12 Airspan Networks Inc. 01040311-07...
  • Page 57 I n s t a l l i n g AS W i p L L M a n a g e m e n t S o f t w a r e 5. Click Next to agree to the terms of the license agreement and continue with the setup. 01040311-07 Airspan Networks Inc. 2-13...
  • Page 58 I n s t a l l i n g AS W i p L L M a n a g e m e n t S o f tw a r e C o m m i s s i o n i n g M a n u a l 6. Click Next to install WipManage into the directory C:\WipMng. 2-14 Airspan Networks Inc. 01040311-07...
  • Page 59 I n s t a l l i n g AS W i p L L M a n a g e m e n t S o f t w a r e 7. Click Next to add WipManage to the “Airspan” Program Manager Group.
  • Page 60 If Microsoft Access is not installed on your workstation, select the Add MS- Access ODBC Drivers check box. Select the Add Data Source check box if you are performing a first-time installation of WipManage, and then click Next. 2-16 Airspan Networks Inc. 01040311-07...
  • Page 61 I n s t a l l i n g AS W i p L L M a n a g e m e n t S o f t w a r e 9. Enter the Customer Key to continue the installation, alternatively, leave the Customer Key field empty, and click Next to continue. 01040311-07 Airspan Networks Inc. 2-17...
  • Page 62 I n s t a l l i n g AS W i p L L M a n a g e m e n t S o f tw a r e C o m m i s s i o n i n g M a n u a l 10. Click Next to begin installing WipManage. 2-18 Airspan Networks Inc. 01040311-07...
  • Page 63 If you selected the Add Data Source check box in Step 8, the ODBC Microsoft Access Setup dialog box appears, as displayed below. In the ODBC Microsoft Access Setup dialog box, accept the settings, and then click OK. The WipManage database WiplldB.mdb file is created in the directory C:\WipMng\WiplldB.mdb. 01040311-07 Airspan Networks Inc. 2-19...
  • Page 64 C o m m i s s i o n i n g M a n u a l A progress bar indicates the status of the WipManage installation process, as displayed below. When WipManage installation has completed, the Installation Complete dialog box appears, as displayed below. 2-20 Airspan Networks Inc. 01040311-07...
  • Page 65 Note: If your network has a firewall, to enable WipManage to manage the devices, you need to "open" the ports concerned with SNMP traffic. For example, if WipManage is located inside the firewall and the ASWipLL devices are located outside the firewall, you need to open the outbound UDP port 161 (for SNMP Get and Set) and the inbound UDP port 161 (for receiving SNMP traps).
  • Page 66 I n s t a l l i n g AS W i p L L M a n a g e m e n t S o f tw a r e C o m m i s s i o n i n g M a n u a l This page is intentionally left blank. 2-22 Airspan Networks Inc. 01040311-07...

  • Page 67: Initial Configuration

    Initial Configuration This chapter describes the procedures for initial configuration of the ASWipLL devices using WipConfig. This chapter includes the following sections: Overview Initial Serial Configuration Summary of Tasks Task 1: Start WipConfig Task 2: Initialize BSDU Task 3: Initialize BSR...

  • Page 68: Overview

    C o m m i s s i o n i n g M a n u a l 3.1. Overview Before you can manage the ASWipLL devices (BSR, SPR, and BSDU) using the ASWipLL network management system (i.e. WipManage), you need to define certain initial network, management, and radio frequency (RF) parameters.
  • Page 69 Air subnet address According RFC 1918 (i.e. ranging from 192.168.0.0) Mode (router/bridge) Router Note: For a detailed description of connecting serial cables between the PC running WipConfig and the ASWipLL device, refer to the ASWipLL Hardware Installation Guide. 01040311-07 Airspan Networks Inc.

  • Page 70: Initial Serial Configuration

    3.2. Initial Serial Configuration The following subsections describe the tasks for performing initial configuration on the ASWipLL devices through a serial communication mode using WipConfig. For clarity, the procedures described are based on the configuration displayed in the figure below: Figure 3-1: Configuration setup example (IP routing mode) Airspan Networks Inc.

  • Page 71: Summary Of Tasks

    I n i t i a l C o n f i g u r a t i o n 3.2.1. Summary of Tasks The flowchart in Figure 3-2 displays the tasks for performing initial configuration of your ASWipLL devices. Figure 3-2: Flowchart for performing initial ASWipLL device configuration 01040311-07 Airspan Networks Inc.

  • Page 72: Task 1: Start Wipconfig

    Initial configuration is performed using WipConfig. For a detailed explanation on installing WipConfig, see Chapter 2, "Installing ASWipLL Management Software". To start WipConfig: From the Windows Start menu, point to Programs, point to Airspan, and then click WipConfig. -Or- On your desktop, double-click the WipConfig shortcut icon.
  • Page 73 I n i t i a l C o n f i g u r a t i o n 4. Click OK. WipConfig starts and displays the WipConfig window showing the SPR Configuration pane, as displayed in the following figure: Figure 3-4: WipConfig window 01040311-07 Airspan Networks Inc.

  • Page 74: Task 2: Initialize Bsdu

    Ensure the BSDU is connected through serial cabling to the PC running WipConfig. In the Communication group, select the Serial option. Click the Connect button. WipConfig connects to the BSDU device, displaying the BSDU Configuration pane: Airspan Networks Inc. 01040311-07...
  • Page 75 C o m m i s s i o n i n g M a n u a l I n i t i a l C o n f i g u r a t i o n Figure 3-5: WipConfig connected to BSDU (BSDU Configuration pane) 01040311-07 Airspan Networks Inc.
  • Page 76 In the Network Configuration group, enter the following fields: Eth IP Address: BSDU’s IP address (e.g. 10.0.0.5) Eth Subnet Mask: BSDU’s subnet mask address (e.g. 255.255.255.240) Default Gateway: BSDU’s default gateway’s IP address, if relevant 3-10 Airspan Networks Inc. 01040311-07...
  • Page 77 Notes: The BSR Power Control group contains six BSR check boxes, each corresponding to the BSDU's rear panel BSR ports for connecting to the SPRs. In the example configuration, all the ports are connected to BSRs. 01040311-07 Airspan Networks Inc. 3-11...

  • Page 78: Task 3: Initialize Bsr

    The following procedure describes initial configuration of the BSR. To perform BSR initial configuration: Ensure the BSR is connected through serial cabling to the PC running WipConfig. In the Communication group, select the Serial option. Click the Connect button. 3-12 Airspan Networks Inc. 01040311-07...
  • Page 79 I n i t i a l C o n f i g u r a t i o n WipConfig connects to the BSR device, and displays the BSR Configuration pane: Figure 3-9: WipConfig connected to BSR (BSR Configuration pane) 01040311-07 Airspan Networks Inc. 3-13...
  • Page 80 WipConfig applies the default settings to the BSR. In the Network Configuration group, enter the following fields: Eth IP Address: BSR’s IP address (e.g. 10.0.0.10) Eth Subnet Mask: BSR’s subnet address (e.g. 255.255.255.240) Default Gateway: BSR’s default gateway’s IP address if relevant 3-14 Airspan Networks Inc. 01040311-07...
  • Page 81 2) To ensure that each BSR has a unique Air MAC address, ensure that the two left-most significant bytes are different between BSRs, e.g. 1000 and 2000. In this way, the ASWipLL system can support 256 different BSRs in the same sector (or area).

  • Page 82: Task 4: Initialize Spr

    The following procedure describes SPR initial configuration. To perform SPR initial configuration: Ensure the SPR is connected through serial cabling to the PC running WipConfig. In the Communication group, select the Serial option. Click the Connect button. 3-16 Airspan Networks Inc. 01040311-07...
  • Page 83 I n i t i a l C o n f i g u r a t i o n WipConfig connects to the SPR device, and displays the SPR Configuration pane: Figure 3-13: WipConfig connected to SPR (SPR Configuration pane) 01040311-07 Airspan Networks Inc. 3-17...
  • Page 84 WipConfig applies default settings to the SPR. In the Network Configuration group, enter the following fields: Eth IP Address: SPR’s IP address (e.g. 10.0.0.20) Eth Subnet Mask: SPR’s subnet address (e.g. 255.255.255.240) Default Gateway: SPR’s default gateway’s IP address (if relevant) 3-18 Airspan Networks Inc. 01040311-07...
  • Page 85 BSR Air MAC Address: BSR’s Air MAC address to which the SPR is associated (valid ranges is between 0x0000 through 0xFFFF), e.g. 0x1200. Note: For the Air MAC address, Airspan recommends using only the most significant bytes (MSB), i.e. the two left-most bytes, and not the least significant bytes (LSB), i.e.

  • Page 86: Establishing A Network Connection

    C o m m i s s i o n i n g M a n u a l 3.3. Establishing a Network Connection After you have configured the ASWipLL devices with basic network parameters such as IP addresses through a serial communication mode, you can connect WipConfig to these devices through an IP network connection.
  • Page 87 SPR via the SDA (that connects to the SPR), using the SDA’s Ethernet port. 2) For detailed description on connecting the cables between the PC running WipConfig and the ASWipLL device for IP network connections, refer to the ASWipLL Hardware Installation Guide. 01040311-07 Airspan Networks Inc.

  • Page 88: Summary Of Tasks

    3.3.1. Summary of Tasks To establish an IP network connection between your PC running WipConfig and the ASWipLL device, you need to perform the following steps (see also Figure 3-17): Define PC’s IP address, subnet, and default gateway Connect WipConfig to the ASWipLL device...
  • Page 89 Ports 1 & 2 are looped and your PC has the correct hardware (e.g. Intel 8255x- based PCI Ethernet Adapter 10/100BaseT). 2. On your desktop, right-click My Network Places , and then from the shortcut menu, choose Properties, as displayed below. Figure 3-18: Choosing Properties from My Network Places icon 01040311-07 Airspan Networks Inc. 3-23...
  • Page 90 C o m m i s s i o n i n g M a n u a l The Network and Dial-up Connections folder appears, as displayed below: Figure 3-19: Network and Dial-up Connections folder 3. Right-click the desired connection, and then from the shortcut menu, choose Properties. 3-24 Airspan Networks Inc. 01040311-07...
  • Page 91 I n i t i a l C o n f i g u r a t i o n The Local Area Connection Properties dialog box appears, as displayed below: Figure 3-20: Local Area Connection Properties dialog box 4. In the Components list, select Internet Protocol (TCP/IP), and then click Properties. 01040311-07 Airspan Networks Inc. 3-25...
  • Page 92 BSR/BSDU (i.e. 255.255.255.240) so that the PC is on the same subnet as the BSR/BSDU) Default Gateway: PC’s default gateway. This must be the BSR (i.e. IP address 10.0.0.10), or if a router exists behind the BSR, then the router’s IP address 3-26 Airspan Networks Inc. 01040311-07...
  • Page 93 Figure 3-22: Verifying IP settings using the ipconfig command As displayed in Figure 3-22, the PC’s IP settings connections have been successfully applied: IP Address: 10.0.0.2 Subnet Mask: 255.255.255.240 Default Gateway: 10.0.0.10 (i.e. BSR’s IP address) 01040311-07 Airspan Networks Inc. 3-27...

  • Page 94: Task 2: Connect Wipconfig To The Device

    Once you have configured the PC’s IP address, you can connect WipConfig to the ASWipLL devices through an IP network communication mode. To connect WipConfig to the ASWipLL device through an IP connection: Start WipConfig. From the Tools menu, choose Select Communication Protocol.
  • Page 95 I n i t i a l C o n f i g u r a t i o n Network option SNMP remote Set Community selected agent’s IP address rights Figure 3-24: Entering IP network parameters 01040311-07 Airspan Networks Inc. 3-29...
  • Page 96 WipConfig retransmits requests is according to the value defined in the Number of Retransmits field. Number of Retransmits: number of times WipConfig retransmits requests to the ASWipLL device after the timeout value is reached with no response from the ASWipLL device. Click OK.
  • Page 97 C o m m i s s i o n i n g M a n u a l I n i t i a l C o n f i g u r a t i o n WipConfig connects to the ASWipLL device (e.g. SPR) through the IP network communication mode, as displayed below: Figure 3-26: WipConfig connected to device (e.g.
  • Page 98 I n i t i a l C o n f i g u r a t i o n C o m m i s s i o n i n g M a n u a l This page is intentionally left blank. 3-32 Airspan Networks Inc. 01040311-07...

  • Page 99: Establishing Bsr-Spr Link In Router Mode

    Note: In this chapter, BSR procedures are also applicable for PPR devices and SPR procedures are also applicable for IDR devices. In other words, this chapter is also relevant for establishing a BSR-IDR link and a PPR-SPR/IDR link in an IP routing mode. 01040311-07 Airspan Networks Inc.

  • Page 100: Summary Of Tasks

    C o m m i s s i o n i n g M a n u a l 4.1. Summary of Tasks The flowchart in Figure 4-1 displays a summary of tasks for establishing a BSR- SPR link in an IP routing mode. Figure 4-1: Flowchart for establishing BSR-SPR IP routing link Airspan Networks Inc. 01040311-07...
  • Page 101 Figure 4-2: Configuration example for establishing BSR-SPR link in IP router mode Note: The BSR and SPRs must be on different networks from each other. In addition, SPRs must be on different networks (i.e. subnets) from one another. 01040311-07 Airspan Networks Inc.

  • Page 102: Task 1: Configure Bsr For Ip Routing

    Note: It is recommended to configure the BSR through a serial connection. To configure BSR for IP routing (WipConfig): Connect the PC running WipConfig to the BSR. Start WipConfig. In the Communication group, select Serial. On the toolbar, click the Connect button. Airspan Networks Inc. 01040311-07...
  • Page 103 E s t a b l i s h i n g B S R - S P R L i n k i n R o u t e r M o d e WipConfig connects to the BSR (i.e. IP address 10.0.0.10). Mode field Figure 4-3: WipConfig connected to BSR 01040311-07 Airspan Networks Inc.
  • Page 104 Router; If the BSR is defined for transparent bridging, then the Mode field displays Bridge. In the Eth IP Address field, enter the BSR’s IP address (e.g. 10.0.0.10). In the Eth Subnet Mask field, enter the BSR’s subnet mask address (e.g. 255.255.255.240). Airspan Networks Inc. 01040311-07...
  • Page 105 Reset button to reset the BSR. A Warning message box appears, requesting you to confirm device reset. Figure 4-6: Warning message box for resetting device 12. Click Yes to reset the device with default settings. 01040311-07 Airspan Networks Inc.
  • Page 106 C o m m i s s i o n i n g M a n u a l Ensure that the Mode field displays Router (i.e. BSR in IP routing mode), as displayed below. BSR in router mode Figure 4-7: BSR configured in IP router mode Airspan Networks Inc. 01040311-07...

  • Page 107: Task 2: Configure Spr For Ip Routing

    Note: It is recommended to configure the SPRs through a serial connection. To configure SPR for IP routing (WipConfig): Connect the PC running WipConfig to the SPR device. Start WipConfig. In the Communication group, select Serial. On the toolbar, click the Connect button. 01040311-07 Airspan Networks Inc.
  • Page 108 C o m m i s s i o n i n g M a n u a l 5. WipConfig connects to the SPR (i.e. 10.0.0.20). Mode field Figure 4-8: WipConfig displaying the SPR Configuration pane 4-10 Airspan Networks Inc. 01040311-07...
  • Page 109 Router; If the SPR’s ROM is defined for transparent bridging, then the Mode field displays Bridge. In the Eth IP Address field, enter the SPR’s IP address (e.g. 10.0.0.20). In the Eth Subnet Mask field, enter the SPR’s subnet mask address (e.g. 255.255.255.240). 01040311-07 Airspan Networks Inc. 4-11...
  • Page 110 Air MAC address to which the SPR is associated, e.g. 0x1200. Valid ranges are between 0x0000 through 0xFFFF. Note: For the Air MAC address, Airspan recommends using only the most significant bytes (MSB), i.e. the two left-most bytes, and not the least significant bytes (LSB), i.e.

  • Page 111: Task 3: Start Wipmanage

    4.4. Task 3: Start WipManage Once you have configured the BSR and SPR for IP routing using WipConfig, you need to define the following ASWipLL elements using WipManage, in order to establish the BSR-SPR link: BS Group (Base Station group)

  • Page 112: Task 4: Add A Bs Group

    Add BS Group. The BS Group Add dialog box appears, as displayed below. Figure 4-13: Adding a BS Group 2. In the Group Name field, enter a name for the BS Group, e.g. "Manhattan_1". 4-14 Airspan Networks Inc. 01040311-07...

  • Page 113: Task 5: Add A Base Station

    In the Database Tree, click the "Manahattan_1" branch, to which you want to add the BS. 2. In the BSs Map view (i.e. right pane), right-click an empty area, and then from the shortcut menu, choose Add BS. 01040311-07 Airspan Networks Inc. 4-15...
  • Page 114 The BS Add dialog box appears, as displayed below. Figure 4-15: Adding a BS In the BS Name field, enter a name for the BS, e.g. "Times Square". Click OK. Added BS Figure 4-16: BS "Times Square" added to BS Group "Manahattan_1" 4-16 Airspan Networks Inc. 01040311-07...

  • Page 115: Task 6: Add A Bsdu

    The BSDU-Add dialog box appears, as displayed below. Figure 4-17: Adding a BSDU In the Manage IP field, enter the BSDU’s IP address, e.g. 10.0.0.5. In the Get Community and Set Community fields, enter the SNMP community rights. 01040311-07 Airspan Networks Inc. 4-17...
  • Page 116 4). The index number that appears by default when you open BSDU Add dialog box, is the index number of the BSDU box in which you right-clicked. Click OK. Added BSDU Figure 4-18: BSDU (10.0.0.5) added to BS "Times Square" 4-18 Airspan Networks Inc. 01040311-07...

  • Page 117: Task 7: Add A Bsr

    In the Manage IP field, enter the BSR’s IP address, e.g. 10.0.0.10. In the Get Community and Set Community fields, enter the BSR's SNMP community rights. To define advanced identifying parameters, select the Advanced check box. The Advanced fields appear, as displayed in Figure 4-20. 01040311-07 Airspan Networks Inc. 4-19...
  • Page 118 Index in BSDU: Up to six BSRs can be added to a BSDU. The index number (1 through 6) represents a unique BSR number within the BSDU. By default, the displayed index number is that which corresponds to the BSR box in which you right-clicked. Click OK. 4-20 Airspan Networks Inc. 01040311-07...
  • Page 119 Added BSR Figure 4-21: BSR (10.0.0.10) added to BS "Times Square" To manage the BSR, double-click the BSR icon. BSR in router mode Figure 4-22: BSR Zoom window displaying BSR (10.0.0.10) in IP Router mode 01040311-07 Airspan Networks Inc. 4-21...

  • Page 120: Task 8: Add An Spr

    1. Double-click the BSR icon. The BSR Zoom window appears. 2. Right-click SPR index #2 icon, and then from the shortcut menu, choose Add, as shown below. Figure 4-23: Choosing the Add command from the shortcut menu 4-22 Airspan Networks Inc. 01040311-07...
  • Page 121 Figure 4-24: Permitted SPRs Add dialog box In the IP Address field, enter the SPR’s IP address (e.g. 10.0.0.20). To add a static route from the BSR to the SPR, click Route. The Static Routing Table per SPR dialog box appears. 01040311-07 Airspan Networks Inc. 4-23...
  • Page 122 C o m m i s s i o n i n g M a n u a l Figure 4-25: Static Routing Table per SPR dialog box 5. Click Add. The following dialog box appears: Figure 4-26: Static Route Table Add dialog box 4-24 Airspan Networks Inc. 01040311-07...
  • Page 123 The Calculate Subnet dialog box appears, as shown below. Figure 4-27: Calculate Subnet dialog box Once you have calculated the subnet mask, click the OK button, and the Static Route Table – Add dialog box reappears. 01040311-07 Airspan Networks Inc. 4-25...
  • Page 124 In the Permitted SPRs Add dialog box, click OK. After a few seconds, the SPR index #2 icon appears green, as shown in Figure 4-29, indicating that an air and network link exists with the SPR. You can now manage the SPR. 4-26 Airspan Networks Inc. 01040311-07...
  • Page 125 Figure 4-29: Added SPR (index 2) displayed in BSR Zoom window Double-click the SPR icon to open the SPR Zoom window, displayed below. SPR in router mode Figure 4-30: SPR Zoom window of SPR (10.0.0.20) 01040311-07 Airspan Networks Inc. 4-27...

