This page is used to enter setpoints for monitoring and motor maintenance. Setpoints Page 5 has two sections,
PLANT CONDITION and PRESET COUNTERS AND TIMERS
.
]] SETPOINTS
]] S5: MONITORING
PATH: SETPOINTS MMMMM S5 MONITORING M PLANT CONDITION
MOTOR GREASING
INTERVAL: OFF hrs
MESSAGE
CONTACTOR INSPECTION
MESSAGE
OFF x 1000 OPS
MAX MOTOR STOPPED
MESSAGE
TIME: OFF hrs
GE Power Management

] PLANT CONDITION

MESSAGE
]
] PRESET COUNTERS
] AND TIMERS
MESSAGE
Range: 100 to 50000 hours or OFF; Step: 100 HOURS
Enter the interval at which the motor bearings must be lubricated. When
the Motor Running Time exceeds this setpoint a MOTOR GREASING
INTERVAL ALARM is generated. Use the CLEAR TIMERS setpoint in
S1: CONFIGURATION \ STATISTICS to clear the Motor Running Hours. If this
feature is not required set this setpoint to OFF.
Range: 1000 to 10000000 operations or OFF; Step: 1000 ops.
Enter the interval at which the contactor contacts must be inspected for
wear. When the NUMBER OF STARTS counter exceeds this setpoint a
CONTACTOR INSPECTION INTERVAL ALARM is generated. Use the
S1: CONFIGURATION \ STATISTICS \ CLEAR COUNTERS setpoint to clear the
NUMBER OF STARTS counter. If this feature is not required set this setpoint
to OFF.
Range: 10 to 10000 hours or OFF; Step: 10 hours
Enter the maximum interval that the motor can be left not running. When
the Motor Stopped Time exceeds this setpoint, a MAXIMUM MOTOR
STOPPED TIME ALARM is generated. Start the motor to clear the Motor
Stopped Time. If this feature is not required set this setpoint to OFF.
