Pyronix 256 System Manual page 77

Type
0059 Engineer Access
0060 Initialise Digi
0063 Test ATE/GSM*
0064 Test ATS
0066 ATE not used
A repeating block of output types should be noted:
0202 Hold Up A
0203 Intruder A
0204 Final Arm A
0207 Tamper A
0208 Duress A
0209 HU Device A
0213 Secure Intruder A
0214 Bell A
0216 Strobe A
0217 Omit At Rearm A
0218 Unconfirmed A
0219 Can Arm A
0220 Exit Starts A
Then this pattern repeats for each other partition, so that:
0221-0240 Partition / Arm Level B
0241-0260 Partition / Arm Level C
0261-0280 Partition / Arm Level D
0281-0300 Partition / Arm Level 0*
0301-0320 Partition / Arm Level 1*
0321-0340 Partition / Arm Level 2*
0341-0360 Partition / Arm Level 3*
1xxx Follow input xxx
i.e. add 1000 to the input number to select output required
Partition Sounder
*NOT AVAILABLE ON PCX 26/SMS
For the defaults please see page: 78
RINS871-3
P C X S M S A N D P C X 2 5 6 S Y S T E M M A N U A L
Active
When entering Engineer Mode
At power up
Test signalling through
PSTN and GSM. Activates
when a test call is
sent.(used for specific
GSMs)
Test signalling through
PSTN and GSM. Activates
when a test call is sent.
Makes the ATE pin 5V.
As 0002 for Partition A / Arm Level A events only
As 0003 for Partition A / Arm Level A events only
As 0004 for Partition A / Arm Level A events only
As 0007 for Partition A / Arm Level A events only
As 0008 for Partition A / Arm Level A events only
As 0009 for Partition A / Arm Level A events only
As 0013 for Partition A / Arm Level A events only
As 0014 for Partition A / Arm Level A events only
As 0016 for Partition A / Arm Level A events only
As 0017 for Partition A / Arm Level A events only
As 0018 for Partition A / Arm Level A events only
As 0019 for Partition A / Arm Level A events only
As 0020 for Partition A / Arm Level A events only
When input is activated
At output 2 of the RIX2 (fixed as loudspeaker)
Restore
When leaving Engineer Mode
Live for 45 seconds only
When test completed
When test completed
0361-0380 Partition / Arm Level 4*
0381-0400 Partition / Arm Level 5*
0401-0420 Partition / Arm Level 6*
0421-0440 Partition / Arm Level 7*
0441-0460 Partition / Arm Level 8*
0461-0480 Partition / Arm Level 9*
When input clears