  • Page 126: Task 9: Test The Bsr-Spr Network Link

    From the PC/Laptop (e.g. IP address 10.0.0.2) behind the BSR, open an MS- DOS prompt and use the command to ping the SPR (IP address ping – t 10.0.0.20), as shown below: Figure 4-31: Pinging SPR using the MS-DOS ping-t command 4-28 Airspan Networks Inc. 01040311-07...

  • Page 127: Color-Coding Of Spr Icons

    (rectangle) Figure 4-32: Areas of the SPR icon For configuration to succeed, the SPR icon’s circle and rectangle surrounding the index number must both be green (i.e. an air and network link must exist). 01040311-07 Airspan Networks Inc. 4-29...
  • Page 128 PC running WipManage Grey with Defined SPR, but currently disabled "X" Grey with Grey Previously defined SPR that has been deleted from check mark the BSR. This SPR index number is not deleted from the ASWipLL database. 4-30 Airspan Networks Inc. 01040311-07...

  • Page 129: Establishing Bsr-Spr Link In Bridge Mode

    Note: In this chapter, BSR procedures are also applicable for PPR devices and SPR procedures are also applicable for IDR devices. In other words, this chapter is also relevant for establishing a BSR-IDR link and a PPR-SPR/IDR link in transparent bridging mode. 01040311-07 Airspan Networks Inc.

  • Page 130: Summary Of Tasks

    C o m m i s s i o n i n g M a n u a l 5.1. Summary of Tasks The flowchart in Figure 4-1 displays the tasks for establishing a BSR-SPR link in transparent bridging mode. Figure 5-1: Flowchart for establishing BSR-SPR link in transparent bridging mode Airspan Networks Inc. 01040311-07...
  • Page 131 E s t a b l i s h i n g B S R - S P R L i n k i n B r i d g e M o d e For the purpose of this chapter, the example configuration shown below is used. Figure 5-2: Configuration example for establishing BSR-SPR link in bridge mode 01040311-07 Airspan Networks Inc.

  • Page 132: Task 1: Configure Bsr For Transparent Bridging

    Note: It is recommended to configure the BSR through a serial connection. To configure BSR for transparent bridging (WipConfig): Connect the PC running WipConfig to the BSR. Start WipConfig. In the Communication group, select Serial. On the toolbar, click the Connect button. Airspan Networks Inc. 01040311-07...
  • Page 133 E s t a b l i s h i n g B S R - S P R L i n k i n B r i d g e M o d e WipConfig connects to the BSR (i.e. IP address 10.0.0.10). Changed to router mode Figure 5-3: WipConfig connected to BSR (in router mode) 01040311-07 Airspan Networks Inc.
  • Page 134 Router; If the BSR is defined for transparent bridging, then the Mode field displays Bridge. In the Eth IP Address field, enter the BSR’s IP address (e.g. 10.0.0.10). In the Eth Subnet Mask field, enter the BSR’s subnet mask address (e.g. 255.255.255.240). Airspan Networks Inc. 01040311-07...
  • Page 135 Reset button to reset the BSR. A Warning message box appears, requesting you to confirm device reset. Figure 5-6: Warning message box for resetting device 12. Click Yes to reset the device with default settings. 01040311-07 Airspan Networks Inc.
  • Page 136 C o m m i s s i o n i n g M a n u a l Ensure that the Mode field displays Bridge (i.e. BSR in transparent bridge mode), as displayed below. Bridge mode Figure 5-7: BSR configured for transparent bridging Airspan Networks Inc. 01040311-07...

  • Page 137: Task 2: Configure Spr For Transparent Bridging

    Note: It is recommended to configure the SPR through a serial connection. To configure SPR for transparent bridging (WipConfig): Connect the PC running WipConfig to the SPR device. Start WipConfig. In the Communication group, select Serial. On the toolbar, click the Connect button. 01040311-07 Airspan Networks Inc.
  • Page 138 C o m m i s s i o n i n g M a n u a l WipConfig connects to the SPR (i.e. IP address 10.0.0.20). SPR in router mode Figure 5-8: WipConfig connected to SPR (in router mode) 5-10 Airspan Networks Inc. 01040311-07...
  • Page 139 Router; If the SPR is defined for transparent bridging, then the Mode field displays Bridge. In the Eth IP Address field, change the SPR’s IP address (e.g. 10.0.0.11). In the Eth Subnet Mask field, enter the SPR’s subnet mask address (e.g. 255.255.255.240). 01040311-07 Airspan Networks Inc. 5-11...
  • Page 140 Air MAC address to which the SPR is associated, e.g. 0x1200. Valid ranges are from 0x0000 through 0xFFFF. Note: For the Air MAC address, Airspan recommends using only the most significant bytes (MSB), i.e. the two left-most bytes, and not the least significant bytes (LSB), i.e.
  • Page 141 E s t a b l i s h i n g B S R - S P R L i n k i n B r i d g e M o d e Ensure that the Mode field displays Bridge (i.e. SPR in transparent bridge mode), as displayed below. SPR changed to bridge mode Figure 5-12: SPR configured for transparent bridging 01040311-07 Airspan Networks Inc. 5-13...

  • Page 142: Task 3: Start Wipmanage

    BSR-SPR link: BS Group (Base Station group) BS (Base Station) BSDU To start WipManage: From the Windows Start menu, point to Programs, point to Airspan, and then click WipManage. Figure 5-13: WipManage Main window 5-14 Airspan Networks Inc.

  • Page 143: Task 4: Add A Bs Group

    , and then from the shortcut menu, choose Add BS Group. The BS Group Add dialog box appears, as displayed below. Figure 5-14: Adding BS Group 2. In the Group Name field, enter a name for the BS Group, e.g. "Manhattan_1". 01040311-07 Airspan Networks Inc. 5-15...

  • Page 144: Task 5: Add A Base Station

    The next step is to add a BS to the BS Group. In our example, the BS is named "Times Square". To add a BS: In the Database Tree, click the "Manahattan_1" branch, to which you want to add the BS. 5-16 Airspan Networks Inc. 01040311-07...
  • Page 145 Figure 5-16: Adding a BS In the BS Name field, enter a name for the BS, e.g. "Times Square". Click OK. Added BS Figure 5-17: BS "Times Square" added to BS Group "Manahattan_1" 01040311-07 Airspan Networks Inc. 5-17...

  • Page 146: Task 6: Add A Bsdu

    The BSDU-Add dialog box appears, as displayed below. Figure 5-18: Adding a BSDU In the Manage IP field, enter the BSDU’s IP address, e.g. 10.0.0.5. In the Get Community and Set Community fields, enter the SNMP community rights. 5-18 Airspan Networks Inc. 01040311-07...
  • Page 147 4). The index number that appears by default when you open BSDU Add dialog box, is the index number of the BSDU box in which you right-clicked. Click OK. Added BSDU Figure 5-19: BSDU (10.0.0.5) added to BS "Times Square" 01040311-07 Airspan Networks Inc. 5-19...

  • Page 148: Task 7: Add A Bsr

    In the Manage IP field, enter the BSR’s IP address, e.g. 10.0.0.10. In the Get Community and Set Community fields, enter the SNMP community rights. To define advanced identifying parameters, select the Advanced check box. The Advanced fields appear, as displayed in Figure 4-20. 5-20 Airspan Networks Inc. 01040311-07...
  • Page 149 Index in BSDU: Up to six BSRs can be added to a BSDU. The index number (1 through 6) represents a unique BSR number within the BSDU. By default, the displayed index number is that which corresponds to the BSR box in which you right-clicked. Click OK. 01040311-07 Airspan Networks Inc. 5-21...
  • Page 150 Figure 5-22: BSR (10.0.0.10) added to BS "Times Square" To manage the BSR, double-click the BSR icon. The BSR Zoom window appears: BSR in bridge mode Figure 5-23: BSR Zoom window displaying BSR (10.0.0.10) in bridge mode 5-22 Airspan Networks Inc. 01040311-07...

  • Page 151: Task 8: Add An Spr

    The BSR Zoom window appears, as displayed below. 2. Right-click the SPR index #2 icon, and then from the shortcut menu, choose Add, as shown below. Figure 5-24: Choosing the Add command from the shortcut menu 01040311-07 Airspan Networks Inc. 5-23...
  • Page 152 The Permitted SPRs-Add dialog box appears. Figure 5-25: Permitted SPRs Add dialog box In the IP Address field, enter the SPR’s IP address (e.g. 10.0.0.11). Click OK. Note: No static routes are added in transparent bridge mode. 5-24 Airspan Networks Inc. 01040311-07...
  • Page 153 Figure 5-26: Added SPR (index 2) displayed in BSR Zoom window Double-click the SPR icon to open the SPR Zoom window, as displayed below. SPR in bridge mode Figure 5-27: SPR Zoom window of SPR (10.0.0.11) in bridge mode 01040311-07 Airspan Networks Inc. 5-25...

  • Page 154: Task 9: Test The Bsr-Spr Network Link

    SPR (IP address ping – t 10.0.0.11), as shown below: Figure 5-28: Pinging the ASWipLL device using the MS-DOS ping-t command Note: To ping devices in the transparent bridging mode, all devices (including hosts) must be in the same subnet.

  • Page 155: Advanced Tasks

    5.11.1. Task 1: View MAC Addresses When a ping is performed between the SPR and BSR, and between the SPR’s hosts and BSR, the BSR enters the SPR’s and the SPR host’s MAC addresses in WipManage's BSR’s MAC Table. 01040311-07 Airspan Networks Inc. 5-27...
  • Page 156 In the BSR Zoom window, from the Configuration menu, point to Bridge, and then choose MAC Table. Figure 5-29: MAC Table dialog box displaying the MAC addresses MAC addresses that begin with 00a00a indicate ASWipLL devices (SPR or BSR). All other MAC addresses represent hosts connected to the SPRs. 5-28 Airspan Networks Inc.

  • Page 157: Task 2: Define Mac Address Aging Time

    The MAC Table dialog box appears, as displayed in Figure 5-29. In the Aging Time field, enter the time (in minutes) after which you want an unused MAC address to be automatically deleted from the MAC Table. Click Set, and then click Close. 01040311-07 Airspan Networks Inc. 5-29...

  • Page 158: Task 3: Enable Forwarding Of Various Packets

    Configuration. The Bridge Configuration dialog box appears, as displayed below. Figure 5-30: Bridge Configuration dialog box 2. To enable the sending of unknown destination packets from the subscriber’s LAN, select the Forward Unknown Destination Packets check box. 5-30 Airspan Networks Inc. 01040311-07...
  • Page 159 PPPoE: if selected, no Point-to-Point Protocol over Ethernet packets are transmitted if selected, no NetBIOS over IP: Network Basic Input Output System messages are transmitted. This is usually for Microsoft for network neighborhood – peer sharing. Other: other applications and services 01040311-07 Airspan Networks Inc. 5-31...
  • Page 160 E s t a b l i s h i n g B S R - S P R L i n k i n B r i d g e M o d e C o m m i s s i o n i n g M a n u a l This page is intentionally left blank. 5-32 Airspan Networks Inc. 01040311-07...

  • Page 161: Changing Link From Router To Bridge

    Task 5: Configure SPR for Transparent Bridging Task 6: Add SPR Task 7: Test the BSR-SPR Link Note: In this chapter, BSR procedures are also applicable for PPR devices and SPR procedures are also applicable for IDR devices. 01040311-07 Airspan Networks Inc.

  • Page 162: Overview

    C o m m i s s i o n i n g M a n u a l 6.1. Overview The following figures display the configuration setup of the ASWipLL system in an IP router mode (see Figure 6-1), and then changed to a transparent bridge mode (see Figure 6-2).
  • Page 163 C o m m i s s i o n i n g M a n u a l C h a n g i n g L i n k f r o m R o u t e r t o B r i d g e Figure 6-2: ASWipLL changed to transparent bridge mode 01040311-07...

  • Page 164: Summary Of Tasks

    The flowchart in Figure 4-1 displays a summary of tasks for changing BSR-SPR network from an IP routing network to a transparent bridging network. Figure 6-3: Flowchart for changing ASWipLL from IP routing to transparent bridging Airspan Networks Inc. 01040311-07...

  • Page 165: Task 1: Install Wipmanage That Supports Transparent Bridging

    For example, if the current SPR’s software version is 2.58.0.4 (i.e. ASWipLL Release 4.1), you can download either the next version, e.g. 2.69.0.1 (i.e. ASWipLL Release 4.2A), or the one after that, e.g. 2.78.0.5 (i.e. ASWipLL Release 4.2B).

  • Page 166: Task 3: Upgrade Bsr To Support Transparent Bridging

    For example, if the current BSR’s software version is 2.58.0.4 (i.e. ASWipLL Release 4.1), you can download either the next version, e.g. 2.69.0.1 (i.e. ASWipLL Release 4.2A), or the one after that, e.g. 2.78.0.5 (i.e. ASWipLL Release 4.2B). For an explanation on the upgrading rules, see Chapter 20, "Upgrading ASWipLL Database and SW Versions".
  • Page 167 In the Communication group, select Serial. On the toolbar, click the Connect button. WipConfig connects to the BSR (i.e. IP address 10.0.0.10). BSR in router mode Figure 6-4: BSR Configuration pane (BSR in IP router mode) 01040311-07 Airspan Networks Inc.
  • Page 168 Router; If the BSR is defined for transparent bridging, then the Mode field displays Bridge. In the Eth IP Address field, enter the BSR’s IP address (e.g. 10.0.0.10). In the Eth Subnet Mask field, enter the BSR’s subnet mask address (e.g. 255.255.255.240). Airspan Networks Inc. 01040311-07...
  • Page 169 10. On the toolbar, click the Write button. the toolbar, click the Reset button to reset the BSR. A Warning message box appears, requesting you to confirm device reset. Figure 6-7: Warning message box for resetting device 01040311-07 Airspan Networks Inc.
  • Page 170 12. Click Yes to reset the device with default settings. Ensure that the Mode field displays Bridge (i.e. BSR in transparent bridge mode), as displayed below. BSR changed to bridge mode Figure 6-8: BSR changed to transparent bridge mode 6-10 Airspan Networks Inc. 01040311-07...

  • Page 171: Task 5: Configure Spr For Transparent Bridging

    To configure SPR for transparent bridging (WipConfig): Connect the PC running WipConfig to the SPR device using a serial cable connection. Start WipConfig. In the Communication group, select Serial. On the toolbar, click the Connect button. 01040311-07 Airspan Networks Inc. 6-11...
  • Page 172 C o m m i s s i o n i n g M a n u a l WipConfig connects to the SPR (i.e. IP address 10.0.0.20) and displays the SPR Configuration pane. SPR in router mode Figure 6-9: SPR Configuration pane (SPR in IP router mode) 6-12 Airspan Networks Inc. 01040311-07...
  • Page 173 In the Eth IP Address field, enter the SPR’s IP address (e.g. 10.0.0.11) so that it is in the same subnet as the BSR. In the Eth Subnet Mask field, enter the SPR’s subnet mask address (e.g. 255.255.255.240). 01040311-07 Airspan Networks Inc. 6-13...
  • Page 174 BSR Air MAC Address: BSR Air MAC address to which the SPR is associated, e.g. 0x1200. Valid ranges are from 0x0000 through 0xFFFF. Note: For the Air MAC address, Airspan recommends using only the most significant bytes (MSB), i.e. the two left-most bytes, and not the least significant bytes (LSB), i.e.
  • Page 175 C h a n g i n g L i n k f r o m R o u t e r t o B r i d g e Ensure that the Mode field displays Bridge (i.e. SPR in transparent bridge mode), as displayed below. SPR in bridge mode Figure 6-13: SPR changed to transparent bridge mode 01040311-07 Airspan Networks Inc. 6-15...

  • Page 176: Task 6: Add Spr In Wipmanage

    SPR icon contains a check mark (√) indicating that the SPR has been deleted. SPR deleted from BSR BSR in bridge mode Figure 6-14: Verifying BSR is in bridge mode In our example configuration, we need to add SPR (10.0.0.11) to SPR index #2. 6-16 Airspan Networks Inc. 01040311-07...
  • Page 177 In the BSR Zoom window, right-click the SPR index #2 icon, and then from the shortcut menu, choose Add, as shown below. Figure 6-15: Choosing the Add command from the shortcut menu The Permitted SPRs-Add dialog box appears. 01040311-07 Airspan Networks Inc. 6-17...
  • Page 178 In the IP Address field, enter the IP address of the SPR (e.g. 10.0.0.11). In the Name field, enter the name of the SPR. Note: In transparent bridging, you do not enter static routes (i.e. Route button is not used). 6-18 Airspan Networks Inc. 01040311-07...
  • Page 179 The SPR index #2 icon appears green, as shown below, indicating that a viable air and network link exists with the BSR. You can now manage the SPR. successfully linked to BSR Figure 6-17: Added SPR (index 2) displayed in BSR Zoom window 01040311-07 Airspan Networks Inc. 6-19...
  • Page 180 Figure 6-18: SPR Zoom window of SPR 10.0.0.11 in bridge mode You can verify that the SPR is in bridge mode by the "Bridge Mode" display in the SPR Zoom window, as shown above 6-20 Airspan Networks Inc. 01040311-07...

  • Page 181: Task 7: Test The Bsr-Spr Network Link

    From the PC/Laptop (IP address 10.0.0.2) behind the BSR, open an MS-DOS prompt and use the command to ping the SPR (IP address ping – t 10.0.0.11), as shown below: Figure 6-19: Pinging the ASWipLL device using the MS-DOS ping-t command 01040311-07 Airspan Networks Inc. 6-21...
  • Page 182 C h a n g i n g L i n k f r o m R o u t e r t o B r i d g e C o m m i s s i o n i n g M a n u a l This page is intentionally left blank. 6-22 Airspan Networks Inc. 01040311-07...

  • Page 183: Changing Link From Bridge To Router

    Task 2: Configure SPR for IP Routing Task 3: Add an SPR Task 4: Test the BSR-SPR Link Note: In this chapter, BSR procedures are also applicable for PPR devices and SPR procedures are also applicable for IDR devices. 01040311-07 Airspan Networks Inc.

  • Page 184: Overview

    C o m m i s s i o n i n g M a n u a l 7.1. Overview The following figures display the configuration setup of the ASWipLL system in a transparent bridge mode (see Figure 7-1), and then changed to an IP router mode (see Figure 7-2).
  • Page 185 C o m m i s s i o n i n g M a n u a l C h a n g i n g L i n k f r o m B r i d g e t o R o u t e r Figure 7-2: ASWipLL changed to IP router mode 01040311-07...

  • Page 186: Summary Of Tasks

    C o m m i s s i o n i n g M a n u a l 7.2. Summary of Tasks The flowchart in Figure 4-1 displays a summary of tasks for changing ASWipLL from a transparent bridging network to an IP routing network.

  • Page 187: Task 1: Configure Bsr For Ip Routing

    Note: It is recommended to configure the BSR through a serial connection. To configure BSR for IP routing (using WipConfig): Connect the PC running WipConfig to the BSR. Start WipConfig. In the Communication group, select Serial. 01040311-07 Airspan Networks Inc.
  • Page 188 WipConfig connects to the BSR (i.e. IP address 10.0.0.10). Bridge mode Figure 7-4: BSR in transparent bridge mode Apply factory default settings by performing the following: On the toolbar, click the Set Factory Default button. A Warning message box appears. Airspan Networks Inc. 01040311-07...
  • Page 189 Valid ranges are from 0x0000 through 0xFFFF. In the Frequency Table ID field, enter frequency table ID used by the BSR (valid range = 0 through 63), e.g. 1. On the toolbar, click the Write button. 01040311-07 Airspan Networks Inc.
  • Page 190 C o m m i s s i o n i n g M a n u a l the toolbar, click the Reset button to reset the BSR. A Warning message box appears, requesting you to confirm device reset. Figure 7-7: Warning message box for resetting device Airspan Networks Inc. 01040311-07...
  • Page 191 C h a n g i n g L i n k f r o m B r i d g e t o R o u t e r 13. Click Yes to reset the device with default settings. Ensure that the Mode field displays Router (i.e. BSR in IP routing mode). Changed to router mode Figure 7-8: BSR changed to IP router mode 01040311-07 Airspan Networks Inc.

