E s t a b l i s h i n g B S R - S P R L i n k i n R o u t e r M o d e
Figure 4-20: Adding advanced BSR parameters
Enter the following Advanced group fields, as desired:
BSDU Index in BS: BSDU (1 through 4) to which you want to add the BSR.
By default, the displayed BSDU index number corresponds to the BSDU that
appears in the same the row in which you right-clicked.
Index in BSDU: Up to six BSRs can be added to a BSDU. The index
number (1 through 6) represents a unique BSR number within the BSDU. By
default, the displayed index number is that which corresponds to the BSR
box in which you right-clicked.
6. Click OK.
