5 ACTUAL VALUES

5 ACTUAL VALUES 5.1 OVERVIEW
All actual values messages are listed and explained in this chapter. Messages are organized into logical
groups of pages. Each page contains sections of related messages. The actual values menu has 4 pages con-
taining the following information:
Table 5–1: ACTUAL VALUES PAGES
PAGE CONTENTS
1 Data
2 Status
3 Inputs
4 Statistics
This chapter shows the actual messages displayed on the front panel of the MM3. Quantities shown are typical
values only. Different quantities will be displayed in each particular application.
When finished viewing a message in a particular section, press
When the last line of a section is reached, press
When the last line of the last section within a page is reached, press
NOTE
Up to 5 default messages can be selected to scan sequentially when the motor is running and the MM3 is left
unattended. If no keys are pressed for 2 minutes and the motor is running, then the currently displayed mes-
sage will automatically be overwritten by the first default message. After 3 seconds, the next default message
in the sequence will display if more than one is selected. Alarm and trip messages override the default mes-
sage display. Any actual value or setpoint can be selected as a default message. For example, the MM3 could
be programmed to display these messages in sequence: three-phase current, ground current, motor status,
motor current as a percentage of full load, and analog input.
Messages are displayed in the order they are selected. To add a default message, use the message keys to
display any actual values or setpoints message to be added to the default queue. Press the
in rapid succession. The display will prompt:
TO ADD THIS DEFAULT
MESSAGE PRESS STORE
Press STORE again. The display confirms that the default message has been added. If 5 default messages are
already selected, the first message is erased and the new message added to the end of the queue.
To delete a default message, wait for 2 minutes and note the messages that are displayed in sequence. Use
the message keys to display the default message to be erased. Press
The display prompts:
TO DELETE THIS
MESSAGE PRESS STORE
Press the key. The display confirms that the default message has been deleted. If the message was not
STORE
a current default message, the display will read:
NOT A SELECTED
DEFAULT MESSAGE
GE Power Management
MESSAGE

5.1.2 DEFAULT MESSAGE SELECTION

MM3 Motor Manager 3

5.1 OVERVIEW

5.1.1 DESCRIPTION

MESSAGE to view the next line.
to view the next section in the page.
ACTUAL to select the next page.
STORE
STORE then RESET in rapid succession.
5
key twice
5-1