  • Page 192: Task 2: Configure Spr For Ip Routing

    To configure SPR for IP routing (using WipConfig): Connect the PC running WipConfig to the SPR device through a serial cable connection. Start WipConfig. In the Communication group, select Serial. On the toolbar, click the Connect button. 7-10 Airspan Networks Inc. 01040311-07...
  • Page 193 C h a n g i n g L i n k f r o m B r i d g e t o R o u t e r WipConfig connects to the SPR (i.e. 10.0.0.11). SPR in bridge mode Figure 7-9: SPR in transparent bridge mode 01040311-07 Airspan Networks Inc. 7-11...
  • Page 194 Router; If the SPR’s ROM is defined for transparent bridging, then the Mode field displays Bridge. In the Eth IP Address field, change the SPR’s IP address (e.g. 10.0.0.20). In the Eth Subnet Mask field, change the SPR’s subnet mask address (e.g. 255.255.255.240). 7-12 Airspan Networks Inc. 01040311-07...
  • Page 195 BSR Air MAC Address: BSR Air MAC address to which the SPR is associated, e.g. 0x1200. Valid ranges are from 0x0000 through 0xFFFF. Note: For the Air MAC address, Airspan recommends using only the most significant bytes (MSB), i.e. the two left-most bytes, and not the least significant bytes (LSB), i.e.
  • Page 196 C o m m i s s i o n i n g M a n u a l 12. Click Yes to reset the device. Ensure that the Mode field displays Router (i.e. SPR in IP routing mode). SPR in router mode Figure 7-13: SPR changed to IP router mode 7-14 Airspan Networks Inc. 01040311-07...

  • Page 197: Task 3: Add An Spr

    BSR’s mode as "Router". In addition, the SPR icon contains a check mark (√) indicating that the SPR has been deleted. SPR deleted from BSR BSR in router mode Figure 7-14: Verifying that BSR is in IP router mode 01040311-07 Airspan Networks Inc. 7-15...
  • Page 198 In our example, we need to add SPR (10.0.0.20) to the SPR index #2 icon. To add the SPR: In the BSR Zoom window, right-click the SPR #2 icon, and then from the shortcut menu, choose Add. Figure 7-15: Choosing the Add command for adding the SPR 7-16 Airspan Networks Inc. 01040311-07...
  • Page 199 Figure 7-16: Permitted SPRs Add dialog box In the IP Address field, enter the SPR’s IP address (e.g. 10.0.0.20). To add a static route from the BSR to the SPR, click Route. The Static Routing Table per SPR dialog box appears. 01040311-07 Airspan Networks Inc. 7-17...
  • Page 200 C o m m i s s i o n i n g M a n u a l Figure 7-17: Static Routing Table per SPR dialog box 4. Click Add. The following dialog box appears: Figure 7-18: Static Route Table Add dialog box 7-18 Airspan Networks Inc. 01040311-07...
  • Page 201 The Calculate Subnet dialog box appears, as shown below. Figure 7-19: Calculate Subnet dialog box Once you have calculated the Subnet Mask, click the OK button, and the Static Route Table – Add dialog box reappears. 01040311-07 Airspan Networks Inc. 7-19...
  • Page 202 6. Click OK. The static route from the BSR to the SPR appears in the Static Routing Table, as shown below. Figure 7-20: Added SPR static route Click Close to close the Static Routing Table per SPR dialog box. In the Permitted SPRs Add dialog box, click OK. 7-20 Airspan Networks Inc. 01040311-07...
  • Page 203 After a few seconds, the SPR index #2 icon appears green, as shown below, indicating that a viable air and network link exists with the BSR. You can now manage the SPR. successfully linked to BSR Figure 7-21: Added SPR (index 2) displayed in BSR Zoom window 01040311-07 Airspan Networks Inc. 7-21...
  • Page 204 Figure 7-22: SPR Zoom window of SPR (10.0.0.20) in IP router mode You can verify that the SPR is in router mode by the "Router Mode" display in the SPR Zoom window, as shown above. 7-22 Airspan Networks Inc. 01040311-07...

  • Page 205: Task 4: Test The Bsr-Spr Network Link

    From the PC/Laptop (IP address 10.0.0.2) behind the BSR, open an MS-DOS prompt and use the command to ping the SPR (IP address ping – t 10.0.0.20), as shown below: Figure 7-23: MS-DOS prompt using the ping – t command 01040311-07 Airspan Networks Inc. 7-23...
  • Page 206 C h a n g i n g L i n k f r o m B r i d g e t o R o u t e r C o m m i s s i o n i n g M a n u a l This page is intentionally left blank. 7-24 Airspan Networks Inc. 01040311-07...

  • Page 207: Establishing Bsr-Spr Link With Autoconnect

    Establishing BSR-SPR Link with AutoConnect This chapter describes procedures for establishing a link between BSRs and SPRs using the ASWipLL AutoConnect feature. This chapter includes the following sections: Overview Configuring Repeating AutoConnect Configuring AutoConnect with Redirection Redirecting Previously Redirected SPRs...

  • Page 208: Overview

    C o m m i s s i o n i n g M a n u a l 8.1. Overview ASWipLL’s AutoConnect feature is a license-dependant feature that automatically connects initially powered-on, unconfigured SPRs to BSRs. These SPRs automatically connect to BSRs with the strongest RF signal. In addition, these SPRs can then be redirected to different BSRs.
  • Page 209 Management VLAN, Air Subnet address, management station, and Get/Set Community string. 3) If you are implementing AutoConnect on existing ASWipLL devices, first change the Air Subnet addresses on each SPR (using WipManage or WipConfig). This will cause IP disconnection until you finally change the Air Subnet of the BSR.

  • Page 210: Automatically Connecting Sprs To Bsrs

    C o m m i s s i o n i n g M a n u a l 8.1.1. Automatically Connecting SPRs to BSRs Unconfigured and newly installed SPRs that do not appear in the ASWipLL management database remain connected to the BSR with the strongest RF signals.

  • Page 211: Redirecting Sprs To Specific Bsrs

    E s t a b l i s h i n g B S R - S P R L i n k w i t h Au t o C o n n e c t WipManage searches in the ASWipLL database for the BSR to which the SPR is assigned.
  • Page 212 The SPR sends an SNMP trap to the ASWipLL management station (i.e. WipManage) notifying WipManage that the SPR has performed an AutoConnect. WipManage identifies the BSR (BSR #2) in the ASWipLL database to which the SPR must be connected. Airspan Networks Inc.
  • Page 213 AutoConnect process ends. The SPR does not undergo AutoConnect in the future, even if switched off and then powered on again. From now on, the SPR will always establish a link with the changed BSR (BSR #2). 01040311-07 Airspan Networks Inc.

  • Page 214: Configuring Repeating Autoconnect

    You can configure repeating AutoConnect for newly installed SPRs, and for regular SPRs that are currently connected to a BSR. 8.2.1. Summary of Tasks The figure below displays a flowchart for configuring repeating AutoConnect. Figure 8-4: Flowchart for configuring repeating AutoConnect Airspan Networks Inc. 01040311-07...

  • Page 215: Task 1: Add Autoconnect Sprs

    SPR indexes configured for AutoConnect. For clarity, in our example, we will define AutoConnect SPR icons for BSR with IP address 10.0.0.10. Note: Ensure the WipManage PC IP address is defined in WipManage’s BSR Managers Table. 01040311-07 Airspan Networks Inc.
  • Page 216 1. In the BSR Zoom window, right-click an available undefined (i.e. grayed) SPR index icon, and then from the shortcut menu, choose Add Range Permitted SPRs, as displayed in Figure 8-5. Figure 8-5: Choosing Add Range Permitted SPRs command 8-10 Airspan Networks Inc. 01040311-07...
  • Page 217 In the First SPR IP Address field, enter the IP address of the first SPR (e.g. 10.0.0.12). From the Status drop-down list, select AutoConnect. From the Auto Disconnect drop-down list, select On to enable this feature. 01040311-07 Airspan Networks Inc. 8-11...
  • Page 218 Subnet Mask address. The subnets should be defined by mask. A calculator is provided to determine optimal efficiency. Figure 8-7: Subnet Address Calculator Note: If the SPRs are in transparent bridge mode, clear the Add to Static Route Table check box. 8. Click OK. 8-12 Airspan Networks Inc. 01040311-07...
  • Page 219 For a description on color-coding of AutoConnect SPR icons, see Section 8.5, "Color-Coding of AutoConnect SPR Icons". Note: The added AutoConnect SPR icons are only added to the ASWipLL database when you edit them or when an SPR device connects to them.

  • Page 220: Task 2: Define Autodisconnect Interval

    BSR SPR icon ready for Auto Disconnect connection to return time (in min.) SPR icon Available SPR icon available for configured for accepting SPR AutoConnect and device through AutoDisconnect AutoConnect Figure 8-9: AutoDisconnect process 8-14 Airspan Networks Inc. 01040311-07...
  • Page 221 SPR index to AutoConnect after an SPR disconnects from the BSR (i.e. index available for accepting an SPR with AutoConnect). Click OK. Note: The Number of Pings and Pings Interval fields are not applicable for this ASWipLL release. 01040311-07 Airspan Networks Inc. 8-15...

  • Page 222: Task 3: Configure Autoconnect For Spr

    NVRAM frequency tables before performing this procedure. To enable AutoConnect using WipConfig: Connect the PC running WipConfig to the SPR using a serial connection. Start WipConfig, and then connect to the SPR by clicking 8-16 Airspan Networks Inc. 01040311-07...
  • Page 223 A Warning message box appears, requesting you to confirm device reset. Figure 8-12: Warning message box for resetting device 5. Click Yes to reset the device with default settings. WipConfig applies factory default settings to the SPR. 01040311-07 Airspan Networks Inc. 8-17...
  • Page 224 C o m m i s s i o n i n g M a n u a l 6. Under the RF Configuration group, select the AutoConnect check box, as displayed below: AutoConnect check box selected Figure 8-13: Selecting the AutoConnect check box the toolbar, click the Write button. 8-18 Airspan Networks Inc. 01040311-07...
  • Page 225 This is because the SPR’s configuration parameters are later set (by the BSR) when the SPR connects to the BSR through AutoConnect. 2) WipConfig displays the AutoConnect check box only if the SPR device supports the AutoConnect feature. 01040311-07 Airspan Networks Inc. 8-19...

  • Page 226: Using Wipmanage

    In the BSR Zoom window, from the MultiDevices menu, choose AutoConnect. Note: You can also redefine individual SPRs for AutoConnect in the SPR Zoom window, by simply choosing the AutoConnect command from the Configuration menu. 8-20 Airspan Networks Inc. 01040311-07...
  • Page 227 E s t a b l i s h i n g B S R - S P R L i n k w i t h Au t o C o n n e c t The Multi AutoConnect Configuration dialog box appears. AutoConnect check box Figure 8-15: Enabling AutoConnect for currently connected SPRs 2. Select the AutoConnect check box. 01040311-07 Airspan Networks Inc. 8-21...
  • Page 228 Select the SPRs (e.g. 10.0.0.20 and 10.0.0.36) for which you want to enable AutoConnect, and then click Apply. The Multi Apply confirmation box appears, as displayed below. Figure 8-16: Multi Apply confirmation box 4. Select the Apply Changes check box, and then click Apply. 8-22 Airspan Networks Inc. 01040311-07...
  • Page 229 E s t a b l i s h i n g B S R - S P R L i n k w i t h Au t o C o n n e c t The SPR is configured for AutoConnect (i.e. YES appears in the AutoConnect column, as displayed below). Figure 8-17: YES displayed for AutoConnect Reset the SPR: from the MultiDevices menu, choose Reset. 01040311-07 Airspan Networks Inc. 8-23...
  • Page 230 C o m m i s s i o n i n g M a n u a l Figure 8-18: YES displayed for AutoConnect Select the SPRs that you want to reset, and then click Apply. 8-24 Airspan Networks Inc. 01040311-07...
  • Page 231 E s t a b l i s h i n g B S R - S P R L i n k w i t h Au t o C o n n e c t Figure 8-19: Confirming SPR selection 7. Click Apply. Figure 8-20: Confirming reset 8. Click Yes. 01040311-07 Airspan Networks Inc. 8-25...

  • Page 232: Task 4: Verify Bsr-Spr Link

    BSR and then using AutoConnect, connect to the BSR with which it has the strongest RF signal. In WipManage, the BSR Zoom window displays the SPR AutoConnect icons in green color, as displayed below: Figure 8-21: SPRs connected to BSR using AutoConnect 8-26 Airspan Networks Inc. 01040311-07...

  • Page 233: Configuring Autoconnect With Redirection

    AutoConnect. In such a scenario, the SPR associates with the same BSR, but with a different index number. 3) For redirection, all BSRs in the network must have the same Management VLAN ID, Air Subnet, Managers Table, and Get/Set Community settings. 01040311-07 Airspan Networks Inc. 8-27...

  • Page 234: Summary Of Tasks

    C o m m i s s i o n i n g M a n u a l 8.3.1. Summary of Tasks The steps for configuring AutoConnect with Redirection using WipManage are described in the flowchart below. Figure 8-22: Flow diagram of configuring AutoConnect (and Redirection) 8-28 Airspan Networks Inc. 01040311-07...

  • Page 235: Task 1: Enable Wipmanage To Receive Redirection Traps

    Settings. The Environment Settings dialog box appears, as displayed below. Selected check box for receiving Redirection traps Figure 8-23: Environment Settings dialog box - Traps Settings tab Select the SPRs Redirection After AutoConnect check box. Click OK. 01040311-07 Airspan Networks Inc. 8-29...

  • Page 236: Task 2: Add "Fixed" Sprs

    C o m m i s s i o n i n g M a n u a l 8.3.3. Task 2: Add "Fixed" SPRs The first step in configuring AutoConnect in the ASWipLL system is to define a range of "fixed" SPRs. These SPR indexes will be used later to accept SPRs redirected to them that initially connected to a BSR through AutoConnect.
  • Page 237 The subnets should be defined by mask. A calculator is provided to determine optimal efficiency. Figure 8-25: Subnet Address Calculator If required, select the Add to Static Route Table check box. Note: For transparent bridging, clear the Add to Static Route Table check box. 01040311-07 Airspan Networks Inc. 8-31...

  • Page 238: Task 3: Add Autoconnect Sprs

    The defined fixed SPR indexes (e.g. SPR indexes 2 to 43) are displayed below: Figure 8-26: Added "fixed" SPR index icons (2 to 43) displayed in BSR Zoom window Note: The newly added SPRs are only added to the ASWipLL database when you edit them (i.e. when you define the SPRs for Redirection).
  • Page 239 Figure 8-27: Add Range Permitted SPRs dialog box In the First SPR Index field, enter the index number of the first SPR (e.g. 65) In the Last SPR Index field, enter the index number of the last SPR (e.g. 127). 01040311-07 Airspan Networks Inc. 8-33...
  • Page 240 In the Subnet Mask field, enter Subnet Mask address. The subnets should be defined by mask. A calculator is provided to determine optimal efficiency. Figure 8-28: Subnet Address Calculator If required, select the Add to Static Route Table check box. 8-34 Airspan Networks Inc. 01040311-07...
  • Page 241 SPR and BSR), and display the letter "A" (i.e. indicating that the SPR icon is available for accepting an SPR through AutoConnect)/ Note: The added AutoConnect SPR icons are only added to the ASWipLL database when you edit them or when an SPR device connects to them.

  • Page 242: Task 4: Define Autodisconnect Interval

    SPR index to AutoConnect after an SPR disconnects from the BSR (i.e. index available for accepting an SPR with AutoConnect). Click OK. Note: The Pings Interval and Number of Pings fields are only applicable for previous ASWipLL releases. 8-36 Airspan Networks Inc. 01040311-07...

  • Page 243: Task 5: Configure "Fixed" Sprs For Redirection

    This SPR’s Ethernet MAC address for the SPR index icon, corresponding to the associated BSR, is stored in the ASWipLL database. After an SPR initially connects to a BSR using AutoConnect, WipManage searches the ASWipLL database for the SPR’s Ethernet MAC address.
  • Page 244 Select the AutoConnect Redirection check box. In the Redirection Eth. MAC Address field, enter the SPR’s Ethernet MAC address (e.g. 2001F0). This is the SPR device that you want redirected to this BSR (10.0.0.10) after the SPR has performed AutoConnect. 8-38 Airspan Networks Inc. 01040311-07...
  • Page 245 The Permitted SPRs Table dialog box displays the SPR’s Ethernet MAC address in the Redirection Eth. MAC column. SPR’s Ethernet MAC address for redirection Figure 8-33: SPR’s Ethernet MAC address defined 5. To define the Ethernet MAC addresses of additional fixed SPRs, see Step 2. 01040311-07 Airspan Networks Inc. 8-39...

  • Page 246: Task 6: Power On Or Reset Spr Device

    The powered on SPR device first connects to the BSR (e.g. 10.0.0.10) using AutoConnect. The figure below displays the AutoConnect SPR index 65 icon to which the SPR device connects in the BSR using AutoConnect. Figure 8-34: SPR connected to BSR using AutoConnect (AutoConnect SPR index 65) 8-40 Airspan Networks Inc. 01040311-07...
  • Page 247 SPR (i.e. SPR index 2) containing the SPR’s Ethernet MAC address. The figure below displays the fixed Redirection SPR index 2 icon to which the redirected SPR device connects in the BSR. Figure 8-35: SPR redirected to BSR (fixed SPR index 2) 01040311-07 Airspan Networks Inc. 8-41...

  • Page 248: Redirecting Previously Redirected Sprs

    2) When the SPR is redirected, the previous SPR’s entry (i.e. index # 2) in the ASWipLL database is deleted, and the new SPR (i.e. index # 6) defined by its new Ethernet MAC address, is entered in the database with its associated BSR.

  • Page 249: Summary Of Tasks

    8.4.1. Summary of Tasks Figure 8-36 displays a flow chart describing the steps for redirecting a previously redirected SPR, to another BSR (or SPR index). Figure 8-36: Flow chart for redirecting a previously redirected SPR 01040311-07 Airspan Networks Inc. 8-43...

  • Page 250: Task 1: Add A "Fixed" Spr For Redirection

    1. In the BSR Zoom window of the BSR to where you want the SPR device to be redirected, right-click a fixed SPR (e.g. SPR index 6), and then from the shortcut menu, choose Edit. Figure 8-37: Permitted SPRs Edit dialog box for defining redirection 2. Select the AutoConnect Redirection check box. 8-44 Airspan Networks Inc. 01040311-07...
  • Page 251 The Ethernet MAC Address Exists confirmation box appears, informing you that this SPR device has already undergone redirection to a BSR. Figure 8-38: Ethernet MAC Address Exists confirmation box 5. Click Yes to change SPR’s original redirection location. 01040311-07 Airspan Networks Inc. 8-45...

  • Page 252: Task 2: Add An Autoconnect Spr

    1. In the BSR Zoom window, right-click an available undefined (i.e. grayed) SPR index icon, and then from the shortcut menu, choose Add Range Permitted SPRs, as displayed below. Figure 8-39: Choosing the Add Range Permitted SPRs command 8-46 Airspan Networks Inc. 01040311-07...
  • Page 253 Select the Add to Static Route Table check box, and then in the Subnet Mask field, enter Subnet Mask address. Note: If the SPRs are in transparent bridge mode, clear the Add to Static Route Table check box. 01040311-07 Airspan Networks Inc. 8-47...

  • Page 254: Task 3: Redefine Autoconnect For Currently Redirected Spr

    You now need to return the currently connected SPR (that connected to the BSR by redirection), to AutoConnect. To redefine a redirected SPR for AutoConnect: In the BSR Zoom window, from the MultiDevices menu, choose AutoConnect. 8-48 Airspan Networks Inc. 01040311-07...
  • Page 255 Note: You can also redefine individual SPRs for AutoConnect in the SPR Zoom window, by simply choosing the AutoConnect command from the Configuration menu. The Multi AutoConnect Configuration dialog box appears. Figure 8-42: Defining AutoConnect for currently connected and redirected SPRs 01040311-07 Airspan Networks Inc. 8-49...
  • Page 256 Select the permitted SPR (e.g. 30.0.0.1) that you want to redirect to a different BSR, and then click Apply. The Multi Apply confirmation box appears, as displayed below. Figure 8-43: Multi Apply confirmation box 4. Select the Apply Changes check box, and then click Apply. 8-50 Airspan Networks Inc. 01040311-07...
  • Page 257 E s t a b l i s h i n g B S R - S P R L i n k w i t h Au t o C o n n e c t The SPR is configured for AutoConnect (i.e. YES appears in the AutoConnect column, as displayed below). Figure 8-44: YES displayed for AutoConnect 5. Click Close. 01040311-07 Airspan Networks Inc. 8-51...

  • Page 258: Task 4: Reset The Spr Device

    Add a "Fixed" SPR for Redirection"). To reset the SPR device: In the BSR Zoom window, from the MultiDevices menu, choose Reset. The Multi Reset dialog box appears, as displayed below. Figure 8-45: Multi Reset dialog box 8-52 Airspan Networks Inc. 01040311-07...
  • Page 259 AutoConnect), and then is redirected to the BSR containing the SPR’s Ethernet MAC address. Note: The previous SPR’s entry (i.e. index # 2) in the ASWipLL database is deleted, and the new SPR (i.e. index # 6) defined by its new Ethernet MAC address is entered in the database, with its associated BSR.
  • Page 260 The following figures display the process in WipManage’s BSR Zoom window when redirecting a previously redirected SPR device. Figure 8-48: Connected SPR (index #2) that was previously redirected Figure 8-49: Disconnected SPR (index #2) due to reset to AutoConnect 8-54 Airspan Networks Inc. 01040311-07...
  • Page 261 E s t a b l i s h i n g B S R - S P R L i n k w i t h Au t o C o n n e c t Figure 8-50: Connected SPR (index #65) using AutoConnect Figure 8-51: SPR (index #65) redirected to BSR (i.e. SPR index #6) 01040311-07 Airspan Networks Inc. 8-55...

  • Page 262: Color-Coding Of Autoconnect Spr Icons

    SPR icon. When the SPR device losses connection with the BSR, the SPR icon changes to a normal fixed SPR icon without air link or IP routing link. Figure 8-54 depicts this process of an SPR icon configured for AutoConnect (without Auto Disconnect). 8-56 Airspan Networks Inc. 01040311-07...
  • Page 263 AutoConnect or regular means. Yellow with SPR icon defined for AutoConnect with triangle AutoDisconnect in the BSR has lost connection with SPR device and is undergoing AutoDisconnect (see Section 8.3.5, "Task 4: Define AutoDisconnect Interval"). 01040311-07 Airspan Networks Inc. 8-57...

  • Page 264: Autoconnect Trap Messages

    WipManage’s trap messages. These trap messages can be viewed in the Traps pane of the WipManage main window, as displayed below. Traps pane displaying AutoConnect trap Figure 8-55: Main window displaying AutoConnect traps 8-58 Airspan Networks Inc. 01040311-07...
  • Page 265 The SPR was redirected. <SPR’s Ethernet MAC address> after redirect The SPR is configured for redirection, but <SPR’s Ethernet MAC address> is WipManage cannot locate the SPR’s Ethernet not set for redirection MAC address in the database. 01040311-07 Airspan Networks Inc. 8-59...
  • Page 266 E s t a b l i s h i n g B S R - S P R L i n k w i t h Au t o C o n n e c t C o m m i s s i o n i n g M a n u a l This page is intentionally left blank. 8-60 Airspan Networks Inc. 01040311-07...

  • Page 267: Configuring A Point-To-Point Radio Link

    Configuring a Point-to-Point Radio Link This chapter describes basic procedures for configuring a point-to-point wireless link using ASWipLL’s PPR device. This chapter includes the following sections: Overview Summary of Tasks Task 1:Configure the PPR Task 2: Configure the SPR Task 3: Test the PPR-SPR Link Note: This chapter mentions the SPR device.

  • Page 268: Overview

    If more than 4 Mbps bandwidth is required between two end points, two or more links can be installed in parallel. For two links, ASWipLL uses IP routing: one link routes IP traffic in the uplink; and another link, routes IP traffic in the downlink.
  • Page 269 Figure 9-1: BSR Zoom window displaying a single SPR index for PPR In the figure, only one SPR index is available for adding an SPR. This available SPR index is calculated using the suffix of the PPR’s Air Mac address. 01040311-07 Airspan Networks Inc.
  • Page 270 MAC address suffix: Table 9-1: SPR index calculated from PPR's Air MAC address PPR Air Mac address suffix SPR index Hexadecimal Decimal XX:00 XX:01 XX:02 … … … XX:7D XX:7E XX:7F … … … XX:FD XX:FE XX:FF Airspan Networks Inc. 01040311-07...
  • Page 271 C o n f i g u r i n g a P o i n t - t o - P o i n t R a d i o L i n k For clarity, the procedures described in this chapter are based on the following configuration example: Figure 9-2: Configuration example for PPR setup 01040311-07 Airspan Networks Inc.

  • Page 272: Summary Of Tasks

    The flowchart in Figure 4-1 displays a summary of tasks for configuring a point-to- point wireless link between a PPR and an SPR. Figure 9-3: Flowchart for configuring PPR in ASWipLL 9.3. Task 1:Configure the PPR You need to use WipConfig to configure the PPR. This includes defining an SPR (by IP address) with which the PPR will form a point-to-point radio link.
  • Page 273 Connect the PC running WipConfig to the PPR. Start WipConfig. In the Communication group, select Serial. On the toolbar, click the Connect button. WipConfig connects to the PPR (i.e. IP address 10.0.0.10). Configuration button Figure 9-4: WipConfig connected to PPR device 01040311-07 Airspan Networks Inc.
  • Page 274 Note: If in the PPR’s ROM, the PPR is defined as an IP router, then the Mode field displays Router; If the PPR is defined for transparent bridging, then the Mode field displays Bridge. 7. In the Eth IP Address field, enter the PPR's IP address (e.g. 10.0.0.10). Airspan Networks Inc. 01040311-07...
  • Page 275 PPR will create a point-to-point radio link. In the Subnet Mask field, enter the subnet mask address of the SPR (e.g. 255.255.255.240) with which the PPR will create a point-to-point radio link. Click Accept. On the toolbar, click the Write button. 01040311-07 Airspan Networks Inc.

  • Page 276: Task 2: Configure The Spr

    SPR's IP and subnet addresses so that the SPR is in the same subnet as the PPR. It is recommended to configure the SPR through a serial connection. To configure the SPR (WipConfig): Connect the PC running WipConfig to the SPR device. Start WipConfig. In the Communication group, select Serial. 9-10 Airspan Networks Inc. 01040311-07...
  • Page 277 C o n f i g u r i n g a P o i n t - t o - P o i n t R a d i o L i n k On the toolbar, click the Connect button. WipConfig connects to the SPR (i.e. IP address 10.0.0.20). PPR button Figure 9-9: SPR Configuration pane 01040311-07 Airspan Networks Inc. 9-11...
  • Page 278 Note: If in the SPR's ROM, the SPR is defined as an IP router, then the Mode field displays Bridge; If the SPR is defined for transparent bridging, then the Mode field displays Router. 7. In the Eth IP Address field, enter the SPR's IP address (e.g. 10.0.0.20). 9-12 Airspan Networks Inc. 01040311-07...
  • Page 279 Air MAC address to which the SPR is associated, e.g. 0x1200. Valid ranges are from 0x0000 to 0xFFFF. Note: For the Air MAC address, Airspan recommends using only the most significant bytes (MSB), e.g. the two left-most bytes, and not the least significant bytes (LSB), e.g.
  • Page 280 Figure 9-13: SPR configured for PPR (e.g. SPR index according to PPR’s Air MAC) Note: If WipManage contains a BSR with the same IP address as the PPR, before you can add the PPR in WipManage, you need to first delete this BSR. 9-14 Airspan Networks Inc. 01040311-07...

  • Page 281: Task 3: Test The Ppr-Spr Link

    From the PC/Laptop (IP address 10.0.0.2) behind the PPR, open an MS-DOS prompt and use the command to ping the SPR (IP address ping – t 10.0.0.20), as shown below: Figure 9-14: Pinging the ASWipLL device using the MS-DOS ping-t command 01040311-07 Airspan Networks Inc. 9-15...
  • Page 282 C o n f i g u r i n g a P o i n t - t o - P o i n t R a d i o L i n k C o m m i s s i o n i n g M a n u a l This page is intentionally left blank. 9-16 Airspan Networks Inc. 01040311-07...

  • Page 283: Configuring A Repeater Solution

    Configuring a Repeater Solution This chapter describes the procedures for configuring a back-to-back (i.e. BSR-to- SPR) repeater solution in the ASWipLL network using a BSR and SPR. This chapter includes the following sections: Overview Summary of Tasks Task 1: Add BS-1 and BS-2 Task 2: Add BSR-1 and BSR-2 Task 3: Define BSR-1’s Default Gateway...

  • Page 284: Overview

    C o m m i s s i o n i n g M a n u a l 10.1. Overview ASWipLL devices can be used to provide repeater functionality. This is implemented in scenarios in which the BSR needs to be "extended" to remote subscriber sites that are blocked by obstacles (such as trees, hills, and other typical line-of-sight obstructions) or that the BSR-SPR transmission is out-of-range.
  • Page 285 C o n f i g u r i n g a R e p e a t e r S o l u t i o n In Figure 1-9, BSR A is part of an ASWipLL Base Station that is connected to the service provider’s backbone.

  • Page 286: Summary Of Tasks

    C o m m i s s i o n i n g M a n u a l 10.2. Summary of Tasks The flowchart in Figure 4-1 displays a summary of tasks for configuring a back-to- back (SPR-to-BSR) repeater solution. Figure 10-2: Flowchart for configuring a back-to-back ASWipLL repeater solution 10-4 Airspan Networks Inc. 01040311-07...
  • Page 287 C o n f i g u r i n g a R e p e a t e r S o l u t i o n For clarity, the back-to-back repeater procedures described in this chapter are based on the following basic configuration: Figure 10-3: Configuration example for configuring a back-to-back ASWipLL repeater solution 01040311-07 Airspan Networks Inc.

  • Page 288: Task 1: Add Bs-1 And Bs-2

    The first task that you need to perform is to add Base Stations BS-1 and BS-2. These Base Stations are located in different geographical areas. BS-1 represents the ASWipLL Base Station consisting of BSR-1 (associated with SPR-1); BS-2 represents the repeater Base Station consisting of BSR-2 (associated with SPR-2, and connected to SPR-1 via Ethernet hub SDA).
  • Page 289 C o n f i g u r i n g a R e p e a t e r S o l u t i o n The WipManage-BS-Add dialog box appears: Figure 10-5: WipManage-BS-Add dialog box 2. In the BS Name field, enter the BS name (i.e. BS-1 or BS-2), and then click OK. 01040311-07 Airspan Networks Inc. 10-7...

  • Page 290: Task 2: Add Bsr-1 And Bsr-2

    The next task is to add BSR-1 and BSR-2 to Base Station BS-1 and BS-2, respectively. The following procedure only relates to adding BSR-1 to BS-1. However, this procedure is similar for adding BSR-2 to BS-2. To add BSR-1 to BS-1: 1. Double-click the BS-1 icon. 10-8 Airspan Networks Inc. 01040311-07...
  • Page 291 2. Right-click one of the blue rectangles, and then from the shortcut menu, choose Add BSR, as shown below. Choosing Add BSR from shortcut menu Figure 10-7: Choosing the Add BSR command from the shortcut menu The WipManage-BSR-Add dialog box appears. Figure 10-8: Adding BSR-1 01040311-07 Airspan Networks Inc. 10-9...
  • Page 292 In the Manage IP field, enter 10.1.1.1 for the IP address of BSR-1. (10.1.2.2 for BSR-2). In the Name field, enter a Name. Click OK. The BSR-1 and BSR-2 are added, as shown below (e.g. BSR-1 added to BS-1). Figure 10-9: Added BSR-1 to BS-1 10-10 Airspan Networks Inc. 01040311-07...
  • Page 293 C o n f i g u r i n g a R e p e a t e r S o l u t i o n Double-click BSR-1 to open the BSR Zoom window, shown below. Figure 10-10: BSR Zoom window of BSR-1 01040311-07 Airspan Networks Inc. 10-11...

  • Page 294: Task 3: Define Bsr-1'S Default Gateway

    To define BSR-1's default gateway: In the BSR Zoom window for BSR-1, from the Configuration menu, point to Network, and then choose Static Routing Table. The Static Routing Table dialog box appears. Figure 10-11: Static Routing Table dialog box 10-12 Airspan Networks Inc. 01040311-07...
  • Page 295 IP address of the router connected to the Internet network (i.e. IP world) In the Metric field, enter "1" Figure 10-12 displays the defined default gateway to the Internet network. Figure 10-12: Defining default GW 01040311-07 Airspan Networks Inc. 10-13...

  • Page 296: Task 4: Define Bsr-2'S Default Gateway

    Select the Enable Default Gateway check box, and then enter the following: IP address of SPR-1 (e.g. 10.1.2.1) In the Metric field, enter "1" The figure below displays BSR-2’s default gateway (i.e. SPR-1). Figure 10-13: Defining BSR-2’s default gateway 10-14 Airspan Networks Inc. 01040311-07...

  • Page 297: Task 5: Add Spr-1 And Spr-2

    The BSR Zoom window appears. 2. Right-click the available SPR index (SPR index 2 in this example), and then from the shortcut menu, choose Add, as shown below. Figure 10-14: Choosing the Add command from the shortcut menu 01040311-07 Airspan Networks Inc. 10-15...
  • Page 298 In the IP Address field, enter the IP address of the SPR-1 (10.1.2.1). In the Name field, enter the name of the SPR-1. Figure 10-15 displays an example of the Permitted SPRs – Add dialog box. IP address of SPR-1 Figure 10-15: Permitted SPRs Add dialog box 10-16 Airspan Networks Inc. 01040311-07...
  • Page 299 Add a route for the BSR-1 to reach SPR-1 by performing the following: Click Route. The Static Routing Table per SPR dialog box appears. Figure 10-16: Static Routing Table per SPR dialog box b. Click Add. Figure 10-17: Adding static route 01040311-07 Airspan Networks Inc. 10-17...
  • Page 300 In the Route Mask field, enter SPR-1 subnet mask (i.e. 255.255.255.0). Click OK. Click Close, and then OK. The SPR-1 icon is added to BSR-1 (10.0.0.10), as shown below. Figure 10-18: Added SPR-1 to BSR-1 10-18 Airspan Networks Inc. 01040311-07...

  • Page 301: Task 6: Add Routes For Sprs Behind Bsr-2 Toward Spr-1

    To add routes for SPRs behind BSR-2 toward SPR-1: In the BSR Zoom window for BSR-1, from the Configuration menu, point to Network, and then choose Static Routing Table. The Static Routing Table dialog box appears. Figure 10-19: Static Routing Table dialog box 01040311-07 Airspan Networks Inc. 10-19...
  • Page 302 For the Next Hop, select the SPR check box, and then select the SPR index number (i.e. 2) for which SPR #1 is defined. This indicates that for BSR #1 to reach SPR #2, it must route through SPR #1. 10-20 Airspan Networks Inc. 01040311-07...
  • Page 303 C o n f i g u r i n g a R e p e a t e r S o l u t i o n 3. Click OK. Added static route shown below. Figure 10-21: Added route from SPR-2 (behind BSR-2) toward SPR-1 01040311-07 Airspan Networks Inc. 10-21...

  • Page 304: Task 7: Define Spr-1'S Default Gateway

    Network, and then choose Static Routing Table. The Static Routing Table dialog box appears. Select the Enable Default Gateway check box, and then click the BSR check box to define BSR-1 as the SPR-1’s default gateway. Figure 10-22: Defining SPR-1’s default gateway as BSR-1 10-22 Airspan Networks Inc. 01040311-07...

  • Page 305: Task 8: Add Routes For Sprs Behind Bsr-2 Toward Bsr-2

    To add routes for SPRs behind BSR-2 toward BSR-2: In the SPR Zoom window for SPR-1, from the Configuration menu, point to Network, and then choose Static Routing Table. The Static Routing Table dialog box appears. Figure 10-23: Static Routing Table dialog box 01040311-07 Airspan Networks Inc. 10-23...
  • Page 306 WipManage automatically calculates the correct destination route. In the Route Mask field, enter the subnet mask of SPR #2. For the Next Hop, enter the IP address of BSR-2 through which SPR-1 has to route traffic in order to reach SPR-2. 10-24 Airspan Networks Inc. 01040311-07...
  • Page 307 C o n f i g u r i n g a R e p e a t e r S o l u t i o n 4. Click OK. The added route is displayed in the Static Routing Table dialog box, as displayed below. Figure 10-25: Added route for SPR-1 to SPR-2 01040311-07 Airspan Networks Inc. 10-25...

  • Page 308: Task 9: Define Spr-2'S Default Gateway

    Select the Enable Default Gateway check box, and then click the BSR check box to define BSR-2 as the SPR-2’s default gateway. All other SPRs associated with BSR-2 must be configured in the same way as described above. 10-26 Airspan Networks Inc. 01040311-07...

  • Page 309: Managing Bandwidth

    Managing Bandwidth This chapter describes the procedures for managing the bandwidth in the ASWipLL system, and includes the following sections: Overview Configuring Asymmetric Bandwidth Summary of Tasks Task 1: Enable Asymmetric Bandwidth Policy Task 2: Define Downlink and Uplink CIR and MIR Values Note: This chapter mentions the BSR and SPR devices.

  • Page 310: Overview

    C o m m i s s i o n i n g M a n u a l 11.1. Overview The ASWipLL system allows operators and service providers to manage the bandwidth policy allocated to their subscribers, assuring optimal network performance.

  • Page 311: Configuring Asymmetric Bandwidth

    M a n a g i n g B a n d w i d t h When the total CIR of active SPRs is greater than the available bandwidth for data (CIR overbooking), ASWipLL implements its CIR Proportional Degradation feature. CIR overbooking can derive from the following:...

  • Page 312: Summary Of Tasks

    BSR, the Asymmetric CIR/MIR bandwidth policy applies to all SPRs associated with the BSR. To enable Asymmetric bandwidth policy: In the BSR Zoom window, from the Configuration menu, point to SPRs, and then choose Bandwidth Limitation. The Bandwidth Limitation dialog box appears. 11-4 Airspan Networks Inc. 01040311-07...
  • Page 313 C o m m i s s i o n i n g M a n u a l M a n a g i n g B a n d w i d t h Asymmetric bandwidth policy selected Figure 11-2: Selecting Asymmetric CIR/MIR option Select the Asymmetric CIR/MIR option. Click OK. 01040311-07 Airspan Networks Inc. 11-5...

  • Page 314: Task 2: Define Downlink And Uplink Cir And Mir Values

    In the BSR Zoom window, from the Configuration menu, point to SPRs, and then choose Multi Edit/Delete Permitted SPRs. The Multi Edit-Delete Permitted SPRs dialog box appears. Figure 11-3: Multi Edit-Delete Permitted SPRs dialog box 11-6 Airspan Networks Inc. 01040311-07...
  • Page 315 MIR and CIR, -Or- Click the Select Range button, and then enter the range of SPR indexes that you want to select, and then click OK. Figure 11-4: Selecting a range of SPRs 01040311-07 Airspan Networks Inc. 11-7...
  • Page 316 C o m m i s s i o n i n g M a n u a l 3. Click Edit. The Edit Permitted SPRs dialog box appears. Downlink MIR and CIR Uplink MIR and CIR Figure 11-5: Editing downlink and uplink MIR and CIR values 11-8 Airspan Networks Inc. 01040311-07...
  • Page 317 3) The default CIR value is zero (0). 4) When the total CIR of active SPRs and IDRs is greater than the available bandwidth for data, ASWipLL implements its CIR Proportional Degradation feature whereby the CIR decreases in proportion for all the SPRs. Therefore, the proportion between CIR bandwidth of all SPRs is maintained.
  • Page 318 M a n a g i n g B a n dw i d t h C o m m i s s i o n i n g M a n u a l This page is intentionally left blank. 11-10 Airspan Networks Inc. 01040311-07...

  • Page 319: Defining Static Routes

    In addition, static route configuration also includes defining default gateways. These are default gateways that you can define for each ASWipLL device. In the case of a BSR, the default gateway can be a third-party router or any SPR that is associated with the BSR.

  • Page 320: Adding Static Routes To A Bsr

    1) The procedures described in this chapter relate to the BSR. However, the procedures for adding static routes for SPRs are similar 2) When ASWipLL is configured for transparent bridging, static routing is not applicable. However, the Static Routing Table command allows you to define a default gateway, which is applicable for transparent bridging.

  • Page 321: Summary Of Tasks

    D e f i n i n g S t a t i c R o u t e s 12.2.1. Summary of Tasks The flowchart in the figure below displays the tasks for adding a static route and default gateway to a BSR. Figure 12-2: Flowchart for adding static routes 01040311-07 Airspan Networks Inc. 12-3...

  • Page 322: Task 1: Add Static Route To Bsr

    To add a static route (for BSR #1): From the Configuration menu, point to Network, and then choose Static Routing Table. The Static Routing Table dialog box is displayed in Figure 12-3. Figure 12-3: Static Routing Table dialog box 12-4 Airspan Networks Inc. 01040311-07...
  • Page 323 BSR). (When the next hop is one of the SPRs/IDRs in the cell, you can select the SPR check box, and then enter the SPR’s index number as defined in the BSR.) Primary Metric: number of hops between the BSR and the SPR/IDR or the next router. Click OK. 01040311-07 Airspan Networks Inc. 12-5...

  • Page 324: Task 2: Add Default Gateway To Bsr

    Select the Enable Default Gateway check box, and then perform the following: In the text box, enter the BSR's default gateway's IP address, e.g. 10.0.0.1. In the Metric field, enter hops between the BSR and the default gateway. Click Apply. 12-6 Airspan Networks Inc. 01040311-07...

  • Page 325: Defining Virtual Ports

    VLANs can be assigned to each of these virtual port interfaces. This is useful when implementing a gateway per VLAN application where SPR VLAN traffic is routed to these interfaces (i.e. gateways). Note: For a detailed description on defining gateways per VLAN, see Chapter 14, "Defining VLANs". 01040311-07 Airspan Networks Inc. 13-1...
  • Page 326 1. In the BSR Zoom window, from the Configuration menu, point to Network, and then choose Addresses Table / 802.1Q. The Addresses Table/802.1Q dialog box appears, as displayed below. Figure 13-2: Addresses Table/802.1Q dialog box 13-2 Airspan Networks Inc. 01040311-07...
  • Page 327 BSR and the other component. If there is only one interface protocol, this selection remains grayed. Otherwise, from the drop- down list, select an interface. Subnet Mask: subnet address of the BSR's logical network interface (e.g. 255.255.255.0). 01040311-07 Airspan Networks Inc. 13-3...
  • Page 328 "Defining VLANs"), select the VLAN ID check box, and then enter the VLAN number (e.g. 100). Click OK. Perform steps 2 through 5 for adding the BSR's virtual port 10.0.1.2 with gateway 10.0.1.1 (with VLAN ID 200), as configured below. Figure 13-4: Defining a virtual port 10.0.1.2 13-4 Airspan Networks Inc. 01040311-07...
  • Page 329 D e f i n i n g V i r t u a l P o r t s The figure below displays the virtual ports defined in the procedure above. BSR's virtual ports Figure 13-5: Addresses Table / 802.1Q listing virtual ports 01040311-07 Airspan Networks Inc. 13-5...
  • Page 330 D e f i n i n g V i r t u a l P o r t s C o m m i s s i o n i n g M a n u a l This page is intentionally left blank. 13-6 Airspan Networks Inc. 01040311-07...

  • Page 331: Defining Vlans

    Defining VLANs This chapter describes the procedures for defining VLAN policy and management for the ASWipLL system, and includes the following sections: Overview Transparent Mode Tagging Mode Defining VLANs for IP Routing Defining Gateways per VLAN Summary of Tasks −...

  • Page 332: Overview

    Two stations in the same VLAN communicate directly using MAC-level frames (Layer 2), whereas stations in different VLANs need to use Layer 3 connections to communicate (i.e. IP routing protocol). ASWipLL uses two types of VLAN modes: Transparent Tagging 14-2 Airspan Networks Inc.

  • Page 333: Transparent Mode

    WAN to the subscriber. Therefore, in transparent mode, VLAN traffic is passed uninterrupted through the ASWipLL network, preserving the VLAN formats. Figure 14-1: Transparent mode Transparent mode is configured in WipManage, by selecting the Pass Any option in the Addresses Table / 802.1Q dialog box for BSRs (in the BSR Zoom window), or...

  • Page 334: Tagging Mode

    BSR. In the opposite direction, the SPR accepts only traffic from these VLANs. Figure 14-2: Tagging mode 14.2. Defining VLANs for IP Routing This section describes how to define VLANs when ASWipLL is configured in the IP router / PPPoE mode. 14-4 Airspan Networks Inc.

  • Page 335: Defining Gateways Per Vlan

    Therefore, the BSR does not perform the main routing, rather the gateway. The figure below illustrates the implementation of the Gateway per VLAN feature. Figure 14-3: ASWipLL’s gateway per VLAN mode In the figure, VLAN 60 traffic is routed by Gateway #1, and VLAN 70 and VLAN 80 traffic is routed by Gateway #2.

  • Page 336: Summary Of Tasks

    14.2.1.1. Summary of Tasks The flowchart in the figure below displays a summary of tasks for defining gateways per VLAN for the ASWipLL network. Figure 14-4: Flowchart for defining gateways per VLAN 14.2.1.2. Task 1: Enable Gateway per VLAN Mode...
  • Page 337 Gateway Mode. The IntraCom dialog box appears. Figure 14-5: IntraCom dialog box 3. Select the Gateway Per VLAN Mode option, and then click OK. The following Notice message box appears. Figure 14-6: Notice message box 4. Click OK. 01040311-07 Airspan Networks Inc. 14-7...

  • Page 338: Task 2: Reset The Bsr

    Now that you have configured the BSR device for Gateway per VLAN mode, you need to define the BSR's virtual IP address and assign the virtual port a gateway with a specific VLAN ID. This is performed using WipManage. 14-8 Airspan Networks Inc. 01040311-07...
  • Page 339 In the BSR Zoom window, from the Configuration menu, point to Network, and then choose Addresses Table/802.1Q. The Addresses Table/802.1Q dialog box appears. Figure 14-9: Addresses Table/802.1Q dialog box 2. Click Add. The Device Addresses Table dialog box appears. 01040311-07 Airspan Networks Inc. 14-9...

  • Page 340: Task 4: Define Spr Vlan Id(S)

    14.2.1.5. Task 4: Define SPR VLAN ID(s) Each SPR can support only one VLAN ID, except for SPRs that are attached to the ASWipLL SDA-4S/VLtag switch, which provides up to four VLAN IDs, each corresponding to a port (1 to 4).
  • Page 341 C o m m i s s i o n i n g M a n u a l D e f i n i n g V L AN s Figure 14-11: 802.1Q (VLAN) Configuration dialog box 01040311-07 Airspan Networks Inc. 14-11...

  • Page 342: Defining Bsr Vlan Policy And Management

    (SDA-4S/VLtag) group, select Enable/Disable VLAN Tagging check box, and then for each port (1 to 4 ports), define the VLAN ID and its corresponding priority level. Note: SDA-4S/VLtag VLAN tagging is only applicable when ASWipLL is configured for transparent bridging. Click OK.
  • Page 343 3. To define the policy for VLAN traffic, in the IP Routing / Transparent Bridging group or PPPoE Bridging group (depending on the environment), perform the following: Pass Any: passes all traffic Drop 802.1Q: discards traffic that has a VLAN tag 01040311-07 Airspan Networks Inc. 14-13...

  • Page 344: Defining Spr Vlan Policy And Management

    BSR Zoom window appears. In the BSR Zoom window, double-click the SPR icon. The SPR Zoom window appears. 3. From the Configuration menu, point to Network, and then click 802.1Q (VLAN). The 802.1Q (VLAN) Configuration dialog box appears. 14-14 Airspan Networks Inc. 01040311-07...
  • Page 345 C o m m i s s i o n i n g M a n u a l D e f i n i n g V L AN s Figure 14-13: 802.1Q (VLAN) Configuration dialog box 01040311-07 Airspan Networks Inc. 14-15...
  • Page 346 Priority: select the priority level (0 to 7, where zero is the lowest priority) Click Apply, and then OK. Notes: 1) The SDA-4S/VL – VLAN Tagging group is relevant only when ASWipLL is configured in Bridge mode. 2) If you select the Management VLAN Enabled check box, only those WipManage stations belonging to the defined VLAN can manage the SPR.

  • Page 347: Defining Vlans For Transparent Bridging

    D e f i n i n g V L AN s 14.3. Defining VLANs for Transparent Bridging When the ASWipLL network is operating in the transparent bridge mode, you can define only one VLAN per SPR. In addition, WipManage allows you to define a VLAN ID for SPR SNMP management.
  • Page 348 In the IP Routing / Transparent Bridging group, select one of the following options: Pass Any: passes all transparent bridging traffic − Drop 802.1Q: discards transparent bridging traffic that has a VLAN tag − 14-18 Airspan Networks Inc. 01040311-07...
  • Page 349 Priority: select the priority level (0 to 7, where zero is the lowest − priority) Note: The Management VLAN Enabled check box is available only if you have selected the Pass Any option, in the Transparent Bridging group. 6. Click Apply, and then OK. 01040311-07 Airspan Networks Inc. 14-19...

  • Page 350: Defining Spr Vlan Policy And Management

    3. From the Configuration menu, point to Network, and then click 802.1Q (VLAN). The Bridge Mode message box appears informing you that PPPoE configurations are not relevant for transparency bridging. Figure 14-16: Bridge Mode message box 4. Click OK. 14-20 Airspan Networks Inc. 01040311-07...
  • Page 351 C o m m i s s i o n i n g M a n u a l D e f i n i n g V L AN s The 802.1Q (VLAN) Configuration dialog box appears. Figure 14-17: 802.1Q (VLAN) Configuration dialog box 01040311-07 Airspan Networks Inc. 14-21...
  • Page 352 Priority: select the priority level (0 to 7, where zero is the lowest priority) Note: If you select the Management VLAN Enabled check box, only those management stations belonging to the defined VLAN can manage the SPR. 8. Click Apply, and then OK. 14-22 Airspan Networks Inc. 01040311-07...

  • Page 353: Defining Air Subnets

    Task 3: Define SPR's Air Subnet using WipConfig Task 4: Verify SPR's Air Subnet Address Task 5: Return PC's IP Settings for Connectivity with BSR Task 6: Add BSR and SPR in WipManage Task 7: View Air Subnets in WipManage 01040311-07 Airspan Networks Inc. 15-1...

  • Page 354: Overview

    C o m m i s s i o n i n g M a n u a l Notes: 1) Air Subnet addressing is relevant only when ASWipLL is operating in the IP router mode. 2) If using WipManage, change the SPR's Air Subnet address before changing the BSR’s Air Subnet address.
  • Page 355 The Economical mode provides the subnet address 255.255.255.252, thereby, providing a total of four IP addresses, where only two of the addresses can be used for ASWipLL devices: one for the BSR and one for the SPR. Not Economical: only for networks using RFC's 192.168.0.0 range. IP addresses of the Air subnet ports are fixed ranging from 192.168.0.0 to...
  • Page 356 Not Economical air subnetting address schemes. All other ranges can only use Economical air subnetting address schemes. 2) By default, ASWipLL uses air subnet addressing is according to RFC 1918 (i.e. IP addresses ranging from 192.168.0.0.) – Not Economical. 3) Airspan recommends using WipConfig to configure air subnet addressing scheme.

  • Page 357: Configuring Air Subnet Addresses For Private Networks

    The configuration example describes configuring the BSR and SPR from default settings to user-defined settings. The configuration setup example is illustrated in the figure below: Figure 15-3: Configuration setup example for Economical air subnet addressing scheme 01040311-07 Airspan Networks Inc. 15-5...

  • Page 358: Summary Of Tasks

    The first step is to define the BSR's air subnet scheme as Economical and in the 172.16.0.0 address range. The BSR is accessed using the BSR's default parameters (i.e. IP address 10.0.0.10). Thus, ensure that the PC 's IP addressing scheme provides 15-6 Airspan Networks Inc. 01040311-07...
  • Page 359 In the Remote Agent field, enter the BSR's default IP address, i.e. 10.0.0.10. On the toolbar, click the Connect button. WipConfig connects to the BSR, as displayed below. Air Subnet group Figure 15-5: WipConfig connected to BSR (using Not Economical mode) 01040311-07 Airspan Networks Inc. 15-7...
  • Page 360 A Warning message box appears, requesting you to confirm device reset. Figure 15-6: Warning message box for resetting BSR 10. Click Yes to reset the device. WipConfig losses connection with the BSR due to the BSR's new IP address. 15-8 Airspan Networks Inc. 01040311-07...

  • Page 361: Task 2: Verify Bsr's Air Subnet Address

    In the Remote Agent field, enter the BSR's IP address, e.g. 192.168.1.1. On the toolbar, click the Connect button. WipConfig connects to the BSR and shows the BSR's air subnet address configured for Economical mode and in the 172.16.0.0 range, as displayed below. 01040311-07 Airspan Networks Inc. 15-9...

  • Page 362: Task 3: Define Spr's Air Subnet Using Wipconfig

    The SPR is accessed using the SPR's default parameters (i.e. IP address 10.0.0.20) and by connecting the PC's LAN directly to the SPR (i.e. not via the BSR). Thus, you need to change the PC's Ethernet interface IP address so that it's in the same 15-10 Airspan Networks Inc. 01040311-07...
  • Page 363 In the Communication group, select Network. In the Remote Agent field, enter the SPR's default IP address, i.e. 10.0.0.20. On the toolbar, click the Connect button. WipConfig connects to the SPR and displays the Configuration parameters. 01040311-07 Airspan Networks Inc. 15-11...
  • Page 364 In the New Base field, enter only the network ID address, e.g. 172.16.0.0. In the Network Configuration group, enter the following fields: Eth IP Address: SPR’s IP address, e.g. 192.168.2.1 Eth Subnet Mask: SPR’s subnet address, e.g. 255.255.255.0 15-12 Airspan Networks Inc. 01040311-07...
  • Page 365 A Warning message box appears, requesting you to confirm device reset. Figure 15-9: Warning message box for resetting BSR 11. Click Yes to reset the device. WipConfig losses network connection with the SPR due to the SPR's new IP address. 01040311-07 Airspan Networks Inc. 15-13...

  • Page 366: Task 4: Verify Spr's Air Subnet Address

    Ensure that WipConfig is connected to the BSR by a local network connection. Start WipConfig. In the Communication group, select Network. In the Remote Agent field, enter the BSR's IP address, e.g. 192.168.1.1. On the toolbar, click the Connect button. 15-14 Airspan Networks Inc. 01040311-07...
  • Page 367 WipConfig connects to the SPR and shows the SPR's air subnet address configured for Economical mode and in the 172.16.0.0 range, as displayed below. Network ID of air subnet Economical scheme selected Figure 15-10: SPR configured for Economical mode in 172.16.0.0 range 01040311-07 Airspan Networks Inc. 15-15...

  • Page 368: Task 5: Return Pc's Ip Settings For Connectivity With Bsr

    To view air subnet addresses: In the WipManage main window, double-click the BSR icon. The BSR Zoom window appears. In the BSR Zoom window, from the Configuration menu, point to Network, and then choose Static Routing Table. 15-16 Airspan Networks Inc. 01040311-07...
  • Page 369 Figure 15-11: Static Routing Table dialog box 3. Click Advanced. The Air Subnet Configuration dialog box appears, displaying the configured air subnet address scheme (i.e. Economical) and the network ID (i.e. 172.16.0.0) on which the scheme is based. 01040311-07 Airspan Networks Inc. 15-17...
  • Page 370 Economical mode selected Figure 15-12: Air Subnet Configuration dialog box 4. Click Air Addresses. The Air Subnet Addresses window appears, listing the air subnet addresses of each consecutive SPR and the BSR. 15-18 Airspan Networks Inc. 01040311-07...
  • Page 371 SPR #3 is 172.16.0.10). This is because the Economical mode provides the subnet address 255.255.255.252, thereby, providing a total of four IP addresses (only two of the addresses can be used for ASWipLL devices: one for the BSR and one for the SPR).
  • Page 372 D e f i n i n g Ai r S u b n e t s C o m m i s s i o n i n g M a n u a l This page is intentionally left blank. 15-20 Airspan Networks Inc. 01040311-07...

  • Page 373: Defining Aswipll As A Dhcp Relay Agent

    Defining ASWipLL as a DHCP Relay Agent This chapter describes the procedures for configuring ASWipLL as a Dynamic Host Configuration Protocol (DHCP) relay agent, and includes the following sections: Overview Defining ASWipLL as a DHCP Relay Agent Note: DHCP Relay Agent configuration is relevant only when the ASWipLL system is configured for IP routing (i.e.

  • Page 374: Defining Aswipll As A Dhcp Relay Agent

    IP address. In order to do so within an IP routing environment, the IP routers have to support DHCP relay agent functionality. ASWipLL as an IP router is also a DHCP relay agent/server. 16.2. Defining ASWipLL as a DHCP Relay Agent You define a DHCP relay agent for BSRs.
  • Page 375 2. In the DHCP Server IP field, enter the IP address of the DHCP server, and then click OK. The following Notice message box appears: Figure 16-3: Notice message box 3. Click OK. The DHCP requests will now be forwarded to the designated DHCP server. 01040311-07 Airspan Networks Inc. 16-3...
  • Page 376 D e f i n i n g AS W i p L L a s a D H C P R e l a y Ag e n t C o m m i s s i o n i n g M a n u a l This page is intentionally left blank. 16-4 Airspan Networks Inc. 01040311-07...

  • Page 377: Defining Pppoe

    Task 5: Verify SPRs in PPPoE Mode Notes: 1) PPPoE configuration is relevant only when the ASWipLL system is configured for IP routing (i.e. not applicable for transparent bridging). 2) This chapter mentions the BSR and SPR devices. However, the BSR procedures are also applicable for PPR devices;...

  • Page 378: Overview

    MUST allocate the resources for a PPP virtual interface. The PPPoE method in ASWipLL is described below: The Data Terminal Equipment (DTE) client requests PPPoE service with a broadcast message to the SPR.
  • Page 379 A PPPoE data link tunnel is set up between the LAN client and the WAN server through the SPR and BSR air link. Figure 17-1: PPPoE process in the ASWipLL system Note: When you configure PPPoE for the BSR, you can configure some...

  • Page 380: Enabling Pppoe For Bsr And Associated Sprs

    17.2.2. Task 1: Select PPPoE Enabled Option for BSR The first task that you need to perform is to select the PPPoE Enable option (instead of the IP Filters Active option) to enable point-to-point over Ethernet in the BSR. 17-4 Airspan Networks Inc. 01040311-07...
  • Page 381 PPPoE/IP Filtering, as shown below. Figure 17-3: Choosing the PPPoE / IP Filtering command The PPPoE / IP Filters dialog box appears: Figure 17-4: PPPoE/IP Filtering dialog box showing device in IP Filters Active mode 01040311-07 Airspan Networks Inc. 17-5...

  • Page 382: Task 2: Reset The Bsr

    Figure 17-5: Reset confirmation box 2. Click Yes to confirm resetting the device. The Device Reset message box appears, as displayed below. Figure 17-6: Device Reset message box 3. Click OK to reset the device. 17-6 Airspan Networks Inc. 01040311-07...

  • Page 383: Task 3: Verify Bsr In Pppoe Mode

    PPPoE/IP Filtering. The PPPoE / IP Filters dialog box appears, displaying "PPPoE Enabled" in the Current Device Mode field, as shown below. PPPoE enabled Figure 17-7: Current Device Mode field displaying "PPPoE Enabled" 01040311-07 Airspan Networks Inc. 17-7...

  • Page 384: Task 4: Select Pppoe Enabled Option For Sprs

    BSR that is configured for PPPoE. To enable PPPoE for SPRs: In the BSR Zoom window, from the MultiDevices menu, point to Network, and then choose PPPoE/IP. The Multi SPRs PPPoE / IP Window dialog box appears: 17-8 Airspan Networks Inc. 01040311-07...
  • Page 385 Figure 17-8: PPPoE/IP Filtering dialog box showing device in IP Filters Active mode Select the SPRs that you want to configure for PPPoE with the BSR. Select the PPPoE Enabled option. Click Apply. 01040311-07 Airspan Networks Inc. 17-9...

  • Page 386: Task 5: Reset The Sprs

    5. Click Apply. 17.2.6. Task 5: Reset the SPRs After you have selected the PPPoE Enabled option for the SPRs in the previous task, you need to reset the SPRs for the configuration to take effect. 17-10 Airspan Networks Inc. 01040311-07...
  • Page 387 D e f i n i n g P P P o E To reset the SPRs: In the BSR Zoom window, from the MultiDevices menu, choose Reset. The Multi Reset Window dialog box appears, as displayed below. Figure 17-10: Reset confirmation box 01040311-07 Airspan Networks Inc. 17-11...
  • Page 388 Select the SPRs that you want to reset, and then click Apply. Figure 17-11: Multi Apply Confirmation message box 3. Click Apply. The Reset message box appears, as displayed below. Figure 17-12: Device Reset message box 4. Click Yes to reset the device. 17-12 Airspan Networks Inc. 01040311-07...

  • Page 389: Task 6: Verify Sprs In Pppoe Mode

    In the BSR Zoom window, from the MultiDevices menu, point to Network, and then choose PPPoE/IP. The Multi SPR PPPoE / IP Filters Window dialog box appears. "PPPoE Enabled" displayed Figure 17-13: Current Device Mode field displaying "PPPoE Enabled" 01040311-07 Airspan Networks Inc. 17-13...
  • Page 390 D e f i n i n g P P P o E C o m m i s s i o n i n g M a n u a l This page is intentionally left blank. 17-14 Airspan Networks Inc. 01040311-07...

  • Page 391: Configuring Bsr Antenna

    RF signal is received by the antenna (i.e. main/primary or secondary antenna) with the best RF signal. Notes: 1) The current ASWipLL release allows antenna configuration only in the Rx Mode. 2) Only the main antenna transmits.
  • Page 392 In the BSR Zoom window, in the workspace area, click the Antenna Configuration icon, -Or- From the Configuration menu, point to RF, and then choose Antenna Configuration, as shown below. Figure 18-1: Choosing the Antenna Configuration command 18-2 Airspan Networks Inc. 01040311-07...
  • Page 393 Diversity option is selected, the antenna with the best RF reception is used to receive the signal. Note: The Diversity option is available only when the BSR uses two internal antennas or two external antennas for dual-antenna diversity. 01040311-07 Airspan Networks Inc. 18-3...
  • Page 394 C o n f i g u r i n g B S R An t e n n a C o m m i s s i o n i n g M a n u a l This page is intentionally left blank. 18-4 Airspan Networks Inc. 01040311-07...

  • Page 395: Configuring Radio Transmit Power

    Configuring Radio Transmit Power This chapter provides procedures for configuring ASWipLL radio transmit power, and includes the following sections: Overview Defining BSR Transmit Power Summary of Tasks Task 1: Define the BSR Power Level Task 2: Reset the BSR Configuring BSR Control over SPR Transmit Power...

  • Page 396: Overview

    19.1. Overview WipManage allows you to configure maximum radio transmit (Tx) power levels for each ASWipLL radio (i.e. BSR and SPR). In addition, you can allow the BSR to control the SPR's transmit power levels to ensure viable BSR-SPR wireless communication at minimum SPR transmit power levels.

  • Page 397: Defining Bsr Transmit (Tx) Power

    SPR/IDR transmit power configuration, but performed in the SPR Zoom window. 19.2.1. Summary of Tasks The figure below displays a flowchart for configuring transmit power level for a BSR. Figure 19-1: Flowchart for configuring BSR's transmit power level 01040311-07 Airspan Networks Inc. 19-3...

  • Page 398: Task 1: Define The Bsr Power Level

    Figure 19-2: BSR Power Settings dialog box Regularity Domain: (read from the device’s ROM and are read-only) displays the regularity domain that the ASWipLL unit supports (e.g. FCC). A flag of the country is displayed where the regularity domain is associated.
  • Page 399 + 6) is achieved. Notes: 1) ASWipLL 900 MHz is capable of transmitting up to 30 dBm. 2) In accordance with FCC regulations, ASWipLL 900 transmit power is limited to 23 dBm in the 4 Mbps mode, and 18 dBm in the 3 Mbps mode.

  • Page 400: Task 2: Reset The Bsr

    Once you have defined the BSR's power level, you need to reset the BSR. To reset the BSR: In the BSR Zoom window, from the Configuration menu, choose Reset. Figure 19-4: Reset confirmation box 2. Click Yes. Figure 19-5: Device Reset information box 3. Click Ok. 19-6 Airspan Networks Inc. 01040311-07...

  • Page 401: Configuring Bsr Control Over Spr Transmit Power

    Note: Power control is not supported by some hardware revisions in the 3.x GHz BSRs/SPRs. 19.3.1. Summary of Tasks The figure below displays a flowchart for configuring BSR power control over the SPR. Figure 19-6: Flowchart for configuring BSR power control of SPR 01040311-07 Airspan Networks Inc. 19-7...

  • Page 402: Task 1: Enable Bsr Power Management For Sprs

    1. In the BSR Zoom window, from the MultiDevices menu, point to RF, and then choose Power Settings. Check boxes selected for Desired SPR RSS level Check box selected for Figure 19-7: MultiDevice Power Settings dialog box 2. Click Select All to select all the SPRs. 19-8 Airspan Networks Inc. 01040311-07...
  • Page 403 In the BSR group, select the Power Management Mode Active check box. Click Apply. Figure 19-8: Multi Apply confirmation box 6. Select the Apply Changes to All SPRs and Apply Also BSR Device options, and then click Apply. Figure 19-9: Notice message box 7. Click Ok. 01040311-07 Airspan Networks Inc. 19-9...

  • Page 404: Task 2: Reset The Sprs

    Once you have configured BSR power control of the SPRs, you need to reset the SPRs. To reset the SPRs: In the BSR Zoom window, from the MultiDevices menu, choose Reset. Figure 19-10: Multi Reset dialog box 19-10 Airspan Networks Inc. 01040311-07...
  • Page 405 C o n f i g u r i n g R a d i o T r a n s m i t P o w e r 2. Click Select All, and then Apply. Figure 19-11: Multi Apply confirmation box 3. Click Apply. Figure 19-12: Reset confirmation box 4. Click Yes. 01040311-07 Airspan Networks Inc. 19-11...

  • Page 406: Task 3: Verify Bsr Power Control Is Enabled

    Figure 19-13: Verifying BSR power management is enabled As can be seen in the figure above, the BSR power management is enabled, which indicated by the following fields: Per Power Mng Mode: displays YES Power Mng Mode: displays YES 19-12 Airspan Networks Inc. 01040311-07...

  • Page 407: Managing Frequency Tables

    Managing Frequency Tables This chapter describes the procedures for managing the ASWipLL system’s frequencies, and includes the following sections: Overview Considerations for Frequency Allocation ROM Frequency Tables Defining NVRAM Frequency Table for BSR-SPRs Wireless Communication Summary of Tasks Task 1: Add Normal Frequency Table for BSR...

  • Page 408: Overview

    C o m m i s s i o n i n g M a n u a l 20.1. Overview The ASWipLL system provides up to 64 frequency tables, each table consisting of up to 97 frequencies. The first 32 (0 to 31) frequency tables are stored in the ASWipLL device's read-only memory (ROM);...
  • Page 409 F5, F1, F2, F3, F4, F5 (i.e. at least 9 entries -- in this case 10 entries to complete the series). 4) For BSDU synchronization of BSRs, you need to enter at least 11 frequency hops. 01040311-07 Airspan Networks Inc. 20-3...

  • Page 410: Considerations For Frequency Allocations

    BSR #1 transmits on 3725 MHz − BSR #2 transmits on 3729 MHz − Unlicensed bands (multiple orthogonal frequencies used for frequency hopping): FDD: ensure minimum separation of 2 MHz TDD: ensure minimum separation of 4 MHz 20-4 Airspan Networks Inc. 01040311-07...
  • Page 411 BSRs with adjacent and overlapping sectors. Note: In all ASWipLL bands, the frequency spacing is 1 MHz. However, in ASWipLL 3.x GHz the frequency spacing can be 1 MHz or 1.75 MHz (the spacing, which is factory set, is determined by Airspan).

  • Page 412: Rom Frequency Tables

    To view the ROM frequency tables: From the Configuration menu, point to RF, and then choose ROM Frequency Table. The ROM Frequency Tables window appears, as displayed in Figure 20-1. Figure 20-1: ROM Frequency Tables window 20-6 Airspan Networks Inc. 01040311-07...
  • Page 413 (i.e. Table 0, Table 1, Table 2, and so on). The RF Type field (read-only) displays the frequency band in which the ASWipLL system is operating. The Frequency Table ID field (read-only) displays the frequency table that the BSR is using.

  • Page 414: Defining Nvram Frequency Table For Bsr-To-Sprs Wireless Communication

    2,468 MHz, with 3 MHz gap between each consecutive frequency. 20.2.1. Summary of Tasks The figure below displays a flowchart for configuring a frequency table for BSR-to- SPRs wireless communication. Figure 20-2: Flowchart for adding an NVRAM frequency table to BSR and SPRs 20-8 Airspan Networks Inc. 01040311-07...

  • Page 415: Task 1: Add Frequency Table For Bsr

    In the BSR Zoom window (of BSR 10.0.0.10), from the Configuration menu, point to RF, and then click NVRAM Frequency Tables. 2. In the NVRAM Frequency Tables dialog box, click Add. The Frequency Tables Add dialog box appears, as displayed in Figure 20-3. 01040311-07 Airspan Networks Inc. 20-9...
  • Page 416 In the Valid Frequencies pane (i.e. right pane), select the desired frequency, and then click the left-pointing arrow button to add the frequency to the Frequency Table pane (i.e. left pane). For example, 2402, 2405, 2408, 2411, 2414, 1417, 2420, 2423, 2426, 2429, and 2432. 20-10 Airspan Networks Inc. 01040311-07...
  • Page 417 Frequency table appears in the Frequency Tables dialog box, as displayed below. Added frequency table ID 32 Frequencies (total of 23) Frequency table ID (0) currently used Figure 20-4: Added NVRAM frequency table (ID 32) 01040311-07 Airspan Networks Inc. 20-11...

  • Page 418: Task 2: Add Frequency Table For Spr

    RF, and then click NVRAM Frequency Tables; The NVRAM Frequency Tables dialog box appears. 2. In the NVRAM Frequency Tables dialog box, click Add. The Frequency Tables Add dialog box appears, as displayed in Figure 20-3. 20-12 Airspan Networks Inc. 01040311-07...
  • Page 419 In the Insert New Table To field, enter the frequency table’s index number (32 to 63), e.g. 32. (If you do not enter a number, WipManage automatically assigns it the next available consecutive Frequency Table number.) 01040311-07 Airspan Networks Inc. 20-13...
  • Page 420 6. Click OK. The Frequency Tables Add dialog box closes, and the new Frequency table appears in the Frequency Tables dialog box, as displayed below. Added frequency table ID 32 Frequencies (total of 23) Frequency table ID (0) currently used Figure 20-6: Added NVRAM frequency table (ID 32) 20-14 Airspan Networks Inc. 01040311-07...

  • Page 421: Task 3: Assign Identical Frequency Table To Multiple Sprs

    In the BSR Zoom window, from the MultiDevices menu, point to RF, and then choose Frequency Tables. The Multi SPRs Frequency Tables dialog box appears, listing all the SPRs associated with the BSR, and the frequency tables of a selected SPR, as displayed in Figure 20-7. 01040311-07 Airspan Networks Inc. 20-15...
  • Page 422 Hashed Table value of SPR 10.0.0.20 is 159710956, and of SPR 10.0.0.36 is 0. The selected SPR’s NVRAM Frequency table appears in the Frequency Tables list, located in the upper pane. Click Apply. The Multi-Apply Confirmation box appears, as displayed below. 20-16 Airspan Networks Inc. 01040311-07...
  • Page 423 SPR 10.0.0.20). If you click on any SPR in the list, the same frequency table will appear in the upper pane, i.e. Frequency Table index 32. Identical Hashed Table values Figure 20-9: SPRs assigned identical NVRAM Frequency tables 01040311-07 Airspan Networks Inc. 20-17...

  • Page 424: Task 4: Specify Operating Frequency Table Id

    ID that you added to the BSR and SPRs (i.e. ID #32). Click Apply. The following message box appears. Figure 20-11: Message box informing to reset device for changes to take affect 4. Click OK, and then click Close to close the Hopping Configuration dialog box. 20-18 Airspan Networks Inc. 01040311-07...

  • Page 425: Task 5: Reset The Bsr

    BSR. To reset the BSR: In the BSR Zoom window, from the Configuration menu, choose Reset. Figure 20-12: Reset confirmation box 2. Click Yes. Figure 20-13: Device Reset confirmation box 3. Click Ok. 01040311-07 Airspan Networks Inc. 20-19...
  • Page 426 M a n a g i n g F r e q u e n c y T a b l e s C o m m i s s i o n i n g M a n u a l This page is intentionally left blank. 20-20 Airspan Networks Inc. 01040311-07...

  • Page 427: Defining Synchronization

    Defining Synchronization This chapter describes procedures for synchronizing an ASWipLL Base Station and includes the following section: Overview Synchronizing a Base Station Summary of Tasks Task 1: Enable GPS Task 2: Reset BSDU Task 3: Verify GPS Synchronization Task 4: Define Synchronization for BSDUs...

  • Page 428: Overview

    Station synchronization to prevent adjacent channel interference between Base Stations. Synchronization in the ASWipLL system is controlled by the BSDU and is based on frequency hopping that is used in BSR-SPR wireless communication. The same frequency table used for BSR-SPR communication is used for this synchronization.
  • Page 429 BSDUs, the BSRs transmit on the following frequencies: 2402 for BSR #1; 2411 for BSR #2; 2420 for BSR #3; and 2414 for BSR #4. Notes: 1) Synchronization is applicable only when ASWipLL implements frequency hopping for wireless communication. 2) Synchronization is available depending on the regularity domain in which the ASWipLL devices are operating.

  • Page 430: Synchronizing A Base Station

    The following subsections describe the procedures for synchronizing a Base Station consisting of two BSRs, two BSDUs, and a GPS connected to one of the BSDUs, as displayed in the figure below. Figure 21-1: Configuration example for synchronizing a Base Station 21-4 Airspan Networks Inc. 01040311-07...

  • Page 431: Summary Of Tasks

    D e f i n i n g S y n c h r o n i z a t i o n 21.2.1. Summary of Tasks The flowchart below displays a summary of tasks for configuring synchronization at a Base Station. Figure 21-2: Flowchart for synchronizing a Base Station 01040311-07 Airspan Networks Inc. 21-5...

  • Page 432: Task 1: Enable Gps

    From the Configuration menu, choose GPS. The GPS dialog box appears, as displayed below. Figure 21-3: Enabling GPS Select the Enable GPS check box to enable the GPS. Click OK. Reset the BSDU. 21-6 Airspan Networks Inc. 01040311-07...

  • Page 433: Task 2: Reset Bsdu

    In the BSDU Zoom window (of BSDU 10.0.0.5), from the Configuration menu, choose Reset. The GPS dialog box appears, as displayed below: Figure 21-4: Reset confirmation box 2. Click Yes. Figure 21-5: Device Reset confirmation box 3. Click OK. 01040311-07 Airspan Networks Inc. 21-7...

  • Page 434: Task 3: Verify Gps Synchronization

    In the BSDU Zoom window (of BSDU 10.0.0.5), from the Configuration menu, choose GPS. The GPS dialog box appears, as displayed below: Figure 21-6: Verifying GPS is enabled The GPS dialog box indicates that the GPS is synchronizing the ASWipLL system by the following indications: Enable GPS: selected GPS Powered On: displays "YES"...

  • Page 435: Task 4: Define Synchronization For Bsdus

    BSDU automatically controls synchronization. Notes: 1) Ensure BSDU synchronization ports are connected between BSDUs. For a detailed description on cabling these ports, refer to the ASWipLL Hardware Installation Guide. 2) Ensure identical frequency table size is configured for all BSDUs.
  • Page 436 BSR-SPR communication (e.g. 23). Select the Synchronization Ring Mode On check box. In the Synchronization Ring ID field, enter an arbitrary identification number (0 through 15) for this BSDU in the daisy chain (e.g. 8). 21-10 Airspan Networks Inc. 01040311-07...
  • Page 437 Perform Steps 1 through 8 for BSDU 10.0.0.6. The Hopping Configuration BSDU dialog box for BSDU 10.0.0.6 is displayed below, showing its Ring ID defined as 5: Figure 21-8: Synchronization defined for BSDU 10.0.0.6 (ring ID 5) 01040311-07 Airspan Networks Inc. 21-11...

  • Page 438: Task 5: Reset The Bsdus

    After you have configured the BSDUs' synchronization parameters, you need to reset the BSDUs. To reset the BSDUs: 1. In the WipManage Main window, from the MultiDevices menu, point to BSDUs, and then choose Reset. Figure 21-9: Multi BSDU Reset dialog box 21-12 Airspan Networks Inc. 01040311-07...
  • Page 439 D e f i n i n g S y n c h r o n i z a t i o n 2. Click Select All, and then click Apply. Figure 21-10: Reset confirmation box 3. Click Yes. 01040311-07 Airspan Networks Inc. 21-13...

  • Page 440: Task 6: Verify Bsdu Synchronization

    Once you have configured BSDU synchronization, you can verify that these synchronization settings have been applied. To verify BSDU synchronization: In the WipManage Main window, from the MultiDevices menu, point to BSDUs, then to RF, and then choose Hopping Configuration. Figure 21-11: Verifying BSDU synchronization 21-14 Airspan Networks Inc. 01040311-07...
  • Page 441 BSDU is the master unit Only left LED on BSDU is a slave unit Both LEDs off BSDU sync pulse lost Blinking Receiving a satellite signal HSP P (hop Change state for the HSP pulse Green synchronization process pulse) 01040311-07 Airspan Networks Inc. 21-15...

  • Page 442: Task 7: Enable Bsr Synchronization

    RF, and then choose Hopping Configuration. The Hopping Configuration dialog box appears. Select the Synchronization Ring Mode On check box. The following appears: Figure 21-12: Enabling synchronization for BSR 10.0.0.10 (phase = 1) 21-16 Airspan Networks Inc. 01040311-07...
  • Page 443 Perform Steps 1 through 6 for BSR 10.0.0.14. The Hopping Configuration dialog box for BSR 10.0.0.14 is displayed below, showing its Synchronization Ring Phase field value defined as 4: Figure 21-13: Enabling synchronization for BSR 10.0.0.14 (phase = 4) 01040311-07 Airspan Networks Inc. 21-17...

  • Page 444: Task 8: Reset Bsrs

    To apply the BSR synchronization settings, you need to reset the BSRs. To reset the BSRs: In the WipManage Main window, from the MultiDevices menu, point to BSRs, and then choose Reset. Figure 21-14: Multi BSR Reset dialog box 21-18 Airspan Networks Inc. 01040311-07...
  • Page 445 D e f i n i n g S y n c h r o n i z a t i o n 2. Click Select All, and then Click Apply. Figure 21-15: Reset confirmation box 3. Click Yes. 01040311-07 Airspan Networks Inc. 21-19...

  • Page 446: Task 9: Verify Bsrs Synchronization

    Once you have enabled BSRs synchronization, you can verify that the BSRs are synchronized by the BSDU. To verify BSRs synchronization: In the WipManage Main window, from the MultiDevices menu, point to BSRs, then to RF, and then choose Hopping Configuration. Figure 21-16: Verifying BSR synchronization 21-20 Airspan Networks Inc. 01040311-07...
  • Page 447 Sync. Ring Phase: index of frequency (in the frequency table) for transmitting at every synchronization pulse received from the BSDU. For BSR 10.0.0.10 this is "1"; for BSR 10.0.0.14 this is "4". Sync. To Master ID: BSDU controlling synchronization (i.e. Master BSDU ID "8") 01040311-07 Airspan Networks Inc. 21-21...
  • Page 448 D e f i n i n g S y n c h r o n i z a t i o n C o m m i s s i o n i n g M a n u a l This page is intentionally left blank. 21-22 Airspan Networks Inc. 01040311-07...

  • Page 449: Defining Transmission Rate

    Defining Transmission Rate This chapter describes the procedures for defining transmission rate in the ASWipLL system. This chapter includes the following sections: Overview Defining Maximum Rate Mode Summary of Tasks Task 1: Define Maximum Rate Mode Task 2: Reset the SPRs/IDRs...

  • Page 450: Overview

    WipManage also allows you to define various rate options, which includes the following: Allowing the ASWipLL system to operate either at a fixed rate regardless of radio conditions, or at an adjustable rate according to radio conditions of each SPR and IDR.

  • Page 451: Defining Maximum Rate Mode

    BSR and its associated SPRs from 3 Mbps to 4 Mbps. Any modification to maximum rate mode requires resetting the BSR and SPR/IDR devices. Figure 22-1: Configuration example for defining maximum rate mode 01040311-07 Airspan Networks Inc. 22-3...

  • Page 452: Summary Of Tasks

    22.2.1. Summary of Tasks The flowchart in the figure below displays a summary of tasks for changing the maximum rate mode for the BSR and its associated SPRs. Figure 22-2: Flowchart for defining maximum rate mode 22-4 Airspan Networks Inc. 01040311-07...

  • Page 453: Task 1: Define Maximum Rate Mode

    In the BSR Zoom window, from the MultiDevices menu, choose Rate; The Multi Rate Window dialog box appears, as displayed below: Max Mode list for BSR Max Mode list for SPR Figure 22-3: Selecting a different maximum rate mode 01040311-07 Airspan Networks Inc. 22-5...

  • Page 454: Task 2: Reset The Sprs/Idrs

    22.2.3. Task 2: Reset the SPRs/IDRs After changing the SPR/IDR maximum rate mode, you need to reset the SPRs/IDRs. Note: Reset the SPRs/IDRs before resetting the BSR to ensure that the BSR- SPRs/IDRs network communication link is retained. 22-6 Airspan Networks Inc. 01040311-07...
  • Page 455 In the BSR Zoom window, from the MultiDevices menu, choose Reset; The Multi Reset Window dialog box appears, as displayed below: Figure 22-4: Multi Reset dialog box Select all the SPRs/IDRs, and then click Apply. 01040311-07 Airspan Networks Inc. 22-7...
  • Page 456 The Multi Apply Confirmation Window confirmation box appears, as displayed below: Figure 22-5: Multi Apply confirmation box 3. Click Apply; The Reset confirmation box appears, as displayed below: Figure 22-6: Reset confirmation box 4. Click Yes. 22-8 Airspan Networks Inc. 01040311-07...

  • Page 457: Task 3: Reset The Bsr

    Figure 22-7: Reset confirmation box 2. Click Yes to confirm resetting the device; The Device Reset message box appears, as displayed below. Figure 22-8: Device Reset message box 3. Click OK to reset the device. 01040311-07 Airspan Networks Inc. 22-9...

  • Page 458: Defining Transmission Rate Options

    C o m m i s s i o n i n g M a n u a l 22.3. Defining Transmission Rate Options Once you have configured the maximum rate mode of your ASWipLL system, WipManage enables you to select various transmission rate parameters controlled by and configured at your BSR.
  • Page 459 1, 2, and 3 Mbps. Click OK. Note: The Broadcast Rate group is available only when the ASWipLL device is configured in the bridge mode and the Automatic Rate Adjustment option is selected in the Rate Mode group.
  • Page 460 D e f i n i n g T r a n s m i s s i o n R a t e C o m m i s s i o n i n g M a n u a l This page is intentionally left blank. 22-12 Airspan Networks Inc. 01040311-07...

  • Page 461: Defining Security

    Defining Security This chapter describes the procedures for defining ASWipLL security settings, and includes the following sections: Overview Defining Management Stations Defining SNMP Read/Write Community Strings Defining Public-Key Encryptions Adding IP Filters Defining IntraComm Gateways Note: This chapter mentions the BSR and SPR devices. However, the BSR procedures are also applicable for PPR devices;...

  • Page 462: Overview

    Managers Table. WipManage station rights: WipManage station rights for managing the ASWipLL device, i.e. read (Get) and write (Set) SNMP community strings. Public-key encryptions: defines public and private encryption keys for the BSR and SPR respectively. The encryption settings are defined for a BSR and its associated SPRs for encryption/decryption.

  • Page 463: Defining Management Stations

    BSR. This procedure is similar to adding management stations for the other devices. To add management stations (e.g. for a BSR): In the BSR Zoom window, from the Configuration menu, choose Managers Table. The Managers Table dialog box appears. Figure 23-1: Managers Table dialog box 01040311-07 Airspan Networks Inc. 23-3...

  • Page 464: Defining Snmp Read/Write Community Strings

    Zoom windows (i.e. BSR Zoom, SPR Zoom, and BSDU Zoom window respectively). The following subsections describe the procedures for defining SNMP read/write community strings for a BSR. 23-4 Airspan Networks Inc. 01040311-07...

  • Page 465: Summary Of Tasks

    You first need to access the BSR (using the default community strings), and then modify the BSR's SNMP read/write community strings. By default, WipManage assigns public and private to read and write community strings respectively. 01040311-07 Airspan Networks Inc. 23-5...
  • Page 466 In the Trap Community field, define the SNMP community string of the BSR traps. This is relevant only for third-party SNMP external management stations (e.g. HP OpenView); WipManage management stations receive traps regardless of community string. 23-6 Airspan Networks Inc. 01040311-07...
  • Page 467 Click OK. Figure 23-5: Defined SNMP strings Warning: If you have enabled ("On") the Manager Mode, before closing the BSR Zoom window, ensure that you have defined a management station (see Section 23.2, "Defining Management Stations". 01040311-07 Airspan Networks Inc. 23-7...

  • Page 468: Task 2: Verify Bsr's Snmp Read/Write Strings

    2) To verify the SPR's read/write community settings, in the BSR Zoom window, right-click the SPR index icon, and then from the shortcut menu choose Edit. Verify the settings in the Get and Set Community fields. 23-8 Airspan Networks Inc. 01040311-07...

  • Page 469: Defining Public-Key Encryptions

    Private) must be identical for the BSR and SPR. 23.4.1. Summary of Tasks The figure below displays a flowchart for configuring key encryption-based security for a BSR and its associated SPR. Figure 23-7: Flowchart for defining public-key encryption 01040311-07 Airspan Networks Inc. 23-9...

  • Page 470: Task 1: Enable Encryption-Based Security

    Air Protocol Security. The Security Configuration dialog box appears. Figure 23-8: Security Configuration dialog box From the Encryption Mode drop-down list, enable encryption by selecting Enable. In the Public Key field, enter the BSR's public key. Click Apply. 23-10 Airspan Networks Inc. 01040311-07...

  • Page 471: Task 2: Reset The Bsr

    The Device Reset message box appears, as displayed below. Figure 23-10: Device Reset message box 3. Click OK to reset the device. Note: Verify that key-encryption is enabled, by ensuring that the Encryption Mode field in the Security Configuration dialog box displays Enabled. 01040311-07 Airspan Networks Inc. 23-11...

  • Page 472: Task 3: Define Spr's Private Key

    In the SPR Zoom window, from the Configuration menu, point to Security, and then choose Air Protocol Security. The Security Configuration dialog box appears. Figure 23-11: Security Configuration dialog box In the Private Key field, enter the private key value (e.g. 170). Click Apply. 23-12 Airspan Networks Inc. 01040311-07...

  • Page 473: Task 4: Reset The Spr

    Once you have defined the SPR's private key, you need to reset the SPR. To reset the SPR: In the SPR Zoom window, from the Configuration menu, choose Reset. The Reset confirmation box appears, as displayed below. Figure 23-12: Reset confirmation box 2. Click Yes to confirm reset. 01040311-07 Airspan Networks Inc. 23-13...

  • Page 474: Adding Ip Filters

    You can assign IP filters according to protocol type (i.e. TCP and UDP), and source and destination IP addresses. You can define a range of addresses and ports to permit and deny traffic for passing through the ASWipLL system. A BSR can use up to 28 different filtering rules.

  • Page 475: Task 1: Enable Ip Filtering

    From the Configuration menu, point to Network, and then choose PPPoE / IP Filtering. The PPPoE / IP Filters dialog box appears. Figure 23-14: PPPoE / IP Filtering dialog box 3. Select the IP Filters Active option as displayed in the figure above, and then click OK. 01040311-07 Airspan Networks Inc. 23-15...

  • Page 476: Task 2: Reset The Bsr

    Figure 23-15: Reset confirmation box 2. Click Yes to confirm resetting the device. The Device Reset message box appears, as displayed below. Figure 23-16: Device Reset message box 3. Click OK to reset the device. 23-16 Airspan Networks Inc. 01040311-07...

  • Page 477: Task 3: Verify Bsr In Ip Filtering Mode

    In the BSR Zoom window, from the Configuration menu, point to Network, and then choose PPPoE/IP Filtering. The PPPoE / IP Filters dialog box appears, as displayed below. Figure 23-17: Current Device Mode field displaying "IP Filters Active" 01040311-07 Airspan Networks Inc. 23-17...

  • Page 478: Task 4: Add Bsr Ip Filtering Rules

    To add an IP filter for blocking FTP packets: In the BSR Zoom window, from the Configuration menu, point to Network, and then choose IP Filtering. The IP Filtering dialog box appears. Figure 23-18: IP Filtering dialog box 23-18 Airspan Networks Inc. 01040311-07...
  • Page 479 From the Protocol Type drop-down list, select TCP (i.e. for FTP). From the Port Number drop-down list, select Specific, and then in the field that appears, enter the port number 21 (i.e. port for FTP). 01040311-07 Airspan Networks Inc. 23-19...
  • Page 480 Note: Source and destination refers to packets that are received by the BSR (from WAN side or SPR side) and sent by the BSR (to WAN side or SPR side), respectively. d. Select the Deny option to discard all packets defined in the above steps. 23-20 Airspan Networks Inc. 01040311-07...
  • Page 481 D e f i n i n g S e c u r i t y 4. Click Apply. The IP filter appears in the IP Filtering table, as displayed below. Figure 23-20: Added IP filter appearing in the IP Filtering table blocking FTP traffic 01040311-07 Airspan Networks Inc. 23-21...

  • Page 482: Task 5: Enable Ip Filtering For Spr

    The SPR Zoom window appears. From the Configuration menu, point to Network, and then choose PPPoE / IP. The PPPoE/IP dialog box appears. Figure 23-21: PPPoE/IP dialog box 3. Select the IP Filters Active option, and then click OK. 23-22 Airspan Networks Inc. 01040311-07...

  • Page 483: Task 6: Reset The Spr

    IP Filtering. The IP Filtering dialog box appears. Click Add. The IP Filtering Table – Add dialog box appears. See Section 23.5.5, "Task 4: Add BSR IP Filtering " for defining the SPR IP filtering parameters. 01040311-07 Airspan Networks Inc. 23-23...

  • Page 484: Defining Intracomm Gateways

    SPR #1 is routed to Gateway #1, and SPR #2 is routed to Gateway #2, despite the fact that both SPR #1 and SPR #2 belong to the same VLAN (i.e. VLAN 60). 23-24 Airspan Networks Inc. 01040311-07...

  • Page 485: Summary Of Tasks

    The flowchart in the figure below displays a summary of tasks for assigning IP filtering among SPRs using third-party external routers (i.e. IntraComm gateways). Figure 23-24: Flowchart for assigning IP filtering among SPRs using third-party external routers (i.e. IntraComm gateways 01040311-07 Airspan Networks Inc. 23-25...

  • Page 486: Task 1: Select Intracomm Gateway Option

    From the Configuration menu, point to Network, and then choose Multiple Gateway Mode. The IntraComm dialog box appears. Figure 23-25: IntraComm dialog box Select the IntraComm Gateway Mode option. Click Apply, and then click OK. 23-26 Airspan Networks Inc. 01040311-07...

  • Page 487: Task 2: Reset The Bsr

    BSR to apply the setting. To reset the BSR: In the BSR Zoom window, from the Configuration menu, choose Reset. The Reset confirmation box appears, as displayed below. Figure 23-26: Reset confirmation box 2. Click Yes to confirm reset. 01040311-07 Airspan Networks Inc. 23-27...

  • Page 488: Task 3: Define Gateway Ip Address Per Spr

    The Permitted SPRs – Edit dialog box appears. Figure 23-27: Permitted SPRs – Edit dialog box In the Intra Comm. GW field, enter the IP address of the third-party external router/gateway that the SPR uses to communicate with other SPRs. Click OK. 23-28 Airspan Networks Inc. 01040311-07...

  • Page 489: Defining Quality Of Service

    Task 1: Define QoS for IP Addresses of SIP Server and Softswitch Task 2: Configure DiffServ Tagging for RGW Task 3: Map DiffServ Tags to ASWipLL Prioritization at BSR and SPR Note: This chapter mentions the BSR and SPR devices. However, the BSR procedures are also applicable for PPR devices;...

  • Page 490: Overview

    C o m m i s s i o n i n g M a n u a l 24.1. Overview ASWipLL provides end-to-end Quality of Service (QoS) for the ASWipLL network. This proprietary QoS relates to internal traffic between the BSR and SPR. Once traffic exits to the WAN, the original QoS settings of the packet are used (except for QoS for IP addresses).
  • Page 491 802.1p and DiffServ/TOS bits: ASWipLL allows you to cross-map (i.e. customize) packets with 802.1p and DiffServ/TOS prioritization levels and assign them to ASWipLL's internal QoS priority levels. For example, you can define that for DiffServ/TOS priority level 1, ASWipLL will assign its own priority level of 2.
  • Page 492 C o m m i s s i o n i n g M a n u a l ASWipLL assigns QoS to this traffic based on the following two parameters: Class (traffic priority): Range 0 through 6. Class determines the relevant importance of a packet: the higher the class, the higher the importance.

  • Page 493: Defining Qos For Data

    UDP transport protocol and uses port 69. Assigning a higher QoS priority to TFTP packets over standard data packets is important for remote download of software files by TFTP to ASWipLL devices. This provides TFTP packets a reliable and unobstructed flow to ASWipLL devices.
  • Page 494 C o m m i s s i o n i n g M a n u a l The following dialog box appears: Figure 24-3: Quality of Service window 2. Click the Applications tab. 24-6 Airspan Networks Inc. 01040311-07...
  • Page 495 TFTP application to the QoS Application tab. The QoS Applications Policy – Add dialog box appears with the Transport Protocol and Port fields displaying the TFTP definitions, as shown below. Figure 24-5: QoS Applications Policy Add dialog box 01040311-07 Airspan Networks Inc. 24-7...
  • Page 496 In the Stamp field, enter a time stamp value (e.g. 1,000 ms). From the Class drop-down list, select a priority level (e.g. 2). Click OK. TFTP application added to BSR's QoS configuration Figure 24-6: QoS defined for TFTP applications 24-8 Airspan Networks Inc. 01040311-07...

  • Page 497: Defining Qos For Voip

    802.1p: WipManage allows you to convert standard QoS priority levels into an ASWipLL customized priority class. This ASWipLL priority is based on VLANs. Therefore, the RGW at the subscriber’s premises must support VLAN and perform 802.1p tagging. The incoming VLAN tagged packet has a field...

  • Page 498: Summary Of Tasks

    24.3.1. Summary of Tasks This section describes the procedures for configuring QoS for VoIP based on DiffServ/TOS tagging to ensure the ASWipLL system assigns the highest QoS for VoIP packets. This QoS configuration is based on the following network scenario: SIP server (e.g.

  • Page 499: Task 1: Define Qos For Ip Addresses Of Sip Server And Softswitch

    SPR) while the QoS for the SPR refers to the destination IP address (i.e. traffic destined to BSR). Therefore, the procedure below describes the QoS setting for the SPR. Simply perform the same at the BSR. 01040311-07 Airspan Networks Inc. 24-11...
  • Page 500 In the SPR Zoom window, from the Configuration menu, choose QoS. The Quality of Service dialog box appears. Figure 24-9: Choosing the QoS command Select the IP Addresses tab. Click Add. Figure 24-10: Adding QoS for IP address 10.0.0.1 (i.e. SIP server) 24-12 Airspan Networks Inc. 01040311-07...
  • Page 501 Repeat steps 1 through 7 for configuring QoS for the softswitch's IP address (i.e. 10.0.0.2), but enter a stamp of 200 ms and class of (4) Media, as displayed below. Figure 24-11: Adding QoS for IP address 10.0.0.2 (i.e. softswitch) 01040311-07 Airspan Networks Inc. 24-13...

  • Page 502: Task 2: Configure Diffserv Tagging For Rgw

    Zoom window: Configuration menu > QoS command > IP Addresses tab). 24.3.3. Task 2: Configure DiffServ Tagging for RGW Configure your third-party residential gateway (RGW) so that it assigns a different DiffServ tag for voice data and for signaling. 24-14 Airspan Networks Inc. 01040311-07...

  • Page 503: Task 3: Map Diffserv Tags To Aswipll Prioritization Scheme

    24.3.4. Task 3: Map DiffServ Tags to ASWipLL Prioritization Scheme You need to enable ASWipLL to recognize and assign appropriate QoS to the DiffServ tagging that you configured for the RGW for voice data and for voice signaling. You need to configure this for both the BSR and the SPR, thereby, ensuring QoS in both the downlink and uplink.
  • Page 504 C o m m i s s i o n i n g M a n u a l QoS for DiffServ tagging for voice signaling QoS for DiffServ tagging for voice data Figure 24-13: Mapping of DiffServ tagging to ASWipLL prioritization 4. Click Set. Note: Configure the same QoS configurations for the BSR (i.e. in the BSR Zoom window: Configuration menu >...

  • Page 505: Managing Traps

    As a Simple Network Management Protocol (SNMP)-based application, WipManage can receive traps generated internally by WipManage and generated by ASWipLL devices. Each ASWipLL device contains an SNMP agent (residing on the device) that collects and stores the device's data (e.g. configuration parameter settings) in a management database type called Management Information Base (MIBs).

  • Page 506: Defining Management Stations

    25.2. Defining Management Stations Up to five management stations can be defined for receiving traps. These stations need to be defined per ASWipLL device type (i.e. BSR, BSDU, and SPR/IDR). Management stations are defined by IP address. You can also define the trap SNMP community string per device that you want the management station to receive.
  • Page 507 2. Click Add. The Manager Entry - Add dialog box appears, as displayed below. Figure 25-2: Adding a manager In the IP Address field, enter the IP address of the WipManage interface configured for the computer on which WipManage is running. Click OK. 01040311-07 Airspan Networks Inc. 25-3...

  • Page 508: Enabling Trap Display In Wipmanage

    In the WipManage main window, from the Tools menu, choose Environment Settings. Click the Trap Settings tab. For viewing traps in Alarms tables (i.e. saving traps to database) For viewing traps in Traps pane Figure 25-3: Enabling trap display in WipManage 25-4 Airspan Networks Inc. 01040311-07...
  • Page 509 1) Traps are displayed with a specific severity level: Normal , Warning Major , and Critical 2) To receive traps, ensure the Stop Listening button is displayed (default) on the WipManage main window's toolbar. If the Start Listening button is displayed, click this button. 01040311-07 Airspan Networks Inc. 25-5...

  • Page 510: Showing The Traps Pane

    Traps not saved in the DB appear with a number sign (#) alongside the index number, e.g. "#2" Traps from a previous WipManage session and not saved in the DB appear with "Old" alongside the index number, e.g. "Old 2" 25-6 Airspan Networks Inc. 01040311-07...

  • Page 511: Viewing The Alarms Table

    To view traps saved in the DB in device-specific windows (e.g. BSR Zoom window): In the BSR Zoom window, from the Alarms menu, choose Alarms Log. The Alarms Table window appears, as displayed below. Figure 25-5: Alarms table displaying traps saved in DB 01040311-07 Airspan Networks Inc. 25-7...

  • Page 512: Enabling Pop-Up Notifications And Execution Of Batch Files On Trap Receipt

    In the IP List field corresponding to the desired trap name, enter the IP address of the ASWipLL device, and then press the <Enter> key. To enable a pop-up window to notify that the trap was generated by the ASWipLL device, select the PopUp check box that corresponds to the trap name. 25-8 Airspan Networks Inc.
  • Page 513 Click OK. To delete an IP address or a file, simply right-click the lower dividing line of the row in which the IP address or file is entered, and then from the shortcut menu, choose Delete. 01040311-07 Airspan Networks Inc. 25-9...

  • Page 514: Enabling/Disabling Receipt Of Specific Traps

    To enable/disable WipManage receiving specific traps (e.g. from BSR): In the BSR Zoom window, from the Alarms menu, choose Config Traps. The Configure Traps dialog box appears, as displayed in Figure 25-7. Figure 25-7: Configuring traps 25-10 Airspan Networks Inc. 01040311-07...
  • Page 515 To receive traps indicating that SPR/IDR devices have been associated (connected) with the BSR, select the Association Connect Trap check box. To receive traps indicating that an SPR/IDR has connected to the BSR through AutoConnect, select the AutoConnect Trap from BSR check box. 01040311-07 Airspan Networks Inc. 25-11...
  • Page 516 (i.e. 128 MAC addresses), select the MAC Table Overflow Trap check box. Notes: 1) The Acknowledge RF E2 Trap button is not applicable. Latest ASWipLL releases perform this automatically. 2) Some alarm types are not configurable (for example, Cold Start).

  • Page 517: Upgrading Aswipll Database

    Sometimes a new ASWipLL release employs a new version of the ASWipLL database. Airspan's WipLL DB Upgrade utility tool, generally supplied on a CD with your ASWipLL system, provides you with the means for upgrading the ASWipLL database. WipLL DB Upgrade allows you to perform the following:...

  • Page 518: Summary Of Tasks

    C o m m i s s i o n i n g M a n u a l 26.2. Summary of Tasks The flowchart in the figure below displays a summary of tasks for upgrading the ASWipLL database. Figure 26-1: Flowchart for upgrading the ASWipLL database 26-2 Airspan Networks Inc. 01040311-07...

  • Page 519: Task 1: Install Wipll Db Upgrade

    WipLL DB Upgrade is supplied on a CD. The CD's installation wizard guides you through the installation steps. You need to install WipLL DB Upgrade on the same PC on which the ASWipLL database resides. To install WipLL DB Upgrade: Insert the WipLL DB Upgrade CD in your CD-ROM drive.
  • Page 520 Figure 26-3: Choose Destination Location window 6. To accept the default destination folder for installing WipLL DB Upgrade, click Next, or to install WipLL DB Upgrade to a different folder, click Browse, and then select the desired folder. 26-4 Airspan Networks Inc. 01040311-07...
  • Page 521 U p g r a d i n g AS W i p L L D a t a b a s e Figure 26-4: Select Program Manager Group window Accept the default Program Manager group ("WipLL"), and then click Next. 01040311-07 Airspan Networks Inc. 26-5...
  • Page 522 U p g r a d i n g AS W i p L L D a t a b a s e C o m m i s s i o n i n g M a n u a l Figure 26-5: Start Installation window 8. Click Next to begin the installation. 26-6 Airspan Networks Inc. 01040311-07...
  • Page 523 U p g r a d i n g AS W i p L L D a t a b a s e The Installing window appears, displaying the installation progress. Figure 26-6: Installing window When the WipLL DB Upgrade has been copied to the selected folder, the Desktop Shortcut window appears. 01040311-07 Airspan Networks Inc. 26-7...
  • Page 524 C o m m i s s i o n i n g M a n u a l Figure 26-7: Desktop Shortcut window 9. Select the Add Shortcut to Desktop check box to add the WipLL DB Upgrade shortcut icon to your desktop, and then click Next. 26-8 Airspan Networks Inc. 01040311-07...
  • Page 525 U p g r a d i n g AS W i p L L D a t a b a s e Figure 26-8: Installation Complete window 10. To close the installation wizard, click Finish. The WipLL DB Upgrade shortcut icon appears on the desktop: Figure 26-9: WipLL DB Upgrade shortcut icon 01040311-07 Airspan Networks Inc. 26-9...

  • Page 526: Task 2: Start Wipll Db Upgrade

    Once you have installed WipLL DB Upgrade on your PC, you can start the application. To start WipLL DB Upgrade: From the Start menu, point to Programs, point to Airspan, and then choose WipLL DB Upgrade, -Or- On your desktop, double-click the WipLL DB Upgrade shortcut icon.

  • Page 527: Task 3: Upgrade The Aswipll Database

    U p g r a d i n g AS W i p L L D a t a b a s e 26.5. Task 3: Upgrade the ASWipLL Database The following describes the procedure for upgrading the ASWipLL database, wiplldb.mdb.
  • Page 528 Figure 26-12: Selecting a database If the selected database file (with the *.mdb file extension), does not conform to ASWipLL standards for upgrading a database, an error message box appears, as displayed in Figure 26-13. Figure 26-13: Incorrect database or version In the Upgrade To drop-down list, select the new database version number to which you want to upgrade the old version.
  • Page 529 Note: If you use the Browse button, all you need to enter is the file name. By default, the upgraded database will be generated in the same folder as the original. Figure 26-14: Naming the new database Figure 26-15: Selected database 01040311-07 Airspan Networks Inc. 26-13...
  • Page 530 The upgrade details that you selected above, are displayed in the following window: Figure 26-16: Upgrade details confirmation 6. Click Finish. When WipLL DB Upgrade successfully completes the upgrading process, the Congratulations message box appears, as displayed below. Figure 26-17: Congratulations message box 26-14 Airspan Networks Inc. 01040311-07...

  • Page 531: Task 4: Compact The Aswipll Database

    U p g r a d i n g AS W i p L L D a t a b a s e 26.6. Task 4: Compact the ASWipLL Database After you have upgraded the ASWipLL database, WipLL DB Upgrade allows you to free disk space on your PC by compacting your database file. This frees unused disk space by removing references no longer in use.
  • Page 532 U p g r a d i n g AS W i p L L D a t a b a s e C o m m i s s i o n i n g M a n u a l This page is intentionally left blank. 26-16 Airspan Networks Inc. 01040311-07...

  • Page 533: Upgrading Aswipll Devices

    Upgrading ASWipLL Devices This chapter describes the procedures for upgrading ASWipLL devices, and includes the following sections: Overview Remote Upgrade using WipManage Upgrading Multiple SPRs Upgrading a Single BSR Local Serial Upgrade using WipConfig Troubleshooting Note: This chapter mentions the BSR and SPR devices. However, the BSR procedures are also applicable for PPR devices;...

  • Page 534: Overview

    SW version file. When you upgrade an ASWipLL device, the SW version file is first downloaded to the device's standby SW bank. To enable the device to use the file, you need to transfer the file to the device's active SW bank.
  • Page 535 ASWipLL device. Table 27-2 and Table 27-3 lists examples of permissible upgrades from one ASWipLL release to another (starting from the earliest release 2.6 to the latest release 4.6). The ASWipLL release depicts the SW version pertaining to the specific release.
  • Page 536 4.2b 4.4a 4.4a 4.2c 4.4a The table below lists the SW version file names for the ASWipLL devices that are downloaded to the relevant ASWipLL device. Table 27-4: SW version file names per ASWipLL device ASWipLL device SW version file...

  • Page 537: Remote Upgrade Using Wipmanage

    27.2. Remote Upgrade using WipManage You can perform SW version upgrade with WipManage (and a TFTP server) from any remote location with IP connectivity to the ASWipLL devices (i.e. BSR, BSDU, and SPR/SDA). The remote upgrade for SPR/SDA is via the BSR, which provides the wireless link with the SPR/SDA.

  • Page 538: Upgrading Multiple Sprs

    TFTP’s Outbound path to the folder in which the software version file (i.e. SW version 2.97.000.002) is located TFTP allows maximum simultaneous clients In the BSR Zoom window, from the MultiDevices menu, choose Download Manager, as displayed below. Figure 27-2: Choosing the Download Manager command 27-6 Airspan Networks Inc. 01040311-07...
  • Page 539 Figure 27-3: Download Manager dialog box In the TFTP Server IP field, enter the TFTP server's IP address (e.g. 10.0.0.2). Select the SPRs that you want to upgrade, by clicking the check boxes corresponding to the SPRs. 01040311-07 Airspan Networks Inc. 27-7...
  • Page 540 C o m m i s s i o n i n g M a n u a l 5. Click Download A blue progress bar indicates the progress of the downloading process for each SPR, as displayed below. Progress bar Figure 27-4: Downloading SW version file 2.78.000.005 to multiple SPRs 27-8 Airspan Networks Inc. 01040311-07...
  • Page 541 When the download is complete, the Download Manager dialog box displays the following, as displayed below: Progress bar: "Download Success" Standby Bank field: "2.97.000.002" Downloaded SW file in Standby bank "Download Success" message Figure 27-5: Download complete (SW version file in Standby bank) 01040311-07 Airspan Networks Inc. 27-9...
  • Page 542 Active software bank. The Swap dialog box appears, as displayed below. Figure 27-6: Swap dialog box 7. Select the Match Data check box, and then click Yes to swap software banks and reset the SPRs. 27-10 Airspan Networks Inc. 01040311-07...
  • Page 543 Figure 27-7: SW version file transferred to Active bank 8. Click Lock Active to ensure that the downloaded SW version file in the Active bank becomes default, and to prevent the file swapping with the file in the Standby bank. 01040311-07 Airspan Networks Inc. 27-11...
  • Page 544 Figure 27-8: SW version file (2.97.000.002) locked in Active bank Click Close, to close the Download Manager dialog box. Continue to upgrade the BSR and BSDU from their respective windows until all the devices are upgraded. 27-12 Airspan Networks Inc. 01040311-07...

  • Page 545: Upgrading A Single Bsr

    (i.e. for SW version 2.97.000.002) is located is defined. 2. In the BSR Zoom window, from the Configuration menu, choose Download, as displayed below. Figure 27-9: Choosing the Download command 01040311-07 Airspan Networks Inc. 27-13...
  • Page 546 In the TFTP Server IP field, enter the TFTP server’s IP address (e.g. 10.0.0.2, i.e. IP address of PC, on which the TFTP server is running). Click Start Download to begin downloading the new software to the BSR. 27-14 Airspan Networks Inc. 01040311-07...
  • Page 547 U p g r a d i n g AS W i p L L D e vi c e s A blue progress bar indicates the progress of the downloading process. Progress bar Figure 27-11: Downloading SW version file 01040311-07 Airspan Networks Inc. 27-15...
  • Page 548 Figure 27-12: Progress bar: "100%" Download Status field: "Download Success" Standby Bank field: "2.97.000.002" Downloaded file in Standby bank "Download Success" message Progress bar displaying 100% Figure 27-12: Download complete (SW version file in Standby bank) 27-16 Airspan Networks Inc. 01040311-07...
  • Page 549 Figure 27-13: Reset dialog box 6. Select the Match Data check box, and then click Yes to swap banks and reset the SPR. The Device Reset message box appears, as displayed below. Figure 27-14: Device Reset message box 01040311-07 Airspan Networks Inc. 27-17...
  • Page 550 After a few seconds, the SW version file is transferred to the Active bank and the previous SW version file is transferred to the Standby bank, as displayed in Figure 27-15. Downloaded file transferred to Active bank Figure 27-15: Download dialog box displaying SW version file in Active bank 27-18 Airspan Networks Inc. 01040311-07...
  • Page 551 The Status field of the Active bank displays "Locked", as displayed below. SW file locked in Active bank Figure 27-16: Download dialog box displaying locked Active bank 9. Click Close to complete the software version upgrade. 01040311-07 Airspan Networks Inc. 27-19...

  • Page 552: Local Serial Upgrade Using Wipconfig

    WipConfig to the ASWipLL device. Upgrades through a serial configuration are required when installing the devices and before a BSR-SPR air link is established. For a detailed explanation on the serial cable setup, refer to the ASWipLL Hardware Installation Guide.
  • Page 553 The Configuration pane (e.g. SPR) appears, displaying the device’s basic configuration settings, as displayed below. Download /Upload button Figure 27-17: WipConfig connected to SPR through serial mode In the Outlook bar, click the Download/Upload button. 01040311-07 Airspan Networks Inc. 27-21...
  • Page 554 C o m m i s s i o n i n g M a n u a l The Download/Upload pane appears, as displayed below. Figure 27-18: Download/Upload pane with SW version 02.96.000.01 in Active bank 4. In the File field, click the double-arrow button. 27-22 Airspan Networks Inc. 01040311-07...
  • Page 555 Figure 27-19: Browsing to the software version file to download Browse to the folder that contains the software version file, and then click OK. The File field displays the path and SW file name relevant to the device type. 01040311-07 Airspan Networks Inc. 27-23...
  • Page 556 Current Action field: "Software Download" Current Status field: "Erasing" and then "Download in Progress" Progress bar: indicates progress of download in percentage "Software Download" message "Download in Progress" message Progress bar Figure 27-20: Progress bar indicating download in progress 27-24 Airspan Networks Inc. 01040311-07...
  • Page 557 When the download is complete, the following is displayed: Current Status field: "Download Finished" Standby Bank field: "02.97.000.02" Downloaded file in Standby bank "Download Finished" message Figure 27-21: Download complete and SW version file in Standby bank 01040311-07 Airspan Networks Inc. 27-25...
  • Page 558 The Ask User confirmation box appears, as displayed in Figure 27-22. Figure 27-22: Confirming swap (and reset) action from Standby to Active bank 8. Click Yes. The Information box appears, as displayed below. Figure 27-23: Information box 27-26 Airspan Networks Inc. 01040311-07...
  • Page 559 Active bank, and the previous SW version file is transferred to the Standby bank, as displayed below. Downloaded file transferred to Active bank Figure 27-24: Downloaded SW version file moved from Standby to Active bank 01040311-07 Airspan Networks Inc. 27-27...
  • Page 560 Standby bank. The Status field of the Active bank displays "locked", as displayed below. Downloaded file locked in Active bank Figure 27-25: Downloaded SW version file locked in Active bank 27-28 Airspan Networks Inc. 01040311-07...

  • Page 561: Troubleshooting

    Unable to download outbound path is correctly pointing to the folder in which the software version is located. • WipConfig: verify path is correctly pointing to the folder in which the software version is located 01040311-07 Airspan Networks Inc. 27-29...
  • Page 562 U p g r a d i n g AS W i p L L D e vi c e s C o m m i s s i o n i n g M a n u a l This page is intentionally left blank. 27-30 Airspan Networks Inc. 01040311-07...

  • Page 563: Evaluating Link Quality

    This includes measuring the following parameters: RSSI (received signal strength indication) Throughput (i.e. bandwidth) Note: Link quality must be tested for a single link, i.e. between a BSR and an SPR. 01040311-07 Airspan Networks Inc. 28-1...

  • Page 564: Rssi Levels

    BSR, traffic generation is required (see Section 28.5, "Generating Traffic to Measure Throughput"). Typically, the RSSI is measured at the BSR using WipManage, and the RSSI is measured at the SPR using WipConfig. 28-2 Airspan Networks Inc. 01040311-07...

  • Page 565: Measuring Rssi At Spr Using Wipconfig

    To measure RSSI at SPR using WipConfig: Start WipConfig. In the outlook bar, click the WipConfig tab. Click the Statistics button. The Statistic pane appears, as displayed below. RSSI graph Figure 28-1: Statistics pane displaying RSSI graph 01040311-07 Airspan Networks Inc. 28-3...

  • Page 566: Measuring Rssi At Bsr Using Wipmanage

    Open the BSR Zoom window pertaining to the BSR whose RSSI you want to measure. From the Performance menu, point to Air, point to Cell, and then choose RSSI per SPR. The RSSI Per SPR dialog box is displayed below. Figure 28-2: RSSI per SPR graph 28-4 Airspan Networks Inc. 01040311-07...

  • Page 567: Carrier-To-Interference Ratio

    1.33 Mbps and 1 Mbps 12 dBm Note: ASWipLL can operate in 2-, 4-, and 8-level FSK with signal strengths greater than -90, -83, and -75 dBm, respectively. For example, if the noise level measured by the spectrum analyzer is -70 dBm (see...

  • Page 568: Spectrum Analysis Using Wipconfig

    1) Airspan’s Spectrum Analyzer feature, which plugs into WipConfig, is license- dependant. 2) Ensure all other ASWipLL devices are powered off, except the device whose spectrum you are analyzing. 3) Mount the ASWipLL device prior to commencing the spectrum analysis.

  • Page 569: Accessing The Spectrum Analyzer

    Serial mode: on the toolbar, select the Serial option, and then click Connect. IP mode: on the toolbar, select the Network option, and then in the Remote Agent field, enter the ASWipLL device's IP address, and then click Connect. In the Outlook bar, click the Spectrum Analyzer button;...

  • Page 570: Starting The Spectrum Analyzer

    Stop Freq: frequency to where you want to scan (i.e. upper frequency) 28.3.1.3. Starting the Spectrum Analyzer To start and stop the Spectrum Analyzer, click the Start and Stop buttons (located below the graph), respectively. 28-8 Airspan Networks Inc. 01040311-07...

  • Page 571: Viewing Results

    Distance (in spectrum RF) that the BSR/PPR can establish a viable communication link with another transmitter. This is displayed in the TxRxOffset field. Interference of –70 dBm at 2,445 MHz Figure 28-3: WipConfig's spectrum analyzer showing peak interference of -70 dBm 01040311-07 Airspan Networks Inc. 28-9...

  • Page 572: Bit Error Rate (Ber)

    Note: To measure BER, ensure that a flood of packets between the BSR and SPR are generated (see Section 28.5, "Generating Traffic to Measure Throughput"). The BER can be measured locally at the SPR using WipConfig, or it can be measured remotely using WipManage. 28-10 Airspan Networks Inc. 01040311-07...

  • Page 573: Measuring Ber Using Wipconfig

    Start WipConfig, and then connect it to the SPR. In the outlook bar, click the Statistics button. The Statistic pane appears, as displayed below. BER graph measuring BER between BSR and SPR Figure 28-4: Statistics pane 01040311-07 Airspan Networks Inc. 28-11...

  • Page 574: Measuring Ber Using Wipmanage

    Open the BSR Zoom window pertaining to the BSR whose BER you want to measure. From the Performance menu, point to Air, point to Cell, and then choose BER per SPR. The BER per SPR window is displayed below. Figure 28-5: BER per SPR graph 28-12 Airspan Networks Inc. 01040311-07...

  • Page 575: Generating Traffic To Measure Throughput

    Slow Start phenomenon (succinct explanation can be found in RFC #2001). During the test, record the RSSI and BER levels for the BSR and SPR/IDR. This information is useful to Airspan’s technical support team for future diagnosis. 01040311-07 Airspan Networks Inc.
  • Page 576 E va l u a t i n g L i n k Q u a l i t y C o m m i s s i o n i n g M a n u a l This page is intentionally left blank. 28-14 Airspan Networks Inc. 01040311-07...

  • Page 577: Troubleshooting

    Troubleshooting This chapter explains how to solve the following problems that you might encounter when using WipManage: No PC-BSR Network Link No BSR-SPR Air Link No PC-SPR Network Link 01040311-07 Airspan Networks Inc. 29-1...

  • Page 578: No Pc-Bsr Network Link

    • Ensure that the external antenna is connected (if an external antenna exists). • Ensure that the distance between the BSR and SPR/IDR is in range for RF communication. • Ensure no obstacles in LOS between BSR and SPR/IDR that may interfere with transmission. 29-2 Airspan Networks Inc. 01040311-07...

  • Page 579: No Pc-Spr Network Link

    • Check PC’s routing table for correct routes from BSR to SPR/IDR (MS-DOS command: route print): • For AS WipLL in the transparent bridge mode, check PC’s routing table for correct routes from BSR to SPR/IDR (MS-DOS command: tracert <SPR’s IP address>: 01040311-07 Airspan Networks Inc. 29-3...
  • Page 580 • If all the above routing verifications are correct, and still no network link to the SPR/IDR, using WipConfig, reset the SPR/IDR to factory defaults, and then reconfigure the SPR/IDR. This ensures that your configuration settings are correct. 29-4 Airspan Networks Inc. 01040311-07...

This manual is also suitable for:

As3010

Table of Contents
